Technical parametersSupermicro MBD-C7Z270-PG-O Specs | | | Product Type | Motherboard - ATX | | Chipset Type | Intel Z270 Express | | Processor Socket | LGA1151 Socket | | Max Processors Qty | 1 | | Compatible Processors | Core i5, Core i3, Core i7 (supports 6th and 7th Generation Intel Core i3 / i5 / i7) | | | | Max Size | 64 GB | | Technology | DDR4 | | Bus Clock | 3733 MHz (O.C.) | | Supported RAM Integrity Check | Non-ECC | | Registered or Buffered | Unbuffered | | | | Type | HD Audio (8-channel) | | Audio Codec | Realtek ALC1150 | | Compliant Standards | High Definition Audio | | | | Network Controller | Intel I210-AT / I219V | | Network Interfaces | 2 x Gigabit Ethernet | | | | Expansion Slots | 1 x CPU
4 x DIMM 288-pin (1.2 V)
4 x PCIe 3.0 x16 (dual x16 mode; quad: x8 mode)
1 x PCIe 3.0 x4 | | Storage Interfaces | SATA-600 -connectors: 6 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 / RAID 5
PCIe 3.0 -connectors: 2 x M.2 - RAID 0 / RAID 1
PCIe 3.0 -connectors: 2 x U.2 - RAID 0 / RAID 1 | | Interfaces | 2 x USB 2.0
3 x USB 3.1
1 x audio line-out - mini-jack
1 x audio line-in - mini-jack
1 x microphone - mini-jack
1 x audio line-out (side surround) - mini-jack
1 x audio line-out (center/subwoofer) - mini-jack
1 x DisplayPort
1 x HDMI
2 x LAN (Gigabit Ethernet)
1 x USB-C
1 x PS/2 keyboard / mouse
1 x TOSLINK
2 x USB 3.0 | | Internal Interfaces | 2 x USB 3.0 - header
6 x USB 2.0 - header | | Power Connectors | 24-pin main power connector, 8-pin ATX12V connector | | | | BIOS Type | AMI | | BIOS Features | Power failure recovery (AC loss resume), SMBIOS 2.7 support, DMI 2.7 support, ACPI 5.0 support | | Hardware Monitoring | CPU fan tachometer, chassis fan tachometer, system voltage, CPU overheating protection, CPU core voltage | | | | Width | 12 in | | Depth | 9.6 in | | Package Type | Retail | | | | Service & Support | Limited warranty - parts - 1 year
Limited warranty - labor - 3 years |
