User manual
Sony Alpha a6000 Mirrorless Digital Camera

User Manual for Sony Alpha a6000 Mirrorless Digital Camera with 16-50mm Lens and Accessory Kit

• Product category: Mirrorless System Cameras Sony
• Brand: Sony
• Description and content of package
• Technical information and basic settings
• Frequently asked questions – FAQ
• Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
• Authorized service for Sony Mirrorless System Cameras

Product description

• Sony Alpha a6000 Mirrorless Digital Camera with 16-50mm Lens (White)
  • Sony a6000
  • Sony a6000 Auto Focus
  The white Sony Alpha a6000 Mirrorless Digital Camera is a versatile and advanced mirrorless camera featuring a 24.3MP APS-C-sized Exmor APS HD CMOS sensor and BIONZ X image processor to produce high-resolution still images and Full HD movies with marked low-light quality and sensitivity to ISO 25600. Beyond notable imaging traits, the image processor also lends itself to continuous shooting up to 11 fps and an intelligent Fast Hybrid AF system that uses both phase- and contrast-detection methods to quickly and accurately acquire focus.

  For live view monitoring, image playback, and menu navigation, both a large rear monitor and detailed electronic viewfinder are available. The 3.0" 921k-dot XtraFine LCD screen features a tilting design to facilitate easier use from both high and low angles and also incorporates WhiteMagic technology for easier viewing in bright conditions. The 0.39" 1,440k-dot Tru-Finder OLED EVF offers 100% frame coverage and a refined optical design to provide a natural viewing perspective and magnification. The body design of the a6000 also houses a configurable user interface, built around several customizable buttons and two control dials, for efficient and intuitive access to frequently used camera settings. Additionally, a Multi Interface shoe is available for attaching external flashes, continuous lights, or microphones.

  Built-in Wi-Fi connectivity, with support for NFC-enabled devices, is also integrated into the a6000 to support remote camera control and image sharing to linked mobile devices. In addition to these base features, with firmware version 2.0 users will have access to the XAVC S format for Full HD 1080p video at 24, 30, and 60 fps. This format will dramatically improve video quality by allowing the camera to capture images at a high bit rate of 50 Mbps, which holds more information than AVCHD for fewer artifacts. Along with this, users will be required to use Class 10 or faster SDXC memory cards with a capacity of 64GB or greater.

  Included with the camera body is a Sony E-mount 16-50mm f/3.5-5.6 OSS Retractable Zoom Lens, which provides a 35mm-equivalent focal length range of 24-75mm. This range of perspectives is well-suited to everyday shooting and is further enhanced through the inclusion of Optical SteadyShot image stabilization for minimizing the appearance of camera shake. Power Zoom technology allows for electronic control over the zoom position and the inclusion of one extra-low dispersion element and four aspherical elements helps to reduce chromatic aberrations throughout the zoom range as well as contribute to high overall sharpness.
  24.3MP Exmor APS HD CMOS Sensor and BIONZ X Image Processor
  • The 24.3MP APS-C-sized Exmor APS HD CMOS sensor and BIONZ X image processor work together to produce high resolution, well-detailed imagery with minimal noise and notable low-light quality and sensitivity to ISO 25600. The sensor utilizes a gapless on-chip lens design, which fills the gaps between neighboring pixels with optimized lenses that match the angle of incidence to increase light gathering ability and produce edge-to-edge sharpness and quality. The processor also contributes to providing a wealth of speed throughout the camera system, including Fast Hybrid AF, a top continuous shooting rate of 11 fps, and Full HD 1080i/p video recording in multiple frame rates.
  Fast Hybrid AF System
  • The Fast Hybrid AF system utilizes both a 179-point phase-detection system and 25-point contrast-detection system to achieve precise focus in as little as 0.06 sec. Utilizing a Spatial Object Detection algorithm, this fast focusing system first employs the phase-detection AF points to quickly bring the subject into focus and then uses the contrast-detection AF points, with wide AF coverage, to fine-tune the sharpness for ensured accuracy. Beyond supporting single shot modes, this system also provides AF tracking when shooting up to 11 fps in continuous high mode and functions seamlessly when recording Full HD movies.

