User Manual for Speco Technologies Contractor Series 60W RMS Public Address Power Mixer Amplifier Click to enlarge the picture
Contents of the user manual for the Speco Technologies Contractor Series 60W RMS
- Product category: Mixer/Amplifiers Speco Technologies
- Brand: Speco Technologies
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Speco Technologies Mixer/Amplifiers
|
User manual for the Speco Technologies Contractor Series 60W RMS contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Speco Technologies product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Speco Technologies user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Speco Technologies product will considerably shorten its lifespan!
|
Product description The UL listed Contractor Series Public Address Power Mixer Amplifier from Speco Technologies is designed for long-running, every day use. It can stand on its own to run a smaller installation, or can be incorporated into a much larger job. With RMS power of 60W, the amplifier is suitable for microphone and source-mixing ability, telephone paging interface, music-on-hold capability, and more. UPC: 030519275651 In the Box Speco Technologies Contractor Series 60W RMS Public Address Power Mixer Amplifier Limited 5-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Speco Technologies Contractor Series 60W RMS Public Address Power Mixer Amplifier in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersSpeco Technologies PMM60A Specs | Output Power | RMS: 60 W
Maximum: 90 W | | Power Consumption | 670 W | | Power Supply | 120 VAC, 50/60 Hz | | Zones | 1 | | Output | Speaker: 4/8/16 Ohms, 70/25 V
Other: Tape (RCA), Booster (RCA), Pre-Amp (RCA) | | Inputs | 3 x Mic (XLR)
1 x Mic (XLR or Terminal)
3 x Mic/Aux (Terminal or Stereo RCA)
1 x EQ/Mix (RCA)
1 x TEL (Terminal) | | Frequency Response | 50 Hz to 15 kHz (±3 dB) | | Tone Control | Bass: ±10 dB
Treble: ±10 dB | | THD | Less than 1% @ 1 kHz | | S/N Ratio | Microphone: >60 dB
TEL: >60 dB
Line: >70 dB | | Controls | Volume for each source, Master Volume, Vox Sensitivity, TEL Input Level, MoH Volume, Tone | | Telephone Interface | TEL in and MoH Out | | Indicators | Power, power level | | Listings | UL, cUL, CE, FCC | | Dimensions | 16.9 x 3.5 x 11.8" (42.9 x 8.9 x 29.9 cm) | | Weight | 19 lb (8.6 kg) |
