User Manual for Starlight Xpress USB Filter Wheel with 7-Position 1.25" Eyepiece Filter Carousel

Click to enlarge the picture
Starlight Xpress USB Filter Wheel with 7-Position 1.25" Eyepiece Filter Carousel Contents of the user manual for the Starlight Xpress USB Filter Wheel with
  • Product category: Astrophotography Starlight Xpress
  • Brand: Starlight Xpress
  • Description and content of package
  • Technical information and basic settings
  • Frequently asked questions – FAQ
  • Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
  • Authorized service for Starlight Xpress Astrophotography

User manual for the Starlight Xpress USB Filter Wheel with contain basic instructions that need to be followed during installation and operation. Before starting your appliance, the user manual should be read through carefully. Follow all the safety instructions and warnings, and be guided by the given recommendations. User manual is an integral part of any Starlight Xpress product, and if it is sold or transferred, they should be handed over jointly with the product. Following the instructions for use is an essential prerequisite for protecting health and property during use, as well as recognition of liability on the part of the manufacturer for possible defects should you make a warranty claim. Download an official Starlight Xpress user manual in which you will find instructions on how to install, use, maintain and service your product.

And do not forget – unsuitable use of a Starlight Xpress product will considerably shorten its lifespan!

Product description

Take your astrophotography and astronomy to the next level with the Starlight Xpress USB Filter Wheel. This configuration of the wheel features a 7-position carousel that accepts conventional 1.25" eyepiece filters, so many users who are new to wheels will be able to use the filters they already have, including planetary, neutral density, light pollution, or specialty filters like nebula. This wheel is configured with a front female Schmidt-Cassegrain telescope (SCT) mount adapter so it can be securely attached to your telescope without the need for additional adapters so the back focus distance is minimized. On the rear of the wheel is a standard male T2 mount for attaching your photo gear.Sub-miniature DC gear drives make quiet and vibration-free filter changes and each position is programmable within the control software that is available as a free download from the SX website. The wheel is also compatible with many popular third-party astronomy and imaging software such as AstroArt and MaximDL. The wheel is connected to a computer via a USB 2.0 port for software control and conveniently is powered by the USB cable. For those who don't want to or can't tether the wheel to a computer, there is an optional handbox control unit and independent power supply. Additionally, a standard serial port allows another computer control option, but power is not supplied, so a separate power supply will be needed.If your rig or need changes, the front and rear adapters can be swapped for other optional mounting adapters and the carousel can be switched out for others that are available separately that accept different size filters—eliminating the need to purchase an entirely new wheel. This is just the filter wheel and carousel; you need to provide the filters of your own choosing. In the Box Starlight Xpress USB Filter Wheel with 7-Position 1.25" Eyepiece Filter Carousel (Female SCT/Male T-Mount)
  • 7-Position USB Filter Wheel Carousel (1.25" Eyepiece Filter Threads)
  • Female SCT Adapter for SXV Filter Wheel
  • Male T-Thread Adapter for SXV Filter Wheel
  • 10' USB 2.0 Cable
  • Limited 1-Year Warranty
