Product description The Sony MVS7000X Multi-Format Production Switcher Processor is a flexible, easily upgradeable professional production switcher that can grow and expand as your business grows. In its standard configuration, the MSV7000 features twenty inputs, twenty four assignable outputs, and two power supplies. The MVS-7000X can be configured to meet user requirements with the minimal purchase of a mix/effect boards, and supports optional DME boards that support stereoscopic production and visual effects such as Spot Lighting and Texture Lighting without needing any external devices.
With the available BZS-7560X Switcher Upgrade Software it supports 1080p/59.94/50 production, which enables users to take full advantage of HD production with features such as transition and keyer. Other optional additions include the MKS-7470X DME Board Set and MKS-7471X DME Board with BZS-7560X/7561X for 3D program production. In the Box Sony MVS7000X Multi-Format Production Switcher Processor Limited 2-Year Parts & Labor (Depot Service) Table of Contents
|
Upload User Manual
Have you got an user manual for the Sony MVS7000X Multi-Format Production Switcher Processor in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersSony MVS-7000X Specs | Signal Processing | SMPTE424M/SMPTE292M/SMPTE259M-C | | Quantization | SD/HD-SDI: 10-bit | | Supported Formats | SD
NTSC/PAL
HD - Requires Optional Upgrades
1080i 50/59.94
1080p 50/59.94
1080PsF 23.976/24/25/29.97 | | Input | Standard Configuration
20 x BNC (primary inputs)
Max Configuration
80 x BNC (primary)
20 x for DME
Reference Input
2 x BNC 75 Ω with loop-through output. HD Tri-level sync or Analog black burst | | Output | Standard Configuration
24 x Assignable outputs
Maz Configuration
48 x BNC
20 x BNC (for DME)
4 x BNC (for Format Converter)
4 x BNC (for Multi Viewer) | | Frame Size | 1 to 5 M/E | | Control | Data LAN
1 x RJ-45, 100BASE-TX
Control LAN
1 x RJ-45, 100BASE-TX
FM Data
1 x RJ-45, 100BASE-TX
FM Device
2 x USB Type A, USB 2.0
GPI
D-sub 25-pin
8 x TTL level inputs
4 x Relay contact outputs
4 x Open collector outputs
Remote Control
D-sub 9-pin, RS-422A | | Power Requirement | 1.5 to 6.5 A | | Temperature | Operating
41 to 104°F (5 to 40°C)
Storage
-4 to 140°F (-20 to 60°C) | | Operating Humidity | 10 to 90% (Non-condensing) | | Dimensions (W x H x D) | 17.38 x 14 x 19.63" (44.15 x 35.56 x 49.86 cm) | | Weight | Not Specified |
