Product description The Notepad-5 from Soundcraft is a small-format, 5-channel analog mixing console with an integrated 2x2 USB audio interface, well suited for music production, podcasts, video production, interviews, rehearsals, writing sessions, and mobile events. The mixer combines professional-grade analog components such as a microphone preamp with a combo XLR-1/4" input, 2-band EQ, and a 100 Hz high-pass filter. Additionally, input 1 offers a Hi-Z instrument input for incorporating guitars and other high-impedance instruments.
Channels 1-3 include gain/trim controls, a monitor send, and level controls. Channels 2/3 utilize 1/4" line-level inputs, while channels 4/5 include stereo RCA inputs. Outputs include Master L/R on XLR, a 1/4" monitor send, and a dedicated 1/4" monitor output button to select between mono line output or stereo headphone output. The master section offers a master control knob and four LED meters with -20, 0, +6 dB, and peak settings. The Notepad-5 features a durable metal enclosure and ships with an external power supply. -
- Soundcraft-quality sound from the professional microphone preamp
- Easily record, edit, and play back from your Mac or Windows computer with an integrated USB audio interface. Simply plug-and-play with your Mac (Windows computers require Soundcraft driver installation)
- Getting a great mix is easy with a familiar channel-strip layout that includes EQ, monitor send, master level, and rotary headphone-volume control
- Durable metal enclosure that’s built to last
UPC: 668705003018 In the Box Soundcraft Notepad-5 Small-Format Analog Mixing Console with USB I/O External Power Supply Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Soundcraft Notepad-5 Small-Format Analog Mixing Console with USB I O in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersSoundcraft NOTEPAD-5 Specs | Inputs | Mic/Line (Channel 1): 1 x combo XLR-1/4" / 6.35 mm
Line (Channels 2/3): 2 x 1/4" / 6.35 mm
Line (Channels 4/5): 2 x RCA | | Outputs | Master (L/R): 2 x XLR
Monitor: 1 x 1/4" / 6.35 mm
| | Controls | Gain (Channel 1): 1 x Gain knob
Trim (Channels 2/3): 1 x Trim knob
Monitor Send (Channels 1, 2/3, 4/5): 3 x Monitor send knobs
Level (Channel 1, 2/3, 4/5)): 3 x Level knobs
Master Level: 1 x knob
Monitor Master: 1 x Monitor master knob
Output Type: Button for mono line out or stereo headphones
| | EQ Controls | 2-Band EQ (Channel 1)
HF: ±12 at 12 kHz
LF: ±12 at 80 Hz | | Indicator LEDs | Meters: 4 x LED (-20, 0, +6 dB, Peak) | | Dimensions | Not specified by manufacturer | | Weight | Not specified by manufacturer | | | | Package Weight | 2.35 lb | | Box Dimensions (LxWxH) | 10.3 x 9.0 x 3.5" |
