User Manual for Tektronix Computer Serial Triggering and Analysis Module Click to enlarge the picture
Contents of the user manual for the Tektronix Computer Serial Triggering and Analysis
- Product category: Waveform Monitor & Scope Accessories Tektronix
- Brand: Tektronix
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Tektronix Waveform Monitor & Scope Accessories
|
User manual for the Tektronix Computer Serial Triggering and Analysis contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Tektronix product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Tektronix user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Tektronix product will considerably shorten its lifespan!
|
Product description The Tektronix Computer Serial Triggering and Analysis Module (RS-232 / 422 / 485 / UART) is designed to automate the process of triggering on specific data packets across RS-232 / 422 / 485 / UART buses. Designed for use with the DPO / MSO2000 series oscilloscopes, this module simplifies execution and allows speedy evaluation of packet data, resulting in better productivity. Featuring automatic trigger, decode, and search options, the DPO2COMP Computer Serial Triggering and Analysis Module transforms the oscilloscope in to a robust tool for debugging serial buses. You can stipulate your criteria for search, and this module will automatically capture your event of interest over a period. Captured information is pooled and displayed on the oscilloscope’s screen, thereby making it easy to identify all the critical elements of a serial bus such as address, data, CRC, etc. Decoding the signals is made simpler, thanks to the module's ability to display the collected data as ASCII code on the bus waveform. In addition, this module adds to your convenience by displaying the data with individual subcomponent identifiers in an event table with the packets being time-stamped. In addition, smart search functionality in this module highlights each occurrence of a specified identifier on the waveform, thus ensuring efficiency in analyzing and navigating across the displayed waveforms. - Automatically triggers on data packets across RS-232 / 422 / 485 / UART buses
- Designed to be used with DPO / MSO2000 series oscilloscopes
- Simplifies execution and allows speedy evaluation, resulting in improved productivity
- Features automatic trigger, decode, and search options
- Search through loads of data using custom criteria to find specific messages
- Simultaneously display of individual signals for easy identification of subpacket components such as address, data, identifier, CRC, etc.
- Obtained data is also displayed as ASCII code on the bus waveform
- Occurrence of an event is highlighted on the waveform for simpler analyzing and navigating options
- Values are also represented in a table for your convenience
- Event table values can be exported to CSV format for offline analysis of data
- Packets are time-stamped for a quick summary of system activity
