User Manual for Tamron 23FM12 2 3 12mm F 1.8 Standard High Resolution C-Mount Lens Click to enlarge the picture
Contents of the user manual for the Tamron 23FM12 2 3 12mm F
- Product category: Lenses Tamron
- Brand: Tamron
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Tamron Lenses
|
User manual for the Tamron 23FM12 2 3 12mm F contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Tamron product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Tamron user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Tamron product will considerably shorten its lifespan!
|
Product description Specifically designed for factory automation and machine vision applications, Tamron's 23FM12 2/3 12mm F/1.8 lens features a solid construction to endure long periods of use in vibrating conditions encountered in a factory automation environment. Compact in size, this high resolution lens is designed to fit today's machinery dimensions and uses superior optics to maintain sharp clarity in a focusing range of less than 0.3m. - Solid Mechanism
- Designed to endure the rigors of factory automation apparatus, this solid built lens maintains maximum performance even after long periods of use.
- Closer MOD
- Uses superior optics to achieve a Minimum Object Distance requirement of less than 0.3m.
- Compact
- A compact size ensures compatibility with today's machinery dimensional requirements.
- Filter Compatibility
- With a filter size of M25.5 Po.5, this lens readily accepts UV, polarizer, red, green, and blue filters.
UPC: 725211917083 In the Box Tamron 23FM12 2/3 12mm F/1.8 Standard High Resolution C-Mount Lens 2 Year parts & labor warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Tamron 23FM12 2 3 12mm F 1.8 Standard High Resolution C-Mount Lens in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersTamron 23FM12 Specs | Focal Length | 12mm | | Mount Type | C | | Iris Range | F1.8 - 16 | | Iris Operation | Manual | | Focus Operation | Manual | | Angle of View | 1/3": 22.4° x 16.6°
1/2": 30.0° x 22.4°
2/3": 40.9° x 30.9° | | Effective Diameter | 11.7mm/8.0mm | | Minimum Object Distance (M.O.D.) | 10.2" (0.26m) | | Back Focus | 11.03mm (in air) | | Filter Size | M25.5 P=0.5 | | Maximum Diameter | 1.1" (29mm) | | Overall Length | 1.1" (27mm) | | Weight | 1.4 oz (40 g) | | | | Package Weight | 0.15 lb | | Box Dimensions (LxWxH) | 2.9 x 2.8 x 1.8" |
Rating70% users recommend this product to others. And what about you?
This product has already been rated by 28 owners. Add your rating and experience with the product.
