User Manual for Sony HDR-CX900 Full HD Handycam Camcorder Click to enlarge the picture
Contents of the user manual for the Sony HDR-CX900 Full HD Handycam Camcorder
- Product category: Consumer Camcorders Sony
- Brand: Sony
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Sony Consumer Camcorders
 |
User manual for the Sony HDR-CX900 Full HD Handycam Camcorder contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Sony product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Sony user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Sony product will considerably shorten its lifespan!
|
Product description - Sony HDR-CX900 Demo
- Sample Movie for Handycam HDR-CX900
The black Sony HDR-CX900 Full HD Handycam Camcorder brings broadcast-quality HD video to the palm of your hand. The 1" Exmor R CMOS sensor is approximately 8x larger than that of typical camcorders, allowing you to capture cinematic images with shallow depth of field for defocused backgrounds. The camcorder features a wide-angle Zeiss Vario-Sonnar T* lens with 12x optical zoom plus 24x Clear Image digital zoom. SteadyShot image stabilization with Active Mode delivers smooth video, and 3-Way-Shake-Canceling adds electronic roll stability for even smoother results.
The HDR-CX900 is a versatile camcorder that lets you capture Full HD 1920 x 1080 video in XAVC S (up to 50 Mb/s), AVCHD, or web-optimized MP4. You can also capture high-quality 20MP still images. Frame your shots using either the large 3.5" XtraFine LCD touchscreen, or with the high-contrast 0.39" OLED EVF. For connectivity, the camcorder provides a USB 2.0 port, micro-HDMI output, and a composite video output. Built-in Wi-Fi and NFC support lets you use your smartphone or tablet to control the camera, as well as wirelessly transfer files to your mobile device for sharing and back up data on your computer.
A rechargeable lithium-ion battery pack, AC adapter, power cord, micro-HDMI cable, and a USB connection support cable come included. Also included is a lens hood, lens cap, and RMT-835 Remote Commander with battery. - 1" Exmor CMOS Sensor with Direct Pixel Readout
- The HDR-CX900 features Sony's first 1.0" Exmor R CMOS sensor. The back-illuminated technology improves low-light sensitivity and combines with Sony's Column A/D Conversion to reduce noise by 50%. This is great when shooting in dimly lit environments such as night landscapes or indoor scenes.
- 1080p Video and 20MP Still Images
- The 20-megapixel CMOS sensor allows you to capture cinematic 1080p video at 24, 30, and 60 fps, and high-quality 20MP still images.
- Versatile Shooting with XAVC S, AVCHD, and MP4 Codecs
- The HDR-CX900 records Full HD movies in the XAVC S format, which uses MPEG-4 AVC/H.264 codec for compression while saving files in a MP4 wrapper. The highly compressed files allow for longer record times. The camcorder also records in AVCHD, providing high-quality video for HDTV playback and Blu-ray disc burning. Additionally, the camcorder can shoot MP4 HD video, which is ideal for sharing over the internet at up to 28 Mb/s. Having the ability to switch between all three of three formats makes this camcorder a versatile tool content creation. For the greatest flexibility, you can even record AVCHD and MP4 formats simultaneously.
- Carl Zeiss Vario-Sonnar T* Lens with 12x Optical Zoom
- The HDR-CX900 comes equipped with a Carl Zeiss Vario-Sonnar T* lens. It features a wide 35mm-equivalent focal length of 29mm, making it suitable for capturing landscapes, as well as 12x optical zoom and 24x Clear Image zoom for getting close to the action.
- BIONZ X Processor Enables High-Speed 120 fps Recording
- The BIONZ X Image processor enables the camcorder to create more naturally vivid and lifelike images with higher resolutions. Detail reproduction technology optimally filters edges and textures different depending on the scene. It also features area-specific noise reduction which swiftly and efficiently analyzes the subject and reduces noise. The image processor also allows you to record at 120 fps at 1280 x 720 resolution for slow-motion playback at 1/5th the speed when played back at 24 fps after post-processing.
- Optical SteadyShot Image Stabilization with Active Mode
- Optical SteadyShot Image Stabilization with Intelligent Active Mode is an advanced optical Image stabilization technology that corrects camera shake to capture scenes with smoothness and stability. Intelligent Active Mode analyzes video frames and provides compensation with assistance from the BIONZ X image processing engine. Whether recording movies while walking or zooming, you can capture scenes with a higher level of stability.
- High-Contrast 0.39" OLED EVF
- The HDR-CX900 provides a high-contrast 0.39" OLED Tru-Finder EVF which reproduces rich color and deep blacks. The optical design of the EVF utilizes four dual-surface aspherical lenses, allowing for a 33° wide viewing angle that is clear from edge to edge of the viewfinder.
- Large 3.5" Xtra Fine LCD
- The 3.5" Xtra Fine LCD screen features a 16:9 aspect ratio and a 921K dot resolution, delivering sharp, bright, and vivid images. The large screen allows you to compose your shots more easily, even when outdoors.
