Product description The WVR4000 Multi-Standard Multi-Format Waveform Rasterizer from Tektronix is a solution designed to provide basic audio and video monitoring support. It is housed in a 1RU half-rack chassis. This model supports SD-SDI (ITU-R BT.601) only.
This unit offers sharp CRT-like traces, patented gamut displays, picture thumbnails, display freeze, and an error log for 10,000 events. Its user interface features backlit buttons and online help. Commonly used configurations can be programmed and recalled at will with the unit's (32) presets. These preset configurations can even be transferred between units using the device's front-panel USB port.
Passive loop-through inputs allow for transparent monitoring at any point of the signal path, even if the instrument is powered down. It also includes an Ethernet port to facilitate downloading screen shots and error logs. - Multi-Format Measurement and Monitoring
- Use this unit to monitor SD-SDI signals.
- Ports
- It includes a USB and Ethernet port to facilitate data transfer.
- Preset Configurations
- The unit will accommodate up to (32) presets to instantly recall common configurations.
- Advanced Display & Control Parameters
- Multiple display and control parameters allow you to customize the unit to meet your exact needs.
In the Box Tektronix WVR4000 Multi-Standard Multi-Format Waveform Rasterizer Rasterizer Limited Lifetime Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Tektronix WVR4000 Multi-Standard Multi-Format Waveform Rasterizer in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersTektronix WVR4000 Specs | Inputs | Inputs: (2) SD-SDI (ITU-R BT.601), (only one active at a time)
Input types: passive loop-through BNC, 75 Ohms compensated | | Power | 12VDC in, 100 to 240VAC, +/-10%, 50/60Hz | | Dimensions (HxWxD) | 1.7 x 8.1 x 18" (4.32 x 20.57 x 45.72cm) | | Weight | 3.12 lbs (1.7kg) |