    For further refinement, a series of distinct AF modes can be selected from depending on the subject. Eye AF is a detail-oriented focusing function that can prioritize a subject's pupil and dedicate focusing performance on that for sharply-rendered portraits; Lock-on AF is a dedicated focusing method for use with moving subjects and adjusts the target frame size as the subject moves throughout the image frame; AF area settings allow you to prioritize specific regions within the frame for increased accuracy; and AF-A (Automatic AF), AF-S (Single-shot AF), AF-C (Continuous AF), DMF (Direct Manual Focus), and Manual Focus modes can also be chosen.
  Full HD Video Recording
  • Full HD 1080p video recording is supported at 60, 30, and 24 fps in the high-quality 50 Mbps XAVC S codec. Other recording options include the ability to utilize the AVCHD and MP4 codecs, with support for recording up to 1080p60 video at 28 Mbps. Dual video recording is supported, as well, with the ability to select either XAVC S or AVCHD codecs plus a duplicate MP4 file to be recorded at the same time for greater efficiency when sharing videos online. Additionally, using the integrated HDMI type D output, both 1080i60 and 1080p60 uncompressed 8-bit 4:2:2 video can be recorded to an optional external recorder.

    Complementing the video capabilities of the a6000, a built-in stereo microphone is incorporated into the design and records audio in the Linear PCM 2-channel format for XAVC S movies, the AC-3 Dolby Digital format for AVCHD movies, and the MPEG-4 AAC-LC format for web-quality MP4 videos.

    Manual focus peaking and a zebra function are also available, to benefit working in manual focus and to assure highlight detail is retained, respectively. A marker setting can be shown on the rear LCD as well, in order to display a center marker, guide frame, aspect marker, safety zone, and other pertinent features for video recording.
  Body Design
  • Revolving around a compact and lightweight profile, the a6000 incorporates both an electronic viewfinder and a large rear LCD monitor. The Tru-Finder 0.39" 1,440k-dot OLED EVF features a refined optical system that integrates four double-sided aspherical elements to provide 100% frame coverage and a wide 33° viewing angle for clear edge-to-edge viewing. The electronic viewfinder's design offers a true live view image, which is able to simulate the appearance of the finalized image prior to shooting and also avails focusing aids, such as MF Assist and the Peaking function. The 3.0" 921k-dot rear Xtra Fine monitor is a larger alternative, suitable for making accurate compositions, reviewing imagery, and navigating the menu system. It features a tilting design that can tilt upward approximately 90° or downward 45° to benefit working from high and low angles. Additionally, WhiteMagic technology works to increase the overall brightness of the screen to better support use in bright or sunlit conditions.

    Complementing the overall handling of the a6000 is a customizable user interface that includes an Fn function button and seven other buttons that can be adjusted depending upon user preferences and assigned to one of 47 different functions. Furthermore, two top dials offer an intuitive means for selecting crucial camera settings in a deft manner. A built-in pop-up flash, featuring a guide number of 19.7' at ISO 100, is available for working in difficult lighting conditions and a Multi Interface Shoe is also available for attaching additional on-camera accessories, such as flashes, video lights, and microphones.
  Built-In Wi-Fi Connectivity
  • Built-in Wi-Fi connectivity enables the a6000 to instantly share imagery to mobile devices for direct sharing online to social networking, via email, and to cloud storage sites. NFC (Near Field Communication) is also supported, which allows for one-touch connection between the camera and compatible mobile devices; no complex set-up is required. Once connected, the linked mobile device can also display a live view image on its screen and remotely control the camera's shutter.

