User Manual for StarTech USB150WN1X1 USB 150Mb s 802.11n g 1T1R Mini Wireless N Network Adapter Click to enlarge the picture
Contents of the user manual for the StarTech USB150WN1X1 USB 150Mb s 802.11n
- Product category: Wireless Adapters & Cards StarTech
- Brand: StarTech
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for StarTech Wireless Adapters & Cards
|
User manual for the StarTech USB150WN1X1 USB 150Mb s 802.11n contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any StarTech product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official StarTech user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a StarTech product will considerably shorten its lifespan!
|
Product description The black USB150WN1X1 USB Mini Wireless N Network Adapter from StarTech allows almost any USB-enabled desktop, laptop, or netbook computer system to connect to n, g, or b wireless networks. Using a 1T1R (1 Transmitter/1 Receiver) design over the 2.4GHz frequency in an extremely compact form factor, the USB adapter is capable of reaching up to 150Mb/s over an 802.11n network while taking up minimal space.
Backward compatible with 802.11b/g networks (11/54Mb/s), this adapter is a versatile wireless networking solution. With support for standard and advanced security options such as WEP, WPA, as well as wireless QoS (Quality of Service) support, and quick and easy setup through WPS, this USB 2.0 adapter makes a suitable wireless upgrade or first-time setup option. - General
- Compatible with 802.11b/g/n Wi-Fi networks and a small form factor, delivers a versatile, portable wireless networking solution
Support for the latest security protocols and easy-to-use WPS (Wi-Fi Protected Setup) ensures a safe and efficient wireless experience anywhere you go
Compact and lightweight design
1 Transmitter/1 Receiver (1x1:1) antenna configuration
Compliant with IEEE 802.11n standard, with transfer rates up to 150 Mb/s
Backward compatible with IEEE 802.11b/g standards, for up to 11/54 Mb/s connections respectively
Supported security features such as WEP (64-128-bit) and WPA
Broadcast distances up to 328.0' (100m) indoors and 984.2' (300m) outdoors
WPS (Wi-Fi Protected Setup) push button or software configuration
Infrastructure and Ad-Hoc network modes support
Plastic enclosure type
Full duplex support - Applications
-
- Add wireless networking capabilities, without having to open up your computer case
- Connect to a wireless network hotspot while on the go, from a USB-enabled portable computer
- Replace or upgrade the wireless capabilities of a desktop or laptop computer
- Connect a computer to a network, where cables cannot be used, such as outdoor locations
- Certifications, Reports, & Compatibility
- CE and FCC compliant
UPC: 065030845038 In the Box StarTech USB150WN1X1 USB 150Mb/s 802.11n/g 1T1R Mini Wireless N Network Adapter (Black) Driver CD Limited 2-Year Warranty Brochure PDF 137.5kb More from Manufacturer Table of Contents
|
Upload User Manual
Have you got an user manual for the StarTech USB150WN1X1 USB 150Mb s 802.11n g 1T1R Mini Wireless N Network Adapter in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersStarTech USB150WN1X1 Specs | | | Antenna Configuration | 1x1:1 (TxR:S) | | Interface | Wireless Ethernet | | Bus Type | USB 2.0 | | Chipset ID | Realtek RTL8188CU | | Industry Standards | IEEE 802.11b
IEEE 802.11g
IEEE 802.11n | | | | Connector Type | 1: USB A (4-pin) male
1: Wireless N (IEEE 802.11n) | | | | Frequency | 2.4 GHz | | Maximum Data Transfer Rate | 150 Mb/s | | Security Features | TKIP/AES
WEP data encryption
WPA / WPA2 data encryption | | MTBF | 44,000 hours | | | | OS Compatibility | Windows 2000 / XP / Server 2003 / Server 2008 R2 / Vista / 7 / 8 (32/64-bit)
Mac OS X (tested up to 10.8)
Linux kernel 2.6 | | System and Cable Requirements | USB enabled computer system with USB port (sold separately)
Microsoft Windows 2000 / XP / Server 2003 / Vista / Server 2008 R2 / 7 (32/64-bit), or Apple Mac OS 10.4 / 10.5 / 10.6, or Linux kernel 2.6.x | | | | Humidity | 10 to 90% RH | | Operating Temperature | 32 to 104°F (0 to 40°C) | | Storage Temperature | -4 to 167°F (-20 to 75°C) | | | | Dimensions (L x W x H) | 1.4 x 0.7 x 0.2" (35.0 x 19.0 x 6.0 mm) | | Weight | 0.1 oz (2.2 g) | | | | Package Weight | 0.2 lb | | Box Dimensions (LxWxH) | 6.4 x 4.0 x 0.4" |
