User Manual for SureFire X400 Vampire IRc White Light Infrared LED & Infrared Laser WeaponLight Click to enlarge the picture
Contents of the user manual for the SureFire X400 Vampire IRc White Light
- Product category: Weapon & Tactical Lights SureFire
- Brand: SureFire
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for SureFire Weapon & Tactical Lights
|
User manual for the SureFire X400 Vampire IRc White Light contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any SureFire product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official SureFire user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a SureFire product will considerably shorten its lifespan!
|
Product description Conduct force-on-force training or perform covert operations using the infrared properties of X400 Vampire IRc White Light/Infrared LED & Infrared Laser WeaponLight from Surefire. The integral Class 1 infrared-laser sight is well-suited for use with night vision devices or with Multiple Integrated Laser Engagement System (MILES) vests. The 120mW infrared illuminator provides a bright picture when used in conjunction with a Night Vision Device (NVD), or you can select the 350 lumen white LED emitter for use without. The light features SureFire's Total Internal Reflection (TIR) lens that produces a pre-focused beam with a tight center cone of bright light, and a dimmer ring on the periphery to help maintain situational awareness.
To choose between white and IR modes, simply depress and rotate the light's bezel. An ambidextrous toggle switch controls the momentary and constant-on modes. The selector switch, located behind the laser, switches the output modes and features a lock-out function to prohibit accidental activation during storage or when strict light discipline must be maintained. The device mounts to any hand or long gun equipped with a Picatinny or Universal rail. Designed for durability, this system features a weatherproof O-ring and gasket-sealed MIL-STD anodized aluminum housing. - Light Performance
-
- 350 lumen output from white LED
- 120mW infrared LED output
- White LED runtime of 1.8 hours
- Infrared LED runtime of 8 hours
- Total Internal Reflection (TIR) lens with optically coated tempered glass
- Laser Performance
-
- Eye-safe Class 1 infrared
- <0.7mW peak output
- Switching
-
- White/IR Light Selector:
- Push and twist the self-locking bezel selector
- Toggle Switch:
- Location: Back of light
- Type: Multi-directional toggle
- Push switch forward for momentary-on
- Push switch up or down for constant-on
- Ambidextrous switch for use by all shooters
- Selector switch:
- Location: Behind laser emitter
- Function: Output and lock-out control
- Rotating positions controls output modes
- Lock-out function to prevent accidental activation
- Output modes: white-light only, laser only, or flashlight and laser
- Construction Details
-
- 1.06" diameter bezel
- Aluminum alloy housing
- Type III MIL-STD hard anodized finish
- O-ring and gasket-sealed for water resistance
- Anti-reflective coated, tempered glass lens window
- Rail-Lock system for quick attachment/detachment
- Picatinny and Universal-rail mountable for pistols or rifles
- Accepts optional pistol grip and long gun forend switches
- Adapter mounts available for several non-rail equipped handguns
UPC: 084871325349 In the Box SureFire X400 Vampire IRc White Light/Infrared LED & Infrared Laser WeaponLight 2 x 123A Batteries Limited Lifetime Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the SureFire X400 Vampire IRc White Light Infrared LED & Infrared Laser WeaponLight in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersSureFire X400V-B-IRC Specs | Illumination Source | White LED
Infrared LED | | Output | White LED: 350 lumens / 1.8 h
Infrared LED: 120 mW / 8.0 h | | Laser | Class 1 eye-safe
<0.7 mW infrared | | Power Source | 2 x 123A | | Mount | Picatinny | | Construction | Aluminum alloy with Type III hard anodizing | | Diameter | Bezel: 1.06 / 2.69 | | Length | 4" / 10.2 cm | | Weight | 4.8 oz / 136.1 g | | | | Package Weight | 0.5 lb | | Box Dimensions (LxWxH) | 5.9 x 4.1 x 2.6" |