    Additionally, PlayMemories Camera Apps are also supported via the built-in Wi-Fi connection, and allow you to personalize the camera's features depending on specific shooting styles. Apps are available to suit creating portraits, detailed close-ups, sports, time lapse, motion shot, and other specific types of imagery.
  Compatible Media
  • SD, SDHC, SDXC, Memory Stick PRO Duo, Memory Stick PRO-HG Duo, Memory Stick XC-HG Duo memory cards
  Sony 16-50mm f/3.5-5.6 OSS Retractable Zoom Lens
  • The included silver 16-50mm f/3.5-5.6 OSS Retractable Zoom Lens provides a 35mm-equivalent focal length range of 24-75mm, covering wide-angle to portrait-length perspectives to suit working in a wide variety of situations. It features Optical SteadyShot image stabilization to help minimize the appearance of camera shake by up to four shutter speed steps to greatly benefit working in low-light conditions and with greater zoom magnifications. One extra-low dispersion element and four aspherical elements are integrated into the optical construction to help reduce chromatic aberrations as well as increase clarity, sharpness, and contrast and the Power Zoom electronically-driven zoom mechanism brings greater efficiency to controlling the zoom position of the lens.
  Other Camera Features
  • • The Sony E-mount affords compatibility with an extensive number of lenses and lens adapters.
    • An advanced 1200-zone evaluative exposure metering sensor delivers consistent and accurate results using multi-segment, center-weighted, or spot metering modes.
    • Auto Object Framing is an intelligent shooting mode that can automatically analyze the scene and subjects within it and determine an aesthetically-pleasing composition. The subsequent imagery will be cropped according to subject matter, resulting in a well-balanced composition that utilizes Face Detection and Tracking Focus to ensure high image quality and sharpness.
    • Clear Image Zoom can be used to magnify the center of scenes by 2x to effectively extend the reach of any focal length lens. This digital zoom technology uses an intelligent interpolation process to minimize the amount of image degradation in order to produce realistic, high-quality images.
    • Picture Effect modes allow you to apply creative settings and emphasize certain facets of individual images for a richer, more aesthetic picture quality. Posterization (Color/B&W), Pop Color, Retro Photo, Partial Color (R/G/B/Y), High Contrast Monochrome, Toy Camera, Soft High-Key, Soft Focus, HDR Painting, Rich-Tone Monochrome, Miniature, Watercolor, and Illustration modes are available.
    • The Photo Creativity feature provides quick access to Picture Effects as well as dedicated controls for adjusting Background Defocus, Brightness, Color, and Vividness. Additionally, these effects can be combined for nearly limitless adjustment options.
    • Superior Auto mode is an intelligent automated setting that can quickly identify the current shooting environment and adjust crucial camera settings to deliver optimized results. This mode also utilizes Auto HDR and Hand-held Twilight modes, which employ image compositing techniques to better handle difficult lighting conditions.
    • Anti-Motion Blur automatically corrects for subject movement in order to deliver clean, sharp imagery in low-light conditions. This is accomplished by recording six sequential frames and compositing portions of each image to ensure overall sharpness.
    • Hand-held Twilight Mode automatically composites details from six sequentially-recorded images in order to attain higher overall image sharpness when working in low-light conditions.
    • Multi Frame NR records consecutive images at a reduced ISO sensitivity and then composites them into a single image to realize higher effective sensitivity with minimal image noise.
    • Dynamic Range Optimizer (DRO) works to improve images featuring backlit subjects or scenes with high contrast where details can be lost in the shadows or highlights. This mode can be controlled automatically or fine-tuned using five settings.
    • Auto HDR automatically records three sequential frames of an image and composites them into a single frame to realize greater shadow and highlight detail with an extended range of mid-tones.
    • Creative Style settings provide control over how the camera processes images based on six different predetermined styles: Standard, Vivid, Portrait, Landscape, Sunset, and B&W. Within these settings, contrast, saturation, and sharpness can also be adjusted depending on personal preference.
    • In-camera creation of 4K slide shows is possible for rich playback to ultra high definition televisions. An HDMI port is incorporated into the camera's design, too, to enable direct connection to HDTVs.
    • TRILUMINOS Color support is afforded by the a6000 to produce rich, natural colors when imagery is viewed on a TRILUMINOS Display.
    • Convenient USB charging allows you to charge the included lithium-ion battery in-camera via USB connection from either an AC outlet or PC source.
  UPC: 027242888272
• Ruggard Onyx 25 Camera/Camcorder Shoulder Bag
  • Sony a6000
  • Sony a6000 Auto Focus
  Designed for the photographer and videographer alike, the black with yellow trim Onyx 25 Camera/Camcorder Shoulder Bag from Ruggard is designed to hold a compact camcorder with an attached battery or a mirrorless camera up to 6.75" in length. A durable, weather-resistant nylon shell protects your gear from unwanted elements while high-density foam padding helps prevent damage from accidental impact. For added protection and organization, an included touch-connect divider securely holds your camera in place.

