User Manual for Sony PXW-Z280 4K 3-CMOS 1 2" Sensor XDCAM Camcorder

Click to enlarge the picture
Sony PXW-Z280 4K 3-CMOS 1 2" Sensor XDCAM Camcorder Contents of the user manual for the Sony PXW-Z280 4K 3-CMOS 1 2"
  • Product category: Camcorders Sony
  • Brand: Sony
  • Description and content of package
  • Technical information and basic settings
  • Frequently asked questions – FAQ
  • Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
  • Authorized service for Sony Camcorders

Sony PXW-Z280 4K 3-CMOS 1 2" Sensor XDCAM Camcorder Sony PXW-Z280 4K 3-CMOS 1 2" Sensor XDCAM Camcorder Sony PXW-Z280 4K 3-CMOS 1 2" Sensor XDCAM Camcorder Sony PXW-Z280 4K 3-CMOS 1 2" Sensor XDCAM Camcorder
User manual for the Sony PXW-Z280 4K 3-CMOS 1 2" contain basic instructions that need to be followed during installation and operation. Before starting your appliance, the user manual should be read through carefully. Follow all the safety instructions and warnings, and be guided by the given recommendations. User manual is an integral part of any Sony product, and if it is sold or transferred, they should be handed over jointly with the product. Following the instructions for use is an essential prerequisite for protecting health and property during use, as well as recognition of liability on the part of the manufacturer for possible defects should you make a warranty claim. Download an official Sony user manual in which you will find instructions on how to install, use, maintain and service your product.

And do not forget – unsuitable use of a Sony product will considerably shorten its lifespan!



Product description

  • Sony PXW-Z280 - Hands-On Review
  • Sony| PXW-Z280 | Introduction Video
Sony's PXW-Z280 4K 3-CMOS 1/2" Sensor XDCAM Camcorder continues the fine tradition of the XDCAM series of cameras. It captures 4K at up to 60p relying on three 1/2" Exmor R sensors that provide improved low-light capability when compared to standard sensors. The camera integrates a 17x optical zoom lens and an electronic variable ND filter. The camera supports modern codecs such as XAVC, as well as legacy codecs such as MPEG HD and DVCAM, allowing you to use one camera to shoot 4K, HD, or SD video.

The camera supports S-Log 3 for improved performance, and HLG (Hybrid Log Gamma) which allows you to shoot and deliver footage compatible with both HDR (high dynamic range) and SDR (standard dynamic range) without needing laborious post-production work. You can record in both 4K and HD simultaneously, or output 4K 60p via the built-in 12G-SDI output. The camera features built-in 2.4 and 5 GHz Wi-Fi. UPC: 027242913783 In the Box Sony PXW-Z280 4K 3-CMOS 1/2" Sensor XDCAM Camcorder
  • Lens Hood (Pre-Installed)
  • EVF Eyecup
  • BP-U30 Lithium-Ion Battery
  • BC-U1A Battery Charger / AC Adapter for BP-U90, U60, U60T, U30
  • Power Cord
  • USB Cable
  • Shoulder Strap
  • Limited 1-Year Warranty Parts
  • Limited 90-Day Warranty Labor
  • User Manual PDF 2.5mb Table of Contents




    Upload User Manual

    Have you got an user manual for the Sony PXW-Z280 4K 3-CMOS 1 2" Sensor XDCAM Camcorder in electronic form? Please send it to us and help us expand our library of instruction manuals. Thank you, too, on behalf of other users.

    To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
    Upload PDF user manual Upload DOC user manual
    Please enter here the link to the user manual of this product:





    OR

    Enter here the file with the user manual of this product from your computer/phone:
    (60MB max; Permitted formats: PDF)

