User Manual for Speco Technologies Intensifier T HTINT40T 2MP HD-TVI Mini Board Camera with 3.6mm Lens Click to enlarge the picture
Contents of the user manual for the Speco Technologies Intensifier T HTINT40T 2MP
- Product category: Wired Analog & HD Cameras Speco Technologies
- Brand: Speco Technologies
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Speco Technologies Wired Analog & HD Cameras
|
User manual for the Speco Technologies Intensifier T HTINT40T 2MP contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Speco Technologies product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Speco Technologies user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Speco Technologies product will considerably shorten its lifespan!
|
Product description The black HTINT40T from Speco Technologies uses a progressive scan Sony CMOS sensor and a 3.6mm fixed lens to transmit 1920 x 1080 resolution video at 30 fps. An IR cut filter enables day and night functionality. Intensifier technology enables this board camera to produce clear images in low-light conditions. The camera supports an HD-TVI signal output. UTC (Up-the-Coax) and onboard controls allow for full OSD operation of the camera. - Intensifier technology enables the camera to produce clear images in varying lighting conditions
- Presets for different lighting scenarios
- 12 VDC power (power supply available separately)
- Full OSD operation via UTC or onboard control
- Analog output for 960H resolution
- Day and night functionality
- Amplifies existing light with no distance limitation
- White balance modes include auto, auto ext, AWC-set, and manual
- Adjustable brightness, automatic gain control, and sharpness
- Lens shading compensation
- Motion detection for up to 4 zones
- Privacy masking for up to 16 areas
- Mirror and vertical flip support
UPC: 030519021616 In the Box Speco Technologies Intensifier T HTINT40T 2MP HD-TVI Mini Board Camera with 3.6mm Lens Video Test Connector Power Jack 2 x Tapping Screws (M3 x 10mm) 2 x Machine Screws (M2 x 3mm) Limited 5-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Speco Technologies Intensifier T HTINT40T 2MP HD-TVI Mini Board Camera with 3.6mm Lens in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersSpeco Technologies HTINT40T Specs | Image Sensor | Sony progressive scan CMOS sensor | | Effective Pixels (H x V) | 1985 x 1105 | | Total Pixels (H x V) | 2001 x 1121 | | Resolution | 1920 x 1080 at 30 fps | | TV System | NTSC | | S/N Ratio | >50 dB | | Frame Rate | Up to 50/60 fps | | Video Output | HD-TVI and additional 960H analog output
1.0 V p-p, 75 Ohms | | Lens Type | Manual | | Focal Length | 3.6mm | | Electronic Shutter Speed | 1/60,000 to 1/60 seconds (auto, manual), flicker | | Wide Dynamic Range | On (low, middle, high), off | | Digital WDR | On (low, middle, high), off | | Day/Night | Color, B&W, auto, ext | | OSD Control | Full OSD operation via UTC and onboard control | | White Balance | Auto, auto ext, AWC-set, manual | | Brightness | 0 to 20 (level adjustable) | | AGC (Automatic Gain Control) | 0 to 20 (level adjustable) | | Sense-Up | 2-32x | | Motion Tracking | On, off | | Motion Detection | On, off (4 zones) | | Privacy Masking | On, off (16 zones) | | Flip/Mirror | Mirror and vertical flip (on, off) | | Sharpness | 0 to 20 (level adjustable) | | Lens Shading Compensation | On, off | | 3D-DNR | Off, low, middle, high | | Defog | On (auto, manual), off | | DIS | On, off | | Power Supply | 12 VDC (available separately) | | Power Consumption | 12 VDC, 100 mA | | Operating Temperature | -4 to 140°F / -20 to 60°C | | Dimensions | 1.34 x 1.34 x 1.2" / 34 x 34 x 30.4 mm | | Weight | 10.6 oz / 300.5 g | | | | Package Weight | 0.355 lb | | Box Dimensions (LxWxH) | 4.1 x 2.85 x 2.2" |
