Product description Providing you with 12 analog inputs and the ability to record up to 16 inputs to SD and CompactFlash cards, the 688 12-Input Field Production Mixer and 16-Track Recorder from Sound Devices boasts a streamlined design with flexible routing and the company's MixAssist auto-mix system. Input comes in the form of 6 high-bandwidth mic/line inputs on XLR connectors and 6 line inputs on TA3 connectors, in addition to 2 AES42/AES3 digital inputs.
The 688 can record up to 16 tracks of your audio as mono- or polyphonic broadcast WAV files, supporting sample rates up to 192 kHz on up to 6 tracks. With its dual memory card recording, you can set up redundant recording or combinations of WAV and MP3 files. The recorder is compatible with both the SL-6 power distribution and 6-channel wireless system, and the CL-6 input controller. - I/O
- The 688 has six high-bandwidth mic/line inputs on XLR connectors, each complete with phantom power, high-pass filter, analog input limiter and variable pan. Six additional line-level inputs on TA3 connectors offer flexibility for more complex productions.
- Routing Flexibility
- All inputs are assignable, pre- or post-fade to its eight output buses, left/right plus Aux 1-6. The 688 can send its main left/right mix to three cameras simultaneously via transformer-balanced XLR and Hirose outputs
- Mix Assist
- The 688's digital processing engine delivers 12-channel auto-mixing capability using a proprietary algorithm. MixAssist automatically attenuates the level of inputs that are not active and helps maintain consistent background sound levels regardless of the number of open microphones. Comb filtering and phasing artifacts are also reduced when multiple mics pick up the same sound source by intelligently attenuating redundant mics
- Recording
- The 688 offers 16-track, polyphonic or monophonic broadcast WAV file recording to SD and CompactFlash cards. All common sampling rates are supported, including 192 kHz on up to six tracks. The memory cards can be set independently, recording either identical material for real-time backup, or combinations of WAV and MP3 files
- PowerSafe
- The 688 incorporates exclusive PowerSafe circuitry with smart sensing of available power sources, front panel warning indication of power loss, and an integrated 10-second power reserve that will, in the event of an inadvertent power loss, allow the 688 to safely stop recording, properly end all file operations, and then automatically shut down
- QuickBoot
- Power on and start recording in less than two seconds. You never have to wait on sound
- Timecode and Metadata
- The 688 features an Ambient timecode generator and reader supporting all common rates and modes. A time code compare utility shows the difference between internal and external timecode. The 688 also generates sound reports and supports extensive metadata, via the front panel or attached USB keyboard
-
- 16-track recording to SD & CompactFlash cards; Timecode-stamped WAV & MP3 files
- Eight output buses: L/R mix plus Aux 1-6; transformer-balanced XLR & Hirose outs for freedom from ground loops Two AES42/AES3 inputs, eight AES3 outputs
- Direct menu control of SuperSlot-compatible wireless (with optional SL-6)
- Supports all sample rates up to 192 kHz
- Adjustable input & output delay
- Three camera returns & dedicated COM return
- Internal & external slate mic inputs
- Ambient TC generator and reader and internal TC backup battery
- Easy to navigate interface, 1000-nit LCD visible in all light conditions, configurable metering
- USB Keyboard for metadata entry
- User-configurable headphone presets
- Lightweight, durable carbon-fiber chassis
- Powered by AA-battery, external DC or NP1 via optional SL-6
UPC: 859108005178 In the Box Sound Devices 688 12-Input Field Production Mixer and 16-Track Recorder Limited 2-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Sound Devices 688 12-Input Field Production Mixer and 16-Track Recorder in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersSound Devices 688 Specs | Inputs | 6x XLR mic/line inputs
6x TA3 line inputs
2x AES42/AES3 inputs | | Outputs | 2x XLR mix outputs (L, R)
2x Hirose outputs
6x TA3 auxiliary outputs
2x AES3 digital outputs | | Sample Rate | Supports all sample rates up to 192 kHz | | Power | 5x AA batteries
External DC or NP1 via SL-6 | | | | Package Weight | 7.1 lb | | Box Dimensions (LxWxH) | 16.0 x 11.2 x 5.2" |
