User Manual for Speco Technologies CVC620WPT 2MP Outdoor HD-TVI Bullet Camera Click to enlarge the picture
Contents of the user manual for the Speco Technologies CVC620WPT 2MP Outdoor HD-TVI
- Product category: Wired Analog & HD Cameras Speco Technologies
- Brand: Speco Technologies
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Speco Technologies Wired Analog & HD Cameras
|
User manual for the Speco Technologies CVC620WPT 2MP Outdoor HD-TVI contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Speco Technologies product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Speco Technologies user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Speco Technologies product will considerably shorten its lifespan!
|
Product description Capture surveillance video with the CVC620WPT 2MP Outdoor HD-TVI Bullet Camera from Speco Technologies. This camera features a 1/3" progressive scan Sony CMOS sensor and a 3.6mm fixed lens to capture 1920 x 1080 resolution video at up to 30 fps over coax. The UTC (Up-the-Coax) connection allows for OSD control of the camera. The IP67-rated weather-resistant enclosure makes the camera suitable for outdoor use. A 30' power/video cable is included, along with a mounting bracket and screws. - Privacy masking enables you to select up to 4 areas you don't want recorded
- Motion detection with sensitivity control for up to 4 definable areas
- Smart IR, D-WDR (wide dynamic range), backlight compensation, 2D-DNR, 3D-DNR, and defog help improve image quality and visibility
- Up to 1600' signal range depending on coax quality
- Auto and manual white balance
- Full OSD operation through UTC (Up-the-Coax) connection
- IP67-rated weather-resistant enclosure that is suitable for outdoor use
UPC: 030519022880 In the Box Speco Technologies CVC620WPT 2MP Outdoor HD-TVI Bullet Camera 3 x Mounting Screws Mounting Bracket 30' (9.1 m) Power/Video Cable Limited 5-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Speco Technologies CVC620WPT 2MP Outdoor HD-TVI Bullet Camera in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersSpeco Technologies CVC620WPT Specs | Image Sensor | 2 MP 1/3" CMOS | | Scanning System | Progressive | | Lens Type | 3.6mm fixed | | Resolution | 1920 x 1080 at 30 fps | | Video Output | 1.0 V p-p, 75 Ohms | | Effective Pixels (H x V) | 1984 x 1105 | | Total Pixels (H x V) | 2000 x 1121 | | Minimum Illumination | 0.001 lux | | AGC (Automatic Gain Control) | Yes | | Digital Wide Dynamic (D-WDR) | Yes | | Defog | Auto, off | | Backlight Compensation | Off, BLC, HSBLC | | White Balance | Auto, manual | | Day/Night | Auto, color, B&W, external | | Smart IR | Yes | | Digital Noise Reduction (DNR) | 2D-DNR, 3D-DNR | | Motion Detection | 4 definable areas with sensitivity control | | Privacy Masking | Up to 4 areas | | Dead Pixel Cancellation (DPC) | Yes | | S/N Ratio | More than 50 dB | | Electronic Shutter | Auto/manual (1/30 to 1/30,000 sec) | | Synchronization | Internal | | TV System | NTSC | | Operating Temperature | -20 to 120°F (-28.9 to 48.9°C) | | Test Monitor Output | CVBS (BNC out in yellow) | | Communication | UTC (Up-the-Coax)
Signal Distance: Up to 1600' (487.7 m)
| | IP Rating | IP67 | | Certifications | FCC, RoHS | | Power Supply | 12 VDC (power supply not included) | | Dimensions (Diameter x Height x Length) | 1.34 x 3.5 x 2.52" (34 x 89 x 64 mm) | | Weight | 10 oz (283.5 g) | | | | Package Weight | 1.57 lb | | Box Dimensions (LxWxH) | 9.15 x 4.1 x 3.2" |
Rating70% users recommend this product to others. And what about you?
This product has already been rated by 58 owners. Add your rating and experience with the product.
