Product description The WFM2300DBE Dolby E Analysis Software Upgrade for WFM2300 Waveform Monitor from Tektronix includes Metadata display, peak level indication, and Dolby E timing measurement. The Dolby E test signals user-configurable parameters include: Tone (-18 dB, -20 dB and Multitone), Configuration (8x1 mono, 4x2 stereo, surround 5.1, 5.1+2 and 7.1), Metadata, and Dolby E audio frame start location. This software features Dolby E Guard Band meter with user-defined limits, Dolby E test stream generation for embedded and AES output. The Dolby Status display gives an in-depth view of discrete audio or VANC metadata and Dolby E Guard Band timing and synchronization. User-configurable thresholds for the Dolby E Guard Band timing measurement are available as well as triggering alarms based on their specific guard band parameters. The peak level data in the Dolby metadata is also displayed as a bar graph for checking the presence of the signal. In addition, the DBE upgrade supports Dolby E audio generation, which provides easy access to Dolby E audio reference and test signals within modern broadcast facilities. Table of Contents
|
