User Manual for taulman3D 2.85mm t-glase Filament Click to enlarge the picture
Contents of the user manual for the taulman3D 2.85mm t-glase Filament
- Product category: All 3D Printer Filament/Cartridges taulman3D
- Brand: taulman3D
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for taulman3D All 3D Printer Filament/Cartridges
|
User manual for the taulman3D 2.85mm t-glase Filament contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any taulman3D product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official taulman3D user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a taulman3D product will considerably shorten its lifespan!
|
Product description The green 2.85mm t-glase Filament from taulman3D is a strong, industrial 3D printing filament that has a printable temperature range of 405 to 491°F, although its optimum temperature is 455 to 464°F, a tensile stress of 4516 psi, an ultimate elongation of 7.8%, and a modulus of 80,315 psi. It also features low shrinkage of 0.0029 and allows for the non-destructive evaluation of 3D prints. Furthermore, while it is not biodegradable like PLA, it is a reclaimable filament, so extruders that convert failed prints back to usable filament will work well with t-glase. General Features - Temperature
- Optimum temperature is about 455 to 464°F, but it will print from 405 to 491°F.
- Environmental
- While t-glase is not biodegradable like PLA, it is a material that's considered 100% reclaimable. Thus, extruders that convert failed prints back to usable filament work well with t-glase. If you have a compatible extruder, you can actually mix in 12% of the total weight with discarded clear water bottles.
- Clarity
- t-glase's clarity supports the industry's requirements for the non-destructive evaluation of 3D printed parts.
- Shrinkage
- Very low shrinkage helps make printing large flat surfaces more user-friendly.
- Bridging
- Those of us who have printed with acrylics and polycarbonates are always envious of their bridging capabilities due to their glass temperature. t-glase works well with bridging.
- Fumes
- There are no odors or fumes when 3D printing with t-glase.
Other - Use of Taps for Threads
- Very good
- CNC Finish Tooling
- Carbide
- CNC Coolant
- Forced air only
- Use in 3D Forging
- Very good
- Robotic Assemblies
- Very good
- Jewelry Printing
- Very good
- Lenticulated Overlays
- N/A
- Dye Uptake (Saturation)
- N/A
UPC: 817752014915 In the Box taulman3D 2.85mm t-glase Filament (Green, 0.5kg, 512') Limited 30-Day Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the taulman3D 2.85mm t-glase Filament in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parameterstaulman3D RM-PE0004 Specs | | | Printing Temperature | 455 to 468°F / 235 to 242°C | | Melting Temperature | 405°F / 207°C | | Tg Glass Transition | 169°F / 76°C | | Pyrolysis - Thermal Degradation | 540°F / 282°C | | Non-Destructive Evaluation | Yes | | Print Bed Temperature | 154°F / 68°C (max) | | Ambient Temperature (Enclosure) | None | | | | Tensile Stress | 4516 psi | | Ultimate Elongation | 7.8% | | Modulus | 80,315 psi | | | | Opacity | 88% | | Reflectivity | 5-8% | | Color | Green | | | | UL 94 HB | None | | UL 94 V2 | None | | | | Nominal Diameter | 2.85 mm | | Weight / Spool | 1.0 lb / 0.5 kg | | Nominal Length / Spool | 512' / 156 m | | Shrinkage | 0.0029" / 0.0074 cm | | Solvent/Glue | Tetrahydrofuran | | | | Package Weight | 2.145 lb | | Box Dimensions (LxWxH) | 9.1 x 8.75 x 2.7" |
Rating60% users recommend this product to others. And what about you?
This product has already been rated by 49 owners. Add your rating and experience with the product.
