Product description The DWR-R01D/30 Dual Channel Diversity Receiver from Sony is designed to work with DWL wireless systems. It is capable of receiving 48 kHz/24-bit audio via true diversity and features two XLR analog outputs as well as 2 AES/EBU digital outputs via XLR. Each channel features its own OLED display and is capable of controlling the connected transmitter. The clear and active channel scan is designed for easy setup by scanning available frequencies and automatically tuning the receiver to them. The DWR-R01D/30 can be controlled remotely via available remote control software for PC. - Covers a wide bandwidth of 66 MHz
- Multiple pre-programmed channel groups which enable simultaneous operation of multiple channels
- Auto channel scanning function
- Large-scale OLED display & user jog wheel
- Network remote control function
- Wireless Studio software included for managing the status and parameters of multiple transmitters
In the Box Sony DWR-R01D/30 Dual Channel Diversity Receiver 2 x Whip Antennas 2 x Antenna Mounts with BNC Connectors AC Power Cord Software CD-ROM 4 x Feet Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Sony DWR-R01D 30 Dual Channel Diversity Receiver in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersSony DWR-R01D Specs | | | Wireless Interface | 2x WiDIF-HP | | Reception | Space diversity | | Circuit | Circuit System: Double superheterodyne | | Receiving Frequency Range | 566.125 to 637.875 MHz (TV-30 to TV-41 channels, except TV-37 channel) | | Channel Step | 125 kHz | | Oscillators | Local Oscillators: Crystal-controlled PLL synthesizer | | Antenna | A/B In Connectors: 2x BNC-R, 50 ohms
A/B Out Connectors: 2x BNC-R, 50 ohms | | Sensitivity | 20 dBu or less (at bit error rate = 1x 10-5, no decline in S/N ration 0 dBu=1 dBuVemf) | | | | Analog Output | Output 1/2 Connectors: 2x XLR-3-32 type (male)
Digital Out 1/2/3 Connectors: 2x XLR-3-32 type (male), 1x BNC-R | | Reference Output | Reference Output Level:
Analog:-58 dBu (mic output), -12 dBu (line output)
Digital: -36 dBFS | | Dynamic Range | 106 dB or more (A-weighted) | | THD | 0.03% or less | | Audio Delay | 1/9 ms, analog and digital output | | Word Sync I/O | Input 1 & Output 1: BNC-R with a 75 ohm switch | | External Word Sync | 32 to 96 kHz | | | | Wireless Remote | Cross remote function (2.4 GHz IEEE802.15.4 compliant) | | LAN Connectors | 10/100 Connector: 1x RJ-45 modular jack | | | | Operating Voltage | 120 VAC | | Power Consumption | 22 W | | Operating Temperature | 32° to 122°F (0° to 50°C) | | Storage Temperature | -4° to 140°F (-20° to 60°C) | | Dimensions (W x H x D) | 19 x 1.75 x 13.25" (482 x 44 x 335 mm) | | Weight | 9.1 lb (4.1 kg) |
