User Manual for Sony HKSP-105 Audio-Video Multiplexer Board Click to enlarge the picture
Contents of the user manual for the Sony HKSP-105 Audio-Video Multiplexer Board
- Product category: Embedders & De-Embedders Sony
- Brand: Sony
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Sony Embedders & De-Embedders
|
User manual for the Sony HKSP-105 Audio-Video Multiplexer Board contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Sony product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Sony user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Sony product will considerably shorten its lifespan!
|
Product description The HKSP-105 Audio-Video Multiplexer Board from Sony is designed to multiplex (4) AES/EBU digital audio signals (8 channels) with an HD SDI video signal. The unit provides (2) outputs of the multiplexed signal. An additional (4) signals and a total of (16) channels can be achieved by cascading (2) HKSP-105 boards.
The audio delay of this unit is adjustable up to a maximum of (2) video frames. Auto selection of HD multi-format is a standard feature. This unit also masks and retains HANC area and embedded audio data, transfers UMID and VITC data, and provides a simple signal generator. External reference input is provided as PFV-SP Series Signal Processing Unit. The board may be controlled through your system or remotely through an optional UCP-8060 Universal Control Panel (Ethernet 100BASE-TX). - AES/EBU Multiplexed with HD SDI Signal
- This board is designed to multiplex (4) AES/EBU digital audio signals (8 channels) with an HD SDI video signal.
- (2) Outputs
- The unit provides (2) outputs of the multiplexed signal.
- Expansion
- An additional (4) signals and a total of (16) channels can be achieved by cascading (2) HKSP-105 boards.
- Adjustable Audio Delay
- The audio delay of this unit is adjustable up to a maximum of (2) video frames.
- Control
- The board may be controlled through your system or remotely through an optional UCP-8060 Universal Control Panel (Ethernet 100BASE-TX).
In the Box Sony HKSP-105 Audio-Video Multiplexer Board Multiplexer Board 1 Year Parts, 90 Days Labor Table of Contents
|
Upload User Manual
Have you got an user manual for the Sony HKSP-105 Audio-Video Multiplexer Board in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersSony HKSP-105 Specs | Inputs | x1 HD SDI, BNC | | Outputs | x2 HD SDI, BNC | | Bandwidth | HD serial digital signal conforming to SMPTE291M/292M/299M, 1.4835 or 1.485 Gbs | | Impedance | 75Ω, unbalanced | | Return Loss | 15 dB or less (at 742.5 MHz) | | Power | Power Requirements: +12 VDC: less than 1.0A
Power Consumption: Approx. 12W | | Dimensions | Board (HxW): 4-1/2 x 15-3/8" (112.2 x 388.3mm)
Connector Panel (HxDxW): 5-1/8 x 6-1/8 x 7/8" (130 x 152.5 x 19mm) |
