User Manual for TeachLogic UT-96BP R Bodypack Radio Frequency Transmitter with BRC-70 Drop-In Charger & 2 AA-Size NiMH Rechargeable Batteries Click to enlarge the picture
Contents of the user manual for the TeachLogic UT-96BP R Bodypack Radio Frequency
- Product category: Components & Accessories TeachLogic
- Brand: TeachLogic
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for TeachLogic Components & Accessories
|
User manual for the TeachLogic UT-96BP R Bodypack Radio Frequency contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any TeachLogic product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official TeachLogic user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a TeachLogic product will considerably shorten its lifespan!
|
Product description The UT-96BP/R Bodypack Radio Frequency Transmitter from TeachLogic comes with the BRC-70 Drop-In Charger and two AA-size Duracell NiMH rechargeable batteries. The bodypack transmitter sends a composite voice and RF (UHF) signal to the receiver (sold separately). It features 96 selectable UHF channels and is usually worn on the waistband with an external microphone (not included) plugged in for vocal input. The transmitter ensures reliable connectivity with the receiver in excess of 200' (60.9m). It utilizes two BR-2AA Duracell NiMH rechargeable batteries (included) for 6 to 8 hours of continuous transmission. It can be charged using the BRC-70 Drop-In Charger (included) along with a handheld microphone (not included). Note: The bodypack transmitter is meant to be used with an external microphone (not included). - UT-96BP Bodypack Radio Frequency Transmitter The UT-96BP Bodypack Radio Frequency Transmitter from TeachLogic features 96 selectable UHF channels. It transmits a composite voice and RF (UHF) signal to the receiver (sold separately). It is usually worn on the waistband with an external microphone (not included) plugged in for vocal input. It ensures reliable connectivity in excess of 200' (60.9m). The transmitter requires two AA batteries (sold separately) for 6 to 8 hours of continuous transmission. Note: The bodypack transmitter is meant to be used with an external microphone (not included).
- Selectable 96 UHF channels
- Push-button channel select
- LCD readout for selected channel number, frequency, and battery condition
- 3.5mm Aux line level input jack
- Low battery power consumption
- High / mid / low microphone sensitivity switch
- Compatible with drop-in charger (sold separately)
- Requires two AA batteries (sold separately) for 6 to 8 hours of continuous transmission
- BRC-70 Drop-In Charger for Bodypack and UT-96BP/UT96HH TeachLogic's BRC-70 Drop-In Charger for Bodypack and UT-96BP/UT96HH is a drop-in charger for the TeachLogic Bodypack and one UT-96BP or UT96HH microphone/transmitter.
- AA NiMH Rechargeable Batteries (2,450mAh, 2 Pack) This two pack of AA NiMH Rechargeable Batteries from TeachLogic includes rechargeable batteries with a capacity of 2,450 mAh.
In the Box Bundle Items UT-96BP Bodypack Radio Frequency Transmitter rtbxcyeyferctzbrttvdb - Limited 3-Year Warranty on Parts & Labor
BRC-70 Drop-In Charger for Bodypack and UT-96BP/UT96HH AA NiMH Rechargeable Batteries (2,450mAh, 2 Pack) Table of Contents
|
Upload User Manual
Have you got an user manual for the TeachLogic UT-96BP R Bodypack Radio Frequency Transmitter with BRC-70 Drop-In Charger & 2 AA-Size NiMH Rechargeable Batteries in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parameters - UT-96BP Bodypack Radio Frequency Transmitter
| Frequency Bands | Operating: 640 to 664 MHz | | Selectable Channels | 96 pre-programmed | | Maximum Deviation | 80 kHz, with level limiting | | Dynamic Range | >80 dB | | THD | >1% | | Pre-Emphasis | <50 μs | | De-Emphasis | <50 μs | | Audio Input | 3.5 mm Aux In | | AF Control | Mic mute button
Mic high / mid / low switch | | Operating Life | 14 hours (NiMH) or 17 hours (Alkaline), full charge | | Housing | Aluminum | | Dimension (D x W x H) | 1.0 x 2.5 x 3.3" (25.4 x 63.5 x 85.5 mm) | | Weight | 10.5 oz (297.6 g) | - BRC-70 Drop-In Charger for Bodypack and UT-96BP/UT96HH
| Compatibility | Compatible with TeachLogic Bodypack and UT-96BP/UT96HH | | Power | 110V | | Charging Time | 10-12 Hours | | Indicator Lights | Orange: Charging
Green: Charged | | Dimensions | 4.1 x 3.3 x 3.4" (10.41 x 8.38 x 8.63 cm) | | Weight | 0.43 lb (0.19 kg) | - AA NiMH Rechargeable Batteries (2,450mAh, 2 Pack)
| | | Battery Type | 2 x AA | | Battery Chemistry | NiMH | | Capacity (mAh) | 2450 mAh | | | | Box Dimensions (LxWxH) | 2.5 x 1.75 x 0.5" |
