Product description

Extending the NXCAM line of solid-state camcorders, Sony's HXR-NX5R offers improved network functionality over previous cameras in the line, and it allows you to select from XAVC-S 50 Mb/s to AVCHD/DV recording. Suitable for documentaries, corporate, weddings, events, nature, sports, and journalism, the NX5R shoots at NTSC broadcast frame rates from 59.94 to 23.98. The built-in Wi-Fi and FTP wireless connections enable you to send footage to your editor from the camera while on location, instead of having to send the media cards to the editor. The legacy codec support allows you to shoot and subsequently edit your footage into older projects shot on AVCHD or even DV formats. However, just because the NX5R supports older codecs doesn't make it any less capable. It incorporates a 3G-SDI output that supports Full HD 1920 x 1080p video at 59.94 fps, as well as 1080i, 720p, and the previously mentioned 720 x 480i.

Three 1/2.8" CMOS Exmor sensors and a 20x optical zoom Sony G lens with 40x Clear Image Zoom provide sharp and clear images. And if you need more illumination there is a built-in LED light above the lens. Professional audio is not forgotten with two XLR inputs that support Line, mic, and mic +48 (phantom power). The Slow & Quick Motion function enables 1080p recording at selectable frame rates. The camera features two media card slots that support recording on Memory Stick PRO Duo or SDHC/SDXC media cards.
    Built-In LED Light
  • Mounted above the lens and just below the built-in mic, the LED light features a roughly 90° beam angle, outputting a color temperature of about 5500K. It has an integrated dimmer and includes a snap-on diffuser to soften the output.
    Wi-Fi and FTP
  • Built-in Wi-Fi, NFC, and FTP allow you to send your footage to your editor while you are still shooting, so post-production doesn't have to wait on the data cards being sent from the shoot.
    XAVC S
  • The NX5R can record 1920 x 1080p footage at 59.94 fps using the XAVC S codec.
    AVCHD Format
  • The AVCHD format utilizes the MPEG-4, AVC/H.264 video codec, allowing users to record HD video footage onto random access media, such as Memory Stick PRO Duo and SDHC memory cards. The NX5R supports AVCHD and AVCHD 2.0
    G Lens
  • "G Lens", the lens featured in other successful Sony camcorders, already enjoys an excellent industry reputation. In the HXR-NX5R, this sophisticated lens is optimized to complement the camcorder's advanced image sensor and image processing technology.
    Built-In ND filters
  • The HXR-NX5R is equipped with three built-in ND (Neutral Density) filters—1/4, 1/16, 1/64—which help vary the depth of field with iris control.
    Relay Record with Dual Memory Slots
  • Another new feature is continuous recording between two memory card slots. The new HXR-NX5R camcorder automatically cycles between the dual memory slots. When using two 32GB memory cards, six hours of continuous HD footage can be recorded.
UPC: 027242902800 In the Box Sony HXR-NX5R NXCAM Professional Camcorder with Built-In LED Light
  • Battery Charger
  • Lens Cover with Hood
  • Large Eyecup
  • Shoe Cap
  • USB Cable
  • Video Light Diffuser
  • NP-F770 Battery
  • AC Adapter
  • AC Power Cord
  • Wireless Remote Commander (RMT-845)
  • CR2025 Battery (Pre-Installed in Remote)
  • Accessory Shoe Kit
  • Limited 1-Year Warranty
  • Table of Contents




    Upload User Manual

    Have you got an user manual for the Sony HXR-NX5R NXCAM Professional Camcorder with Built-In LED Light in electronic form? Please send it to us and help us expand our library of instruction manuals. Thank you, too, on behalf of other users.

    To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
    Upload PDF user manual Upload DOC user manual
    Please enter here the link to the user manual of this product:





    OR

    Enter here the file with the user manual of this product from your computer/phone:
    (60MB max; Permitted formats: PDF)

    0%


    Technical parameters

    Sony HXR-NX5R Specs

    Image Sensor 3-Chip 1/2.8" CMOS Sensor
    Sensor Resolution 2.07 MP
    Gain -6 to 30 dB
    Minimum Illumination 1.2 lux at 1/30 Shutter Speed
    Focal Length 4.1 to 82mm
    35mm Equivalent Focal Length 28.8 to 576mm
    Optical Zoom Ratio 20x
    Max Digital Zoom 40x
    Maximum Aperture f/1.6
    Minimum Aperture f/11
    Filter Size 72 mm
    Control Rings Focus
    Zoom
    Focus Control Autofocus
    Manual Focus
    Shutter Speed 1/3 to 1/10,000 sec
    Built-In ND Filter Mechanical Filter Wheel with 2 Stop (1/4), 3 Stop (1/8), 6 Stop (1/64) ND Filters
    Built-In Microphone Type Stereo
    Recording Media 1 x SDXC/Memory Stick PRO Duo Hybrid Card Slot
    1 x SDXC Card Slot
    Broadcast System Compatibility NTSC
    Recording Modes XAVC S 4:2:0 8-Bit:
    1920 x 1080p at 23.98/29.97/59.94 fps (50 Mb/s)
    AVCHD 4:2:0 8-Bit:
    1920 x 1080p at 23.98/29.97/59.94 fps (17 to 28 Mb/s)
    1920 x 1080i at 59.94 fps (17 to 24 Mb/s)
    DV:
    720 x 576i at 59.94 fps (25 Mb/s)
    Audio Recording 2-Channel
    IP Streaming FTP, FTPS, MPEG2, RTMP, UDP: 1920 x 1080
    Video Connectors 1 x BNC (3G-SDI) Output
    1 x HDMI Output
    1 x BNC (Composite) Output
    Audio Connectors 2 x 3-Pin XLR Input
    1 x 1/8" (3.5 mm) Stereo Headphone Output
    1 x 1/8" (3.5 mm) Stereo Output
    Other I/O 1 x 3.5 mm LANC Input
    1 x USB Micro-B Output
    Wireless Interfaces 2.4 GHz Wi-Fi Video Output, Audio Output
    Display Type LCD
    Screen Size 3.5"
    Screen Resolution 1,560,000 Dots
    EVF Display Type OLED
    Screen Size .39"
    EVF Resolution 1,440,000 Dots
    Battery Type Sony L-Series
    Power Connectors 1 x Barrel Input
    Power Consumption 7.8 W
    Operating Temperature 32 to 104°F / 0 to 40°C
    Storage Temperature -4 to 140°F / -20 to 60°C
    Accessory Mount 1 x Multi-Interface Shoe
    Tripod Mount 1/4"-20 Thread
    Built-In Light Yes
    Dimensions 15.3 x 7.9 x 7" / 38.86 x 20.07 x 17.78 cm
    Weight 4.7 lb / 2.1 kg
    Package Weight 9.7 lb
    Box Dimensions (LxWxH) 16.6 x 13.2 x 9.6"
