User Manual for Spypoint Force-11D Trail Camera Click to enlarge the picture
Contents of the user manual for the Spypoint Force-11D Trail Camera
- Product category: Trail/Wildlife Cameras Spypoint
- Brand: Spypoint
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Spypoint Trail/Wildlife Cameras
 |
User manual for the Spypoint Force-11D Trail Camera contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Spypoint product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Spypoint user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Spypoint product will considerably shorten its lifespan!
|
Product description Capture 11MP photos and 720p video with sound of wildlife and people with the Force-11D Trail Camera, featuring a motion detection range that can be set between 5 and 80 feet. You can view and manage your images and videos on the camera's 2" screen. The Force-11D's trigger speed is a quick 0.07 seconds. Its 42-LED, low-glow infrared flash has a 100' range but won't spook game. The motion sensor uses five detection zones and can trigger up to six images per detection. You can also use the timelapse mode, with intervals from 30 seconds to one hour, for big-picture observation. Your still images will have a time stamp with useful information including date, time, temperature, and moon phase. Your images will be captured on a user-supplied SD/SDHC memory card up to 32GB, and the cam works with MySpypoint.com, a free online photo management portal that lets you sort, access, and share your images. The camera runs on six user-provided AA batteries, or on Spypoint's separately sold rechargeable lithium power pack or other 12 volt source. It comes with a tree mounting bracket and strap, and is equipped with a standard 1/4"-20 tripod mount. - Photo and Video Resolution
-
- Maximum Still Image Resolution: 11MP
- Format: JPEG
- Video: 1280 x 720p
- Format: AVI
- Optical field of view: 40°
- Operating Modes
-
- Photo: Up to six images per detection
- Instant mode for trail or security use
- Delay for feeder observation: Instant/10s/1m/3m/5m/10m/15m/30m
- Timelapse: Intervals 30s/1m/3m/5m/15m/30m/1h
- Video: Duration 10s/30s/60s/90s
- Same delay options as Photo mode
- Photo first option
- Motion Sensor
-
- Passive infrared motion sensor
- Detection Range: 5-80'
- Trigger Speed: 0.07
- Multi-Shot Mode: Camera captures up to 6 images per trigger event
- Flash
-
- Built-in, infrared flash with 42 LEDs and a 100' range for covert nighttime illumination
- Setup, Display, and Options
-
- View and manage images & videos on 2" screen
- Memory
-
- Records photos and videos to user-supplied SD/SDHC memory cards up to 32GB
- Power
-
- Runs on 6 user-supplied AA batteries
- Optional rechargeable lithium battery pack
- Can also operate on 12 VDC external power supply
- Mounting
-
- Tree mounting bracket & strap
- Standard 1/4"-20 threaded hole
- Hole for security cable
- Durability
-
- Rugged, weatherproof housing protects camera from the elements over extended periods of outdoor use
UPC: 887157016029 In the Box Spypoint Force-11D Trail Camera (Camo) Mounting Bracket Mounting Strap Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Spypoint Force-11D Trail Camera in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersSpypoint FORCE-11D Specs | Camera Type | Surveillance/Time Lapse/Trail/Wildlife | | | | Image Resolution | 11 MP | | Image File Format | JPEG | | Built-In Flash | 42 x Black Low-Glow 850 nm Wavelength IR LEDs | | Effective Flash Range | 100' / 30.5 m | | Time/Date Stamp | Yes | | | | Sensor Type | Passive Infrared (PIR) | | Detection Range | 5 to 80' / 1.5 to 24.4 m | | Trigger Speed | 0.1 Seconds | | | | Burst Capability | 6 Images per Trigger | | | | Video Recording | Yes | | File Format | AVI | | Video Format | 1280 x 720p | | | | Memory Card Type | SDHC (Up to 32 GB) | | Battery Type | 1 x Rechargeable (Not Included)
6 x AA (Not Included) | | External Power Source Capable | Yes, 12 VDC (Not Included) | | Display | Yes, 2" / 5.1 cm | | Security | Holed for Locking | | Mounting | 1/4"-20 Female
Mounting Strap (Included) | | Dimensions | 5 x 3.8 x 3.2" / 12.7 x 9.7 x 8.1 cm | | | | Package Weight | 1.115 lb | | Box Dimensions (LxWxH) | 8.75 x 5.85 x 4.0" |
