User Manual for Toa Electronics M-633D Digital Stereo Mixer Click to enlarge the picture
Contents of the user manual for the Toa Electronics M-633D Digital Stereo Mixer
- Product category: Install Sound Mixers Toa Electronics
- Brand: Toa Electronics
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Toa Electronics Install Sound Mixers
|
User manual for the Toa Electronics M-633D Digital Stereo Mixer contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Toa Electronics product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Toa Electronics user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Toa Electronics product will considerably shorten its lifespan!
|
Product description The M-633D Digital Stereo Mixer from TOA Electronics is a compact, easy-to-use digital audio mixer, designed for Live and AV sound applications. The M-633D's straightforward analog interface is engineered to make setup and operation fast and efficient. With powerful, automatic on-board DSP, the M-633D eliminates problematic acoustics and feedback, and helps optimize sound quality for most venues. Multiple outputs provide flexibility for operation in several zones, and allow recording of the main mix signal. Its complement of inputs makes it suitable for live performance, houses of worship, conferences, and banquet events, all of which utilize microphones and music playback or other auxiliary audio sources.
The M-633D provides automatic audio with pushbutton simplicity. You don't have to be a sound technician to operate it and there's no need for complex PC settings and adjustments. The mixer features Automatic Resonance Control, feedback suppression, and Automatic Clipguard functions to simplify operation, all while providing professional sounding results. This all comes packed in a minimized footprint, 1 RU-sized unit. - Digital audio with 24 bit 48 kHz A/D & D/A
- 1U Rack size digital mixer with 12 inputs and 6 outputs
- No PC setting required for operation
- Versatile 2 Mono, 1 Stereo (Phoenix), and 1 Recording (RCA) outputs
- Easy analog user interface and no PC setting is required
- Intelligent Feedback Suppressor (FBS)
The M-633D automatically suppresses sudden feedback that can occur when the person holding the microphone moves around and into the playback proximity of speakers - Auto-muting of line input sources via priority mic inputs
- Output zone assignments accessed from the front panel
- 2-Color LED input and output level indicators
In the Box Toa Electronics M-633D Digital Stereo Mixer Security Cover Power Cord (6.6') Table of Contents
|
Upload User Manual
Have you got an user manual for the Toa Electronics M-633D Digital Stereo Mixer in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersToa Electronics M-633D Specs | Inputs | 6 Mono Input Channels, switchable LINE, MIC or Phantom
LINE: -10 dB, 2.4 k ohms
MIC : -46 dB, 2.4 k ohms
Phantom: -46 dB, 2.4 k ohms, +24V DC, electronically balanced
3 Stereo Inputs (L, R)
-10 dB / 10 kOhms, RCA jack, stereo mini jack | | | | Outputs | 2 Mono Outputs
0 dB, electronically balanced, removable terminal block (3 pins)
1 Stereo Output (L, R)
1 Stereo Recording Output (L,R)
-10 dB, RCA jack | | Bus Line | Monaural Channel x 2
Stereo Channel x 1 | | Frequency Response | 20 Hz to 20 kHz | | Digital Sampling | Frequency: 48 kHz / 24 bits | | Dynamic Range | 90 dB or more (IHF-A weighted) | | Signal Processing | Automatic Resonance Control (ARC)
Feedback Suppressor (FBS)
Automatic Clipguard (ACG)
Automatic Mute | | | | Color | Black | | Material | Steel | | Dimensions (W x H x D) | 16.5 x 1.7 x 13.4" (420.0 x 44.0 x 341.3 mm) | | Weight (Approximate) | 8.8 lb (4.0 kg) | | | | Package Weight | 12.6 lb | | Box Dimensions (LxWxH) | 22.835 x 20.472 x 3.937" |