    0%


    Technical parameters

    Sony PXW-Z280 Specs

    Image Sensor 3-Chip 1/2" CMOS Sensor
    Effective Sensor Resolution 3840 x 2160
    Signal-to-Noise Ratio 63 dB
    Minimum Illumination 0.0013 lux
    Focal Length 5.6 to 95.2mm
    35mm Equivalent Focal Length 30.3 to 515mm
    Optical Zoom Ratio 17x
    Maximum Aperture f/1.9
    Minimum Aperture f/16
    Filter Size 77 mm
    Control Rings Focus
    Zoom
    Iris
    Image Stabilization Optical
    Focus Control Autofocus
    Manual Focus
    Shutter Speed 1/24 to 1/8000 sec
    Built-In ND Filter Mechanical Filter Wheel with Clear, 2 Stop (1/4), 4 Stop (1/16), 6 Stop (1/64) ND Filters and a 2 to 7 Stop Electronic ND Filter
    Built-In Microphone Type Stereo
    Recording Media 2 x SxS Card Slots
    Broadcast System Compatibility NTSC, PAL
    Recording Modes XAVC-I:
    3840 x 2160p at 23.98/25/29.97/50/59.94 fps (600 Mb/s)
    1920 x 1080p at 23.98/25/29.97/50/59.94 fps (222 Mb/s)
    1920 x 1080i at 50/59.94 fps (222 Mb/s)
    1280 x 720p at 50/59.94 fps (222 Mb/s)
    XAVC-L:
    3840 x 2160p at 23.98/25/29.97/50/59.94 fps (150 Mb/s)
    1920 x 2160p at 23.98/25/29.97/59.94 fps (50 Mb/s)
    1920 x 1080i at 50/59.94 fps (50 Mb/s)
    1280 x 720p at 50/59.94 fps (50 Mb/s)
    XAVC-L:
    1920 x 1080p at 23.98/25/29.97/50/59.94 fps (35 Mb/s)
    1920 x 1080i at 50/59.94 fps (35 Mb/s)
    1920 x 1080i at 50/59.94 fps (25 Mb/s)
    MPEG2 4:2:2:
    1920 x 1080p at 23.98/25/29.97 fps (50 Mb/s)
    1920 x 1080i at 50/59.94 fps (50 Mb/s)
    1280 x 720p at 23.98/25/29.97/50/59.94 fps (50 Mb/s)
    MPEG2 4:2:0:
    1920 x 1080p at 23.98/25/29.97 fps (35 Mb/s)
    1920 x 1080i at 50/59.94 fps (35 Mb/s)
    1440 x 1080p at 23.98/25/29.97 fps (35 Mb/s)
    1440 x 1080i at 50/59.94 fps (35 Mb/s)
    1280 x 1080p at 50/59.94 fps (35 Mb/s)
    DV 4:2:0 8-Bit:
    720 x 576i at 50 fps (25 Mb/s)
    720 x 576PsF at 50 fps (25 Mb/s)
    720 x 480i at 59.94 fps (25 Mb/s)
    720 x 480PsF at 59.94 fps (25 Mb/s)
    Variable Frame Rates 1 to 60 fps
    Audio Recording XAVC: 4-Channel 24-Bit 48 kHz LPCM Audio
    Video Connectors 1 x BNC (Component) Output
    1 x BNC (12G-SDI) Output
    1 x HDMI Output
    Audio Connectors 2 x 3-Pin XLR Mic Level Input
    1 x 1/8" (3.5 mm) Stereo Headphone Output
    Other I/O 1 x BNC Timecode Input
    1 x BNC Timecode Output
    1 x BNC Genlock Input
    1 x 2.5 mm LANC Control
    1 x USB Micro-B Data
    1 x USB Type-A
    1 x USB Type-C
    1 x RJ45 LAN Data
    Wireless Interfaces 2.4 GHz, 5 GHz Wi-Fi, NFC
    Global Positioning GPS
    Display Type LCD
    Screen Size 3.5"
    Screen Resolution 1,560,000 Dots
    Screen Size .5"
    EVF Resolution 2,360,000 Dots
    Battery Type Sony BP-U Series
    Accessory Mount 1 x Multi-Interface Shoe
    Dimensions 7.02 x 7.95 x 16.78" / 178.4 x 202 x 426.3 mm (With Protrusions)
    Weight 6.6 lb / 3 kg
    Package Weight 11.5 lb
    Box Dimensions (LxWxH) 20.5 x 11.0 x 10.0"

    Rating

    66% users recommend this product to others. And what about you?
    Rating: 3.3 of 5

    This product has already been rated by 76 owners. Add your rating and experience with the product.

    Discussion

    Discussion Ask our technicians if you have a problem with your settings, or if anything is unclear in the user manual you have downloaded. You can make use of our moderated discussion. The discussion is public and helps other users of our website who may be encountering similar problems.

    Post new comment to Sony PXW-Z280 4K 3-CMOS 1 2" Sensor XDCAM Camcorder

    Subject: NTSC/PAL
    Date: 14.11.2022 06:07:49Name: Tobias Openshaw
    NVM I was looking for a "Region" setting but I see the frame rate settings are all there.
    Post reply

    Subject: How to change NTSC/PAL?
    Date: 14.11.2022 01:49:00Name: Tobias Openshaw
    For the life of me I can't figure out how to escape PAL-land. Help!
    Post reply

    Subject: Zoom control on camera
    Date: 14.11.2022 01:47:44Name: Tobias Openshaw
    On the right hand side, towards the back, there is a little flap that says "Remote". Open it and plug your remote zoom in there.
    Post reply

    Subject: Sony PXW-Z280
    Date: 28.09.2022 14:24:30Name: Victor
    Hi,
    How to control zoom on this camera using tripod and zoom stick on the handle?
    Where is located zoom control on the camera?
    Regards,
    Victor
    Post reply

    Subject: Sony PXW-Z280 zoom control by zoom stick on handle, when camera is on the tripod
    Date: 28.09.2022 14:22:45Name: Victor
    Hi,
    How to control zoom on this camera using tripod and zoom stick on the handle?
    Where is located zoom control on the camera?
    Regards,
    Victor
    Post reply