- Simple Connectivity to Smartphones via Wi-Fi/NFC
- Built-in Wi-Fi/NFC support enables easy connectivity with smartphones for one-touch sharing and one-touch remote control. NFC (near field communication) provides "touch connection" convenience when transferring images to Android smartphones and tablets. You simply touch your NFC-compatible device to the camcorder to establish a connection.
- Multi Interface Accessory Shoe
- Expand photographic and movie shooting possibilities by attaching optional accessories via the Multi Interface Shoe. Attach an electronic viewfinder, external flash, stereo microphone, or even a compatible remote control via the Multi Interface terminal.
- Additional Features
-
- Built-in ND filters: Clear, 1/4, 1/16, 1/64
- Manual focus assist: magnified display, peaking, and tracking focus
- Built-in speaker (monaural)
- Premium Closer Voice
- My Voice Cancelling
- 7 picture effects for video and photos
- Low Lux mode
- Manual iris control
- Self-timer
- Red-eye reduction
- Black/white fader effects
- Face detection
- CinemaTone gamma/color
- NightShot infrared system
- Airplane mode
UPC: 027242877535 In the Box Sony HDR-CX900 Full HD Handycam Camcorder (Black) NP-FV50 V-Series Rechargeable Battery Pack (980mAh, 6.8-8.4V) abfersscaf AC-L200 AC Adapter for Handycam Using A/P/F-Series InfoLITHIUM Batteries Power Cord Micro-HDMI Cable USB Connection Support Cable RMT-835 Remote Commander CR2025 Battery for Remote Commander Lens Hood Lens Cap Limited 1-Year Warranty on Parts Limited 90-Day Warranty on Labor User Manual PDF 813.8kb More from Manufacturer Table of Contents
|
Upload User Manual
Have you got an user manual for the Sony HDR-CX900 Full HD Handycam Camcorder in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersSony HDR-CX900 Specs | | | Sensor | 1-Chip 1" CMOS | | Backside Illumination | Yes | | Color Filter | RGB | | Sensor Resolution | 20.92 MP | | Effective Pixels | 14.2 MP (16:9 Video) | | | | 35mm-Equivalent Focal Length | 29 to 348 | | Maximum Aperture | f/2.8 - f/4.5 | | Minimum Focusing Distance | 0.4" / 1.0 cm | | Zoom | Optical: 12x
Intelligent: 24x
Digital: 160x | | Filter Size | 62 mm | | Built-In ND Filters | Clear, 1/4, 1/16, 1/64 | | | | System | NTSC | | Recording Media | 1 x Memory Stick Pro Duo (Mark 2), Memory Stick XC-HG Duo, SD/SDHC/SDXC | | Video Format | 1920 x 1080p at 24/30/60 fps (50 Mb/s XAVC S)
1920 x 1080p at 60 fps (AVCHD)
1920 x 1080p at 24 fps (24 and 17 Mb/s AVCHD)
1920 x 1080i at 60 fps (24 and 17 Mb/s AVCHD)
1440 x 1080i at 60 fps (9 and 5 Mb/s AVCHD)
1280 x 720p at 30 fps (MP4) | | Aspect Ratio | 16:9
4:3 | | Still Image Resolution | JPEG: 20 Megapixel, 5024 x 2824 (16:9)
JPEG: 15 Megapixel, 4464 x 3352 (4:3) | | Channels | Stereo | | Audio Format | Dolby Digital 2ch
Dolby Digital 5.1 | | | | Display Type | LCD | | Touchscreen | Yes | | Screen Size | 3.5" | | Screen Resolution | 921,000 Dots | | Aspect Ratio | 16:9 | | Rotation | Opening Angle: 90°
Turning Angle: 270° | | | | Image Stabilization | Optical | | White Balance Modes | Auto
Indoor 1
Kelvin
Onepush
Outdoors | | Creative Effects | Yes | | Built-In Mic | Yes | | Built-In Speaker | Yes | | Wi-Fi | Yes, Wi-Fi 4 (802.11n) | | Accessory Shoe | 1 x Multi Interface Shoe | | Tripod Mount | 1/4" | | | | Inputs | 1 x 1/8" / 3.5 mm Stereo | | Outputs | 1 x Micro-HDMI (Type D)
1 x Composite Video
1 x USB 2.0
1 x Bravia Sync
1 x 1/8" / 3.5 mm Stereo | | Microphone Input | Yes | | Headphone Jack | Yes | | | | Supported Languages | Brazilian Portuguese
Canadian French
English
Spanish | | Battery | Rechargeable Lithium-Ion Battery Pack, 6.8-7.2 VDC, 1960 mAh | | Charging Method | AC Adapter
USB | | Power Adapter | 5.0 VDC | | Dimensions (W x H x D) | 3.2 x 3.3 x 7.7" / 8.1 x 8.4 x 19.6 cm with NP-FV50 battery | | Weight | 1.74 lb / .79 kg camcorder only
1.92 lb / .87 kg with NP-FV50 battery | | | | Package Weight | 3.325 lb | | Box Dimensions (LxWxH) | 9.55 x 6.6 x 5.45" |
