User Manual for Teradek Cube 306 HD-SDI Decoder with OLED Display, External USB Port, and PoE Click to enlarge the picture
Contents of the user manual for the Teradek Cube 306 HD-SDI Decoder with
- Product category: Wireless Transmission Systems Teradek
- Brand: Teradek
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Teradek Wireless Transmission Systems
|
User manual for the Teradek Cube 306 HD-SDI Decoder with contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Teradek product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Teradek user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Teradek product will considerably shorten its lifespan!
|
Product description The Cube 306 HD-SDI Decoder from Teradek is a video decoder that outputs high-definition video via HD-SDI for use with video switchers and professional monitors. This device decodes IP video from Teradek encoders via Ethernet and includes many of the same features of the original Cube such as a compact aluminum chassis and low power requirements. This device can also be powered over Ethernet (PoE). - Built-in video scaler and deinterlacer
- Web UI for configuration and control
- OLED LCD display with joystick navigation buttons
- Powered USB 2.0 host port
UPC: 854980006701 In the Box Teradek Cube 306 HD-SDI Decoder with OLED Display, External USB Port, and PoE 110 to 240V AC Power Adapter SDI Cable Ethernet Cable Hot Shoe Adapter with Thumbscrew Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Teradek Cube 306 HD-SDI Decoder with OLED Display, External USB Port, and PoE in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersTeradek 10-0306 Specs | Video Outputs | HD-SDI, SD-SDI: BNC | | Supported Resolutions | 1080i 50/59.94/60
1080p 23.98/24/25/30
1080PsF 23.98/24/25
720p 50/59.94/60
576i
480i | | Video Compression | Baseline, Main, and High Profile H.264 | | Video Bit Rate | 250 kbps to 10 Mbps | | Network Protocols | TCP/IP, UDP, HTTP, DHCP, NTP, SSL, IGMP | | Transport Protocols | RTP, RTSP, RTP over HTTP, MPEG-TS (optional paid license), Zixi (optional paid license) | | Audio Compression | AAC-LC, MPEG Layer 2 | | Audio Output | Embedded | | Ethernet | 10/100BASE-T | | Power Input | 6 to 28 VDC via 2-pin LEMO
36 to 57 VDC via PoE | | Power Consumption | Nominal: 3 W | | Dimensions | 2.5 x 3.5 x 0.9" (6.4 x 8.9 x 2.3 cm) | | Weight | 8 oz (227 g) | | | | Package Weight | 1.75 lb | | Box Dimensions (LxWxH) | 6.6 x 6.5 x 4.1" |
