User Manual for SWIT AV-1362 HD USB PTZ Camera Click to enlarge the picture
Contents of the user manual for the SWIT AV-1362 HD USB PTZ Camera
- Product category: PTZ Cameras SWIT
- Brand: SWIT
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for SWIT PTZ Cameras
|
User manual for the SWIT AV-1362 HD USB PTZ Camera contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any SWIT product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official SWIT user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a SWIT product will considerably shorten its lifespan!
|
Product description The AV-1330 AV-1362 HD USB PTZ Camera from SWIT provides IP streaming with H.264/H.265 encoding support up to 1080p/60. Features include multiple HDMI and USB3.0 outputs, a 20x optical zoom, a wide 55.4° angle-of-view, and a low 0.5-lux minimum illumination rating. The AV-1330 AV-1362 HD USB's 1/2.8" CMOS sensor and 2D/3D noise reduction help produce a natural-looking HD image. This PTZ camera is suitable for video conferencing, educational settings, sports applications, and houses of worship. The camera includes an RS-232/RS-485 interface and works with an optional IR remote controller (not included). Key Features - Wide-angle 20x optical/10x digital zoom lens with a 2.9-55.4° angle of view and a 0.5-lux minimum illumination capacity
- 1/2.8" CMOS image sensor, 16:9 aspect ratio, and 2D/3D noise reduction
- IP streaming, DVI (HDMI) and USB3.0 outputs
- HD video output of up to 1080p/60 resolution with H.264/H.265 encoding
- RS-232/RS-485 interface and optional infrared remote control (controller not included)
UPC: 858738005251 In the Box SWIT AV-1362 HD USB PTZ Camera AC Adapter Power Cord RS-232 Cable (7") DVI-I to HDMI Adapter Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the SWIT AV-1362 HD USB PTZ Camera in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersSWIT AV-1362 Specs | | | Image Resolution | 1080p: 60/50/30/25
1080i: 60/50
720p: 120/60/50/30/25 | | Image Sensor | Type: 1/2.8" CMOS
Effective Pixels: 2.07 million
Aspect Ratio: 16:9 | | Scanning Mode | Progressive | | Lens | Zoom: 12x optical, 10x digital
Focal Length: 4.7-94mm
Aperture: f/1.6 to 3.5 | | Minimum Illumination | 0.5 lux (at f/1.8, auto gain on) | | Shutter Speed | 1/30~1/10,000 per second | | White Balance Modes | Auto/Manual/One-Push/3000K/4000K/5000K/6500K/Indoor/Outdoor | | Digital Noise Reduction | 2D and 3D | | Video S/N Ratio | ≥55 dB | | Angle of View | Horizontal: 2.9-55.4°
Vertical: 2.9-55.4° | | Rotation Range | Vertical: -30 to 90° | | Speed Range | Pan: 0.1 to 100°/second
Tilt: 0.1 to 45°/second | | Number of Presets | 255 | | Preset Accuracy | 0.1° | | | | Encoding | H.264/H.265 | | Video Resolutions | First Stream: 1920 x 1080, 1280 x 720, 1024 x 576, 960 x 540, 640 x 360
Second Stream: 720 x 576, 720 x 480, 320 x 240 | | Video Bit Rate | Range: 128~8192 kbps
Type: Variable, fixed | | Frame Rates | 60Hz: 1~60 fps
50Hz: 1~50 fps | | Audio Encoding | AAC/MP3/PCM | | Audio Streaming | 96/128/256 kbps | | Supported Protocols | TCP/IP, HTTP, RTSP, RTMP, Onvif, DHCP, Multicast, etc. | | | | HD Output | 1 x DVI (HDMI): Version 1.3 | | Network Interface | 1 x RJ45: 10/100/1000M adaptive Ethernet ports | | Audio Interface | 1-channel 3.5 mm audio interface, line-in | | USB | 1 x USB3.0: Type A female jack | | Communication Interface | 1 x RS-232 In:
8-pin Min DIN, Max Distance: 98' (30 m), Protocol: VISCA/Pelco-D/Pelco-P
1 x RS-232 Out:
8-pin Min DIN, Max Distance: 98' (30 m), Protocol: VISCA network use only
1 x RS-485:
2-pin Phoenix port, Max Distance: 3937' (1200 m), Protocol: VISCA/Pelco-D/Pelco-P | | Power Input | 12 VDC, JEITA-type | | | | Power Consumption (Maximum) | 12 W, 1.0 A | | Input Voltage | 12 VDC | | Operating/Storage Temperature | Operating: 14 to 122°F (-10 to 50°C)
Storage: 14 to 140°F (-10 to 60°C) | | Mean Time Between Failure (MTBF) | Not specified by manufacturer | | Dimensions | 10 x 7 x 7" (258 x 172 x 169 mm) | | Weight | 3.4 lb (1.54 kg) | | | | Package Weight | 6.6 lb | | Box Dimensions (LxWxH) | 13.8 x 10.7 x 9.8" |