  Small accessories like a spare battery or cleaning cloth can be slipped into either of the two zippered side pockets or the front slip pocket. In addition, three memory card pockets and an another slip pocket are conveniently located under the opening flap of the bag. Carry your gear by way of the top padded grab handle with an integrated mesh underside for added comfort when carrying by hand. Alternatively, a double-touch built-in loop securely wraps around your belt for hands-free carrying. Or, take advantage of the removable 1" wide shoulder strap that can be adjusted from 28" at its shortest length to 53" at its longest length to accommodate a variety of heights and carrying preferences. UPC: 847628571686
• Pawa NP-FW50 Lithium-Ion Battery Pack (7.4V, 1030mAh)
  • Sony a6000
  • Sony a6000 Auto Focus
  The Pawa NP-FW50 Lithium-Ion Battery Pack works with the same cameras as the Sony NP-FW50. This rechargeable replacement pack features 7.4V of output power, a capacity of 1030mAh, and a rating of 7.7Wh. Small and lightweight, lithium-ion batteries can be charged or discharged at any time without developing memory effects.
  Compatible Cameras
  • Alpha:
    • a7S II
    • a7R II
    • a7S
    • a7
    • a7R
    • a7 II
    • a3000
    • a5000
    • a5100
    • a6000
    • a6300
    • a6500
    • NEX-3
    • NEX-5
    • NEX-5N
    • NEX-5R
    • NEX-5T
    • NEX-3N
    • NEX-6
    • NEX-7
    • NEX-F3
    • NEX-C3
    • SLT-A33
    • SLT-A35
    • SLT-A37
    • SLT-A55
    • SLT-A55V
    • A560
    • A580
    Lens-Style Camera:
    • ILCE-QX1
    Cyber-shot:
    • DSC-RX10
    • DSC-RX10 II
  UPC: 847628598010
• Watson Compact AC/DC Charger for NP-FW50 Battery
  • Sony a6000
  • Sony a6000 Auto Focus
  This versatile Compact AC/DC Charger from Watson charges any NP-FW50 lithium-ion battery via the included, dedicated battery plate. The charger runs on 100-240 VAC power, allowing for worldwide use. It features a fold-out, 2-prong US plug and is supplied with a European plug adapter, as well as a 12 VDC car charger that plugs into a cigarette lighter. This makes it ideal for use both at home and on the road. The Compact AC/DC Charger features a USB output that allows you to charge and power MP3 players, phones, digital cameras, and other devices with a USB power input - even while charging your camera or camcorder batteries. As the adapter plates are easily interchangeable, the charger can also be used with other batteries via the purchase of the required plates.
  Compatibility
  • Compatible with any Sony NP-FW50 type battery.
  Compact
  • Charger features a fold-out AC plug for easy storage and travel.
  Versatile
  • Includes a Euro plug adapter for charging in Europe, as well as a DC adapter with a cigarette lighter plug that lets you charge while on the road.
  USB Output
  • Charge or supply power to MP3 players, mobile phones, digital cameras, and other related devices with a USB power input.
  Safety Features
  • Offers protection against overcharging and overheating.
  UPC: 847628545564

• Alpha a6000 Mirrorless Digital Camera with 16-50mm Lens (White) ssruqbbuturddbdqfut
• Sony 16-50mm f/3.5-5.6 OSS Lens (Silver)
• Lens Cap
• NP-FW50 Lithium-Ion Rechargeable Battery (1020mAh)
• Eye Piece
• AC Adapter AC-UB10
• Micro-USB Cable
• Neck Strap
• Limited 1-Year Warranty

• Ruggard - Onyx 25 Camera/Camcorder Shoulder Bag

• Pawa - NP-FW50 Lithium-Ion Battery Pack (7.4V, 1030mAh)

• Watson - Compact AC/DC Charger for NP-FW50 Battery

Upload User Manual

Please enter here the link to the user manual of this product: OR Enter here the file with the user manual of this product from your computer/phone: (60MB max; Permitted formats: PDF) 0%

Technical parameters

• Sony Alpha a6000 Mirrorless Digital Camera with 16-50mm Lens (White)

