Product description The GPS7 GPS Master Clock Module from Tektronix is a special option available for the TG700 Multi-Format Video Generator. It updates your unit to include GPS synchronization and timecode functionality. The module is an integrated GPS receiver that serves as the system timing reference. Synchronization to the GPS timing signals ensures long-term stability and video-frame alignment between independent systems. The module offers (3) black outputs selectable as HDTV tri-level, NTSC, or PAL. It will maintain system timing during periods of GPS signal loss. Timecode is available as VITC on black outputs and from (4) independent LTC outputs. Timecode can be set as "time-of-day" with user-selectable offsets or to a "program time" counter for elapsed-time timecode. - GPS Master Clock
- Use this module to add GPS synchronization and timecode functionality to your TG700 Multi-Format Video Generator.
In the Box Tektronix GPS7 GPS Master Clock Module One-Year Warranty Against Defects in Materials & Workmanship Table of Contents
|
Upload User Manual
Have you got an user manual for the Tektronix GPS7 GPS Master Clock Module in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersTektronix GPS7 Specs | Specifications | GPS RECEIVER
Type: L1 (1575.42 MHz) Frequency, C/A Code, 12 channels
Time-of-Day: User-selectable time zone and DST offset adjustment GPS ANTENNA INPUT
Connector: BNC
Input Impedance: 50 Ohms, internally terminated
DC Antenna Power Output Voltage: 3.3 or 5V at nominal load
Fault Protection: short-circuit/open detection and protection
Return Loss: 8dB at 1575MHz |
