User Manual for TeachLogic AR-960 AirLink Router System Click to enlarge the picture
Contents of the user manual for the TeachLogic AR-960 AirLink Router System
- Product category: Components & Accessories TeachLogic
- Brand: TeachLogic
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for TeachLogic Components & Accessories
|
User manual for the TeachLogic AR-960 AirLink Router System contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any TeachLogic product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official TeachLogic user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a TeachLogic product will considerably shorten its lifespan!
|
Product description The AR-960 AirLink Router System from TeachLogic includes the ALS-960 Wireless Transmitter and DR-702 Diversity Receiver.The ALS-960 Wireless AirLink Transmitter is a stand-alone 96 channel transmitter (640 to 664 MHz). You can transmit to any of the portable Titan systems equipped with a matching receiver module. The AirLink router allows you to take a line level signal from your mixing console or playback device (DVD-iPod), plug it directly into the AirLink transmitter, and then broadcast that audio to a distant AirLink receiver or multiple receivers. It can be incorporated with the diversified receiver for transmission of a composite program for an extended distance in excess of 500.0’ (152.4m) with clarity and reliability.
Whether there is a need to get audio signals to an overflowing crowd at a special event or send the announcer’s voice across the football stadium, the AirLink Router System can get the message across with ease with the use of RF transmission. Tests have been performed through multi-story buildings from the lobby to the upper conference room, from a press box to cross-field component sound systems and various concession booths, or from an outdoor program stage to distant Titans with UHF receivers. Transmission distance in excess of 500.0’ (152.4m) has been achieved in direct line of sight with high level of clarity and connectivity.
It also functions as a very handy 2 channel mixer by combining the aux line level input and the 0.25” (6.35mm) mic input. This allows both pre-recorded program material and a live microphone to be broadcast at an event with no additional mixing equipment required. The system’s 96 UHF channel allow the selection of an interference-free channel. The transmitter antenna renders reliable transmission in excess of 500.0’ (152.4m).
The DR-702 Diversity Receiver is a stand-alone receiver and comes equipped with selectable 96 channels. It has an audio output of 0 to 2V. It reproduces full range sound with clarity. - ALS-960 Wireless Transmitter Features
-
- Half-wave antenna for extended transmission distance
- Two Line Level Program Inputs: Balanced (XLR); unbalanced (Dual RCA)
- Inputs mixable for composite output
- Selectable 96 channels, UHF, (640 to 664 MHz)
- LCD for channel or frequency display
- Master gain control for composite output
- Headphone output
- Titan and Spartan compatible
- DR-702 Diversity Receiver Features
-
- Diversity receiver for more reliable reception
- 2 Half-wave antennas for enhanced reception
- Balanced line level output (0 to 2V), XLR
- Unbalanced line level output, 0.25” (6.35mm) phone
- Selectable 96 channels (640 to 664 MHz)
- LCD for channel or frequency display
- Volume / gain control
- Low / high output level switch
In the Box TeachLogic AR-960 AirLink Router System ALS-960 AirLink Stand Alone 96-Channel Transmitter DR-702 Diversity Receiver Limited 3-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the TeachLogic AR-960 AirLink Router System in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersTeachLogic AR-960 Specs | | | Operating frequency bands | Diversity: 640 to 664 MHz | | Selectable Channels | 96 Pre-programmed | | Maximum Deviation | 80 kHz, with level limiting | | Dynamic Range | 110 dB | | THD | >0.5% | | Pre-Emphasis | De-Emphasis: 50 μs | | Sensitivity | 4 μV @ 30 dB SINAD | | Squelch | Tone Key and Noise Lock | | Frequency Response | 50 Hz, -17 kHz, ± 3 dB | | Delay | Units: Milliseconds
Range: 20 to 500 ms | | Operating Range | In excess of 500.0' (152.4m) with 2 half-wave antenna | | Output | Balanced (XLR), unbalanced 0.25" (6.35 mm) | | Output Level | 0 to 2 V @ 10 kΩ | | Power Requirements | 12 to 15 VDC, 1 A | | Power Supply | 100 to 240 VAC / 12 VDC 1 A switching supply | | Dimensions (WxHxD) | 8.0 x 8.5 x 1.7" (203.2 x 215.9 x 43.1 mm) | | Weight | 2.75 lb (1.24 kg) | | | | Operating frequency bands | Wireless AirLink: 640 to 664 MHz | | Selectable Channels | 96 pre-programmed | | Maximum Deviation | 80 kHz, with level limiting | | Dynamic Range | 110 dB | | THD | >0.5% | | Pre-Emphasis | De-Emphasis: <50 μs | | Sensitivity | 4 μV @ 30 dB SINAD | | Squelch | Tone Key and Noise Lock | | Frequency Response | 50 Hz, -17 kHz, ± 3 dB | | RF Output Power | 30 mW | | Operating Range | In excess of 500.0' (152.4m), with 1 half-wave antenna | | Input | Balanced (XLR), unbalanced line level dual RCA, inputs blended to mono output, unbalanced mic level 0.25" (6.35 mm) phone | | Output | Aux line level, (dual RCA), 0.25" (6.35 mm) phone jack, RCA aux-in only with volume control | | Power Requirements | 12 to 15 VDC, 1 A | | Dimensions | 8.5 x 1.7 x 8.0" (215.9 x 43.1 x 203.2 mm) | | Weight | 2.75 lb (1.24 kg) |
