User Manual for StarTech USB 3.0 to Gigabit Ethernet NIC Network Adapter Click to enlarge the picture
Contents of the user manual for the StarTech USB 3.0 to Gigabit Ethernet
- Product category: Network Interface Cards & Adapters StarTech
- Brand: StarTech
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for StarTech Network Interface Cards & Adapters
 |
User manual for the StarTech USB 3.0 to Gigabit Ethernet contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any StarTech product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official StarTech user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a StarTech product will considerably shorten its lifespan!
|
Product description The white USB 3.0 to Gigabit Ethernet NIC Network Adapter from StarTech adds a single RJ-45 Ethernet port to a USB-enabled computer system, with support for Gigabit network connections at full bandwidth when used with a USB 3.0 host connection, unlike USB 2.0 adapters. This compact adapter is backwards compatible with older USB 2.0/1.x computer systems (speed limited by USB bus), making it a suitable portable replacement network adapter or laptop accessory. In addition, with support for features such as Jumbo Frames, VLAN tagging and Wake on LAN (WOL), the adapter offers versatile Gigabit network performance for home and business users alike. - Full Gigabit bandwidth support, through a USB 3.0 host connection
- Compact, portable, and lightweight design, with no need for an external power adapter
- Added flexibility near the RJ-45 port through dongle-style design
- IEEE 802.3, 802.3u and 802.3ab (10BASE-T, 100BASE-TX, and 1000BASE-T) compatible
- Crossover Detection and Auto-Correction (Auto MDIX)
- IEEE 802.1Q VLAN tagging support
- Supports Checksum Offload (IPv4, IPv6, TCP, UDP) and Large Send Offload
- Add Gigabit Ethernet capabilities to a desktop or laptop
- Replace a failed integrated network adapter with an external, USB Gigabit Ethernet connection, instead of having to open a desktop or laptop computer case
- Activity and Link LED indicators
UPC: 065030849906 In the Box StarTech USB 3.0 to Gigabit Ethernet NIC Network Adapter (White) Driver CD Limited 2-Year Warranty Brochure PDF 140.3kb More from Manufacturer Table of Contents
|
Upload User Manual
Have you got an user manual for the StarTech USB 3.0 to Gigabit Ethernet NIC Network Adapter in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersStarTech USB31000SW Specs | | | Ports | 1 | | Interface | RJ-45 (Gigabit Ethernet) | | Bus Type | USB 3.0 | | Industry Standards | IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, and IEEE 802.3az | | Chipset ID | ASIX AX88179 | | | | External Ports | 1 x RJ-45 female
1 x USB 3.0 A (9-pin, SuperSpeed) male | | | | Maximum Distance | 330' (100 m) | | Type and Rate | USB 3.0 (5 Gb/s) | | Compatible Networks | 10/100/1000 Mb/s | | Auto MDIX | Yes | | Full Duplex Support | Yes | | | | OS Compatibility | Windows 8.1 (32/64-bit)/8 (32/64-bit)/7 (32/64-bit)/Vista (32/64-bit)/XP (32/64-bit)/Server 2012/2008 R2/2003 (32/64-bit)
Mac OS 10.6 - 10.9
Linux Kernel 2.6.25 - 3.5.0 | | | | LED Indicators | 1 x Activity (yellow)
1 x Link (green) | | | | System Requirement | Available USB port | | | | Operating Temperature | 32 to 104°F (0 to 40°C) | | Storage Temperature | -4 to +140°F (-20 to +60°C) | | Relative Humidity | <80% | | | | Certifications | CE, FCC | | Compliance | RoHS | | | | Material | Plastic | | Dimensions (L x W x H) | 8.3 x 1.0 x 0.6" (21.0 x 2.6 x 1.5 cm) | | Weight | 1 oz (27 g) | | | | Package Weight | 0.25 lb | | Box Dimensions (LxWxH) | 6.614 x 5.197 x 1.575" |
