Product description The Sony MKE8020A MVS Interface Board is an optional accessory board for the MVE-8000A DME processor. When installed, it establishes communication from the MVE-8000A, through its MDR 68-pin interface, to the MVS-8000A multi-format switcher system. This board intrinsically meets the high demands of high profile video operations often required by broadcast studios, compositing suites, and digital mobile units. - Provides communication from the MVE-8000A to the MVS-8000A system via LVDS signal format
In the Box Sony MKE8020A MVS Interface Board Installation Manual 90-Day Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Sony MKE8020A MVS Interface Board in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersSony MKE8020A Specs | Type | Interface Board | | Compatibility | MVE-8000A Processor | | Connections | MDR 68-pin | | Dimensions (WxD) | 11 x 3.75" (278 x 94mm) | | Weight | 2.2 lbs (1kg) |
