Product description The Theia Technologies CS-Mount 9-36mm f/1.5-close Motorized Auto-Iris Telephoto 4K Varifocal Lens is designed of use with 1/3”, 1/2.7” HD, 1/2.5”, and 1/2.3” 4K sensors. It offers 4x zoom and focal length of 9-36mm for long reach and field of view optimization. - 5MP resolution for demanding applications
- Compact design (< 50mm TTL) to fit into domes as small as 4" mini-dome size
- Motorized zoom, focus, and iris
In the Box Theia Technologies CS-Mount 9-36mm f/1.5-close Motorized Auto-Iris Telephoto 4K Varifocal Lens Limited 2-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Theia Technologies CS-Mount 9-36mm f 1.5-close Motorized Auto-Iris Telephoto 4K Varifocal Lens in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersTheia Technologies TL936AR3 Specs | Focal Length | 9-36mm | | Resolution | 5 MP | | Aperture | F/1.5-close | | Focus Range | 8.2' to infinity (2.5 m to infinity) | | Range | CS Mount Slip Range: 320° | | Field of View | 1/3": 30 to 7.7° (horizontal), 22 to 5.8° (vertical), 38 to 9.6° (diagonal)
1/2.7" HD: 37 to 9.3° (horizontal), 20 to 5.1° (vertical), 42 to 10.6° (diagonal)
1/2.5" : 36 to 9.2° (horizontal), 27 to 6.9° (vertical), 46 to 11.5° (diagonal)
1/2.3" 4K: 39 to 10° (horizontal), 19 to 5° (vertical), 44 to 11° (diagonal) | | Zoom/Focus | Drive: Stepper motor
2 phase bipolar drive
Operation Voltage: 3.3 V
Operating Range: 2.6 to 4.8 V
Maximum Continuous Operation Time (seconds) for Operation Voltage and Ambient Temperature:
@ 68°F (20°C): 60 sec (3.3 V), 12 sec (4 V), 6 sec (4.8 V)
@ 104°F (40°C): 35 sec ((3.3 V), 9 sec (4 V), 5 sec (4.8 V)
@ 140°F (60°C): 20 sec (3.3 V), 6 sec (4 V), 4 sec (4.8 V)
Coil Resistance: 28.5 Ohms ±7%
Gear Ratio: 1:2308
Zoom Speed: 3 sec (@ 1000 pps
Zoom Cam Rotation: 57°
Focus Speed: 8.5 sec (@ 600 pps
Focus Cam Rotation: 100°
Focus/Zoom Connectors: Housing: Molex 51021-0800
Terminal: Molex 50058-8000
Cable Length: 5.9" (150 mm) | | Auto Iris Control | Drive: DC
Operation Voltage: 3 V (2.5 to 5 V)
Maximum Current Consumption: 26 mA
Drive Coil Resistance: 190 Ohms ±10%
Damper Coil Resistance: 855 Ohms ±7%
Connector Type 2 (CCTV)
Connector Type: Housing: EYC 221
Cable Length: 11.8" (300 mm) | | Operating Temperature & Humidity | -4 to 140°F (-20 to 60°C)
Humidity: < 70%, non-condensing | | Storage Temperature & Humidity | -4 to 158°F (-20 to 70°C)
Humidity: < 90%, non-condensing | | Dimensions (Ø x L) | 2.12 x 1.9" (54 x 49.4 mm) | | Weight | 2.43 oz (69 g) | | | | Package Weight | 0.25 lb | | Box Dimensions (LxWxH) | 3.9 x 2.4 x 2.1" |