  Lens Mount	Sony E
  Camera Format	APS-C (1.5x Crop Factor)
  Pixels	Actual: 24.7 Megapixel Effective: 24.3 Megapixel
  Maximum Resolution	6000 x 4000
  Aspect Ratio	3:2
  Sensor Type	CMOS
  Sensor Size	23.5 x 15.6 mm
  Image File Format	JPEG, RAW
  Image Stabilization	None

  ISO Sensitivity	Auto, 100 to 25600
  Shutter Speed	Electronic Front Curtain Shutter 1/4000 to 30 Seconds 1/4000 to 1/4 Second in Movie Mode Bulb Mode
  Metering Method	Center-Weighted Average, Multi-Zone, Spot
  Exposure Modes	Aperture Priority, Manual, Program, Shutter Priority
  Exposure Compensation	-5 to +5 EV (1/3, 1/2 EV Steps)
  Metering Range	0 to 20 EV
  White Balance	Auto, Cloudy, Color Temperature, Color Temperature Filter, Custom, Daylight, Flash, Fluorescent (Cool White), Fluorescent (Day White), Fluorescent (Daylight), Fluorescent (Warm White), Incandescent, Shade, Underwater
  Continuous Shooting	Up to 11 fps
  Self Timer	2/10-Second Delay

  Recording Modes	XAVC S Full HD (1920 x 1080) at 24p/29.97p/59.94p [50 Mb/s] AVCHD Full HD (1920 x 1080) at 59.94p [28 Mb/s] Full HD (1920 x 1080) at 24p/59.94i [17 to 24 Mb/s] MP4 HDV (1440 x 1080) at 29.97p [12 Mb/s] SD (640 x 480) at 29.97p [3 Mb/s]
  Recording Limit	Up to 29 Minutes, 59 Seconds
  Video Encoding	NTSC
  Audio Recording	Built-In Microphone (Stereo)

  Focus Type	Auto and Manual Focus
  Focus Mode	Automatic (A), Continuous-Servo AF (C), Direct Manual Focus (DMF), Manual Focus (M), Single-Servo AF (S)
  Autofocus Points	Phase Detection: 179 Contrast Detection: 25
  Autofocus Sensitivity	0 to +20 EV

  Viewfinder Type	Electronic
  Viewfinder Size	0.39"
  Viewfinder Eye Point	23 mm
  Viewfinder Coverage	100%
  Viewfinder Magnification	Approx. 1.07x
  Diopter Adjustment	-4 to +3 m
  Monitor Size	3"
  Monitor Resolution	921,600 Dot
  Monitor Type	Tilting LCD

  Built-in Flash	Yes
  Flash Modes	Auto, Fill Flash, Off, Rear Sync, Red-Eye Reduction, Slow Sync, Wireless
  Guide Number	19.69' / 6 m at ISO 100
  Maximum Sync Speed	1/160 Second
  Flash Compensation	-3 to +3 EV (1/3, 1/2 EV Steps)
  Dedicated Flash System	TTL
  External Flash Connection	Hot Shoe, Wireless

  Memory Card Slot	1 x SD/SDHC/SDXC/Memory Stick PRO HG-Duo/Memory Stick Pro Duo
  Connectivity	HDMI D (Micro), USB 2.0, Wired Remote Port
  Wireless	Wi-Fi
  GPS	None

  Battery	1 x NP-FW50 Rechargeable Lithium-Ion, 7.2 VDC, 1080 mAh
  Dimensions (W x H x D)	4.7 x 2.6 x 1.8" / 120.0 x 67.0 x 45.0 mm
  Weight	12.13 oz / 344 g (Body with Battery and Memory)

  Focal Length	16 to 50mm (35mm Equivalent Focal Length: 24 to 75mm)
  Maximum Aperture	f/3.5 to 5.6
  Minimum Aperture	f/22 to 36
  Angle of View	83 Rating 92% users recommend this product to others. And what about you? This product has already been rated by 32 owners. Add your rating and experience with the product. Discussion Ask our technicians if you have a problem with your settings, or if anything is unclear in the user manual you have downloaded. You can make use of our moderated discussion. The discussion is public and helps other users of our website who may be encountering similar problems. The discussion is empty - enter the first post Post a new topic / query / comment: Items marked with * are required. Your name *: E-mail : Subject *: Message *: Your email address will not be displayed. Do not forget to fill it in if you want to receive a reply to your enquiry/contribution. Processing of personal data in accordance with GDPR
