User Manual for Toa Electronics VP-2064 4 x 60W Power Amplifier Click to enlarge the picture
Contents of the user manual for the Toa Electronics VP-2064 4 x 60W
- Product category: 70-Volt Amplifiers Toa Electronics
- Brand: Toa Electronics
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Toa Electronics 70-Volt Amplifiers
|
User manual for the Toa Electronics VP-2064 4 x 60W contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Toa Electronics product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Toa Electronics user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Toa Electronics product will considerably shorten its lifespan!
|
Product description The VP-2064 Power Amplifier from Toa Electronics is part of the SX-2000 Series Audio Management System. The amplifier features four channels of 60W each and a signal-to-noise ratio of 80 dB or more. The front Panel has LED indicators for power and overheating. In the Box Toa Electronics VP-2064 4 x 60W Power Amplifier (2 RU) 4 x Rack Mounting Screws 4 x Fiber Washers Limited 5-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Toa Electronics VP-2064 4 x 60W Power Amplifier in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersToa Electronics VP-2064 Specs | Number of Channels | 4 | | Input | 4 x RJ45 port, Link (Input module VP-200VX) | | Output | Power amplifier output (speaker line)
M3.5 screw terminal, 8.8 mm between barriers | | Frequency Response | 40 Hz - 16 kHz, ±3 dB (at 1/3 rated output) | | Distortion | 1% or less (at rated output, 1 kHz) | | S/N Ratio | 80 dB or more | | Power Source | 28 VDC (operating range: 20 - 40 VDC)
M4 screw terminal, 12 mm between barriers | | Current Consumption | 4.8 A | | Output Power | 4 x 60 W
AC Mains: 195.5 V, 4 x 45 W | | Output Voltage | 100 V | | Resistance | Minimum Resistive Load:
167 Ohms at 100 V
83 Ohms at 70 V
41 Ohms at 50 V | | Maximum Capacity | 0.125 µF at 100 V
0.25 µF at 70 V
0.5 µF at 50 V | | LEDs | 4 x Dual color Power indicators (one per channel)
1 x Yellow Overheat indicator | | Operating temperature | 32 to 104°F (0 to 40°C) | | Finish | Black surface-treated steel plate, 30% gloss | | Dimensions | 19.0 x 3.5 x 13.4" (48.2 x 8.8 x 34.1 cm) | | Weight | 24.7 lb (11.2 kg) |
