Product description

The SDVD9000B2 9" Swivel Style Portable DVD Player from Sylvania offers a 9" LCD display and multi-format playback at an affordable price point. This portable entertainer also has a swivel screen, so you can achieve an ideal viewing angle whether you're using it at home or on the go. With built-in stereo speakers, the SDVD9000B2 can play your DVDs, CDs, and also supports MP3 and JPEG photo files -- so, in addition to watching movies you can listen to music and show off personal photos. It also comes with an internal rechargeable battery. The unit includes an AC adapter so you can plug it into a wall outlet when you're using it around the house. Additional features are a headphone jack for private listening, a video output so you can hook it up to your TV and speakers, and a remote control for making adjustments from a comfortable distance.
    Widescreen Monitor
  • The player features a 9" high-resolution widescreen display
    Multi-Format Playback
  • This disc player supports playback of: DVD Video, DVD-R, DVD-RW, CD, CD-R, and CD-RW discs. It also supports MP3 and JPEG files so you can listen to compressed music files and display photos from a camera on the widescreen display
    Home Theater Friendly
  • Plug the SDVD9000B2 into your TV using the video out and use it as a standard DVD player so everyone can watch
    Headphone Output
  • A headphone output lets you listen privately for when you don't want to disturb others
    Comes With Car Charger Adapter
  • This helps make sure the DVD player is always ready to go, no matter how long the road trip
    Built-in Stereo Speakers
  • If you don't have a surround sound setup, this disc player has two built-in speakers for stereo playback of your movies and music
    Parental Lock Control
  • Parental lock control enables you to control which discs your children watch
    Easy to Control
  • The SDVD9000B2 comes with a remote control so you can operate the disc player from a distance
UPC: 058465774424 In the Box Sylvania SDVD9000B2 9" Swivel Style Portable DVD Player
  • Headphones
  • Audio/Video Cable
  • Remote Control
  • Rechargeable Battery
  • Carrying Bag
  • AC Adapter
  • Car Cigarette Adapter
  • Limited 90-Day Warranty
  • Table of Contents

    Upload User Manual

    Have you got an user manual for the Sylvania SDVD9000B2 9" Swivel Style Portable DVD Player in electronic form? Please send it to us and help us expand our library of instruction manuals. Thank you, too, on behalf of other users.

    To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
    Upload PDF user manual Upload DOC user manual
    Please enter here the link to the user manual of this product:


    Enter here the file with the user manual of this product from your computer/phone:
    (60MB max; Permitted formats: PDF)


    Technical parameters

    Sylvania SDVD9000B2 Specs

    Screen Size 9"
    System NTSC/PAL
    Dynamic Range Better than 85 dB (DVD/CD)
    Signal to Noise Ratio Better than 80 dB (Analog out connectors only)
    Laser Semiconductor laser, wave-length: 650 nm
    Frequency Response 20 Hz - 20 kHz (1 dB)
    Built-in Speaker 1 W x 2
    Disc Playback Formats DVD / DVD‐R / DVD‐RW / VCD / S‐VCD / CD / MP3 / WMA / JPEG
    Audio Output 1 Vp-p/75 Ω, unbalanced
    Video Output 1.4 Vrms/10 k Ω
    Digital Media Slot USB / SD / MMC
    Connectors Coaxial out x 1
    Headphone x 1
    Humidity 5-90%
    Remote Yes
    Power Source DC 9.5 V, 1.5 A
    Power Consumption 10 W
    Battery Output: 7.4 V
    Charge Time: 3-4 hours
    Battery Operable Storage:
    6 Months (Temperature / Humidity): -4-113°F (-20-45°C) / 20-65%
    1 Week (Temperature / Humidity): -4-149°F (-20-65°C) / 20-65%
    Standard Charge (Temperature / Humidity): 32-113°F (0-45°C) / 20-65%
    Standard Discharge (Temperature / Humidity): -4-149°F (-20-65°C) / 20-65%
    Swivel Ability Yes
    Dimension L x W x H 10.2 x 7.2 x 1.5" (260 x 182 x 37.5 mm)
    Weight 2 lb. (0.9 kg)
    Package Weight 3.05 lb
    Box Dimensions (LxWxH) 11.7 x 11.0 x 2.2"
