Product description The HD3G7 3Gbps SDI Video-Generator Module from Tektronix is a special option available for the TG700 Multi-Format Video Generator. It updates your unit with the ability to produce 3Gbps SDI signals. The SDI test signal is produced according to the SMPTE 425M standards for "fast progressive" formats, including 1080p/50 and 59.94/60. The module supports both Level A and Level B coding for 1080p formats. It includes a variety of standard test signals, including SMPTE color bars and SDI pathological test patterns. It also has the ability to up-convert an input from 1080i 1.485Gbps HD-SDI to 1080p output. The module also offers a clock/frame trigger output that can be used to synchronize the output with an oscilloscope or other similar device. - 3Gbps SDI Video Generator
- Use this module to add the ability to produce 3Gbps SDI signals to your TG700 Multi-Format Video Generator.
In the Box Tektronix HD3G7 3Gbps SDI Video-Generator Module One-Year Warranty Against Defects in Materials & Workmanship Table of Contents
|
Upload User Manual
Have you got an user manual for the Tektronix HD3G7 3Gbps SDI Video-Generator Module in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersTektronix HD3G7 Specs | Specifications | SERIAL DIGITAL SIGNAL OUTPUT
Test Signals:
100%, 75%, and SMPTE Color Bars, Flat Field (0% to
100% in 10% steps), 100% and 75% Red/Green/Blue,
Convergence, Ramp, Valid Ramp, 5-step Staircase,
2T30 Pulse and Bar, SDI pathological
HD-SDI Converter: Input 1080i signal up-converted to output 1080p signal
Standards: SMPTE 424M, 425M
Bit Rate: 2.97Gbps, 2.97/1.001Gbps
Output Format:
1080p/50 Hz, 59.94 Hz, 60 Hz.
Both Level A and Level B supported
Embedded Audio:
16 channels copied from input signal to output signal in convertor mode. No embedded audio in generator mode
Payload Identifier: Per SMPTE 352M
Output Impedance: 75 Ohms
Output Amplitude: 800mVp-p +/-10%
Overshoot: <5% (typ.)
Rise/Fall Time: <135 ps (20-80%)
DC Offset (AC coupling): 0V +/-0.5V (typical)
Jitter: <67 ps (typical)
Timing Adjustment for the Output Range: anywhere in the frame
Resolution: clock resolution 6.75 ns (1/148.5 MHz)
Return Loss:
>15 dB from 5MHz to 1.485 GHz
>10 dB from 1.485 to 2.97 GHz TRIGGER OUTPUT
Output Format: 148.5MHz clock
Output Impedance: 50 Ohms
Output Amplitude: 800mVp-p +/-10%
Return Loss: >15 dB from 10 to 300MHz | | Power | 100W | | Dimensions (HxWxD) | 1.73 x 22 x 19" (44 x 559 x 483mm) | | Weight | 18 lbs (8.2kg) |
