Product description The AV-1330 AV-1361 HD IP PTZ Camera from SWIT provides IP streaming with H.264/H.265 encoding support up to 1080p/60. Features include multiple HDMI and 3G-SDI outputs, a 20x optical zoom, a wide 55.4° angle-of-view, and a low 0.5-lux minimum illumination rating. The AV-1330 AV-1361 HD IP's 1/2.8" CMOS sensor and 2D/3D noise reduction help produce a natural-looking HD image. This PTZ camera is suitable for video conferencing, educational settings, sports applications, and houses of worship. The camera includes an RS-232/RS-485 interface and works with an optional IR remote controller (not included). Key Features - Wide-angle 20x optical/10x digital zoom lens with a 2.9-55.4° angle of view and a 0.5-lux minimum illumination capacity
- 1/2.8" CMOS image sensor, 16:9 aspect ratio, and 2D/3D noise reduction
- IP streaming, DVI (HDMI) and 3G-SDI outputs
- HD video output of up to 1080p/60 resolution with H.264/H.265 encoding
- RS-232/RS-485 interface and optional infrared remote control (controller not included)
UPC: 858738005244 In the Box SWIT AV-1361 HD IP PTZ Camera AC Adapter Power Cord RS-232 Cable (7") DVI-I to HDMI Adapter Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the SWIT AV-1361 HD IP PTZ Camera in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersSWIT AV-1361 Specs | | | Image Resolution | 1080p: 60/50/30/25
1080i: 60/50
720p: 120/60/50/30/25 | | Image Sensor | Type: 1/2.8" CMOS
Effective Pixels: 2.07 million
Aspect Ratio: 16:9 | | Scanning Mode | Progressive | | Lens | Zoom: 12x optical, 10x digital
Focal Length: 4.7-94mm
Aperture: f/1.6 to 3.5 | | Minimum Illumination | 0.5 lux (at f/1.8, auto gain on) | | Shutter Speed | 1/30~1/10,000 per second | | White Balance Modes | Auto/Manual/One-Push/3000K/4000K/5000K/6500K/Indoor/Outdoor | | Digital Noise Reduction | 2D and 3D | | Video S/N Ratio | ≥55 dB | | Angle of View | Horizontal: 2.9-55.4°
Vertical: 2.9-55.4° | | Rotation Range | Vertical: -30 to 90° | | Speed Range | Pan: 0.1 to 100°/second
Tilt: 0.1 to 45°/second | | Number of Presets | 255 | | Preset Accuracy | 0.1° | | | | Encoding | H.264/H.265 | | Video Resolutions | First Stream: 1920 x 1080, 1280 x 720, 1024 x 576, 960 x 540, 640 x 360
Second Stream: 720 x 576, 720 x 480, 320 x 240 | | Video Bit Rate | Range: 128~8192 kbps
Type: Variable, fixed | | Frame Rates | 60Hz: 1~60 fps
50Hz: 1~50 fps 720p/130 fps | | Audio Encoding | AAC/MP3/PCM | | Audio Streaming | 96/128/256 kbps | | Supported Protocols | TCP/IP, HTTP, RTSP, RTMP, Onvif, DHCP, Multicast, etc. | | | | HD Output | 1 x DVI (HDMI): Version 1.3
1 x 3D-SDI: BNC/800 mVp-p/75Ω/SMPTE 424M | | Network Interface | 1 x RJ45: 10/100/1000M adaptive Ethernet ports | | Audio Interface | 1-channel 3.5 mm audio interface, line-in | | USB | None | | Communication Interface | 1 x RS-232 In:
8-pin Min DIN, Max Distance: 98' (30 m), Protocol: VISCA/Pelco-D/Pelco-P
1 x RS-232 Out:
8-pin Min DIN, Max Distance: 98' (30 m), Protocol: VISCA network use only
1 x RS-485:
2-pin Phoenix port, Max Distance: 3937' (1200 m), Protocol: VISCA/Pelco-D/Pelco-P | | Power Input | 12 VDC, JEITA-type | | | | Power Consumption (Maximum) | 12 W, 1.0 A | | Input Voltage | 12 VDC | | Operating/Storage Temperature | Operating: 14 to 122°F (-10 to 50°C)
Storage: 14 to 140°F (-10 to 60°C) | | Mean Time Between Failure (MTBF) | >30,000 h | | Dimensions | 10 x 7 x 7" (258 x 172 x 169 mm) | | Weight | 3.4 lb (1.54 kg) | | | | Package Weight | 6.5 lb | | Box Dimensions (LxWxH) | 13.8 x 10.7 x 9.9" |
