TP-Link EAP225 Ceiling-Mount Access Point Kit

User Manual for TP-Link EAP225 Ceiling-Mount Access Point Kit with TL-SF1008P 8-Port Desktop Switch

• Product category: Wireless Access Points TP-Link
• Brand: TP-Link
• Description and content of package
• Technical information and basic settings
• Frequently asked questions – FAQ
• Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
• Authorized service for TP-Link Wireless Access Points

Product description

• 2 x TP-Link EAP225 AC1350 Wireless Dual-Band Gigabit Ceiling Mount Access Point The EAP225 AC1350 Wireless Dual-Band Gigabit Ceiling Mount Access Point from TP-Link lets you extend your wireless network's coverage throughout the office. It has a low profile, easy mount design, which lets you install it on the ceiling or onto a wall. Featuring dual-band 802.11ac connectivity, you'll be able to transfer data at speeds of up to 867 Mb/s on the 5 GHz band and 450 Mb/s on the 2.4 GHz band. This device is PoE-compatible and can be used together with the EAP Controller Software to manage connected devices and guest access.
  • • 1317 Mb/s wireless data rate for an uninterrupted wireless connection
    • Free controller software for easy centralized management of hundreds of EAPs
    • Supports Power over Ethernet (802.3af) and passive PoE (adapter included) for convenient and affordable installation
    • The captive portal provides one convenient method of authentication for Wi-Fi guests
    • The simple mounting design makes easy to install on any wall or ceiling surface
    • Rate limit on per SSID to restrict the bandwidth of each client
    • Load balance ensures large numbers of users have smooth network experiences in high-density business networks
    • Band Steering Automatically moves dual-band devices onto the wider 5 GHz band for faster connections
    • MU-MIMO means access points simultaneously transfer data with multiple devices, speeding up connections
    • Beamforming concentrates signal towards where you need it most, providing a fast and stable Wi-Fi experience
    • Access Control restricts or only allows the client to access the specified network segment
    • Schedules can be set so access points automatically reboot and Wi-Fi turns on/off at the times you choose
    • Multi-SSID divides multiple wireless networks for different users
    • Compatible with 802.11a/b/g/n/ac products
    • Multiple operating modes including managed AP and standalone AP satisfy different application conditions
    • QoS function gives video and voice streams higher priority to promote smoother performance for video and voice services
  UPC: 845973093006
• TP-Link TL-SG1008P 8-Port Gigabit Desktop Switch with 4-Port PoE The TP-Link TL-SG1008P Gigabit Desktop Switch is an eight 10/100/1000 Mb/s port unmanaged switch that requires no configuration and provides 4 PoE (Power over Ethernet) ports. It can automatically detect and supply power with all IEEE 802.3af compliant PDs (Powered Devices). In this situation, the electrical power is transmitted along with data in one single cable, allowing you to expand your network to where there are no power lines or outlets, where you wish to connect devices such as APs, IP cameras, IP phones, and more.
  Power Over Ethernet
  • Four of the 8 auto-negotiation RJ-45 ports (port 1 to port 4) of the switch support PoE (Power over Ethernet) function. These PoE ports can automatically detect and supply power with the IEEE 802.3af compliant PDs (Powered Devices). Supports PoE power up to 15.4W for each PoE port, a total of up to 53W for all PoE ports, and supports priority function to protect the system when the system power is overloaded.
  Overload Arrangement
  • Features priority function which will help protect the system when the system power is overloaded. If all PoE PDs power consumption is 53W a priority will be arranged among the PoE ports, and then the system will cut of the power of the lowest-priority port.
  Port Priority Function
  • Priority (port 1 > port 2 > port 3 > port 4): This function will help protect the system if the system power becomes overloaded. For example, Port 1, 2, and 4 are using 15.4W (maximum power per port is 15.4W), the system power is 46.2W in total (PoE max LED is red). If there is an additional PD inserted to port 3 with 10W, then the system will cut of port 4 to protect the system, this means ports 1 and 2 will use 15.4W, and port 3 will use 10W, and no power will be supplied to port 4.
  High Performance
  • Features Auto-MDI/MDIX, auto-negotiation, store and forward, IEEE 802.3x flow control for Full-duplex Mode, back pressure for half-duplex mode, and 8K MAC address auto-learning and auto-aging.
  Easy To Use
  • It requires no configuration and installation. With desktop design, outstanding performance, and quality, this switch is a great selection for expanding your home or office network. It has a plug-and-play and fanless design.
  Additional Features
  • Supports flow control, back pressure, and fanless operation.
  UPC: 845973021160

• 2 x EAP225 AC1350 Wireless Dual-Band Gigabit Ceiling Mount Access Point ywrwqyfvzyaaxcysvesszzuxxq
• Passive PoE Adapter
• Power Cord
• Mounting Kits
• Limited 5-Year Warranty

• TL-SG1008P 8-Port Gigabit Desktop Switch with 4-Port PoE

Upload User Manual

Please enter here the link to the user manual of this product: OR Enter here the file with the user manual of this product from your computer/phone: (60MB max; Permitted formats: PDF) 0%

Technical parameters

• 2 x TP-Link EAP225 AC1350 Wireless Dual-Band Gigabit Ceiling Mount Access Point

  Interface	1 x Gigabit Ethernet (RJ-45) port (Supports 802.3af PoE and Passive PoE)
  Button	Reset
  Power Supply	802.3af PoE and passive PoE
  Power Consumption	12.6 W
  Antenna Type	3 x Internal omni 2.4 GHz: 4 dBi 5 GHz: 5 dBi
  Mounting	Ceiling/wall mounting (kits included)
  Security Lock Slot	Yes
  Watch Dog Timer	Yes

  Wireless Standards	IEEE 802.11a/b/g/n/ac
  Frequency	2.4 GHz, 5 GHz
  Signal Rate	5 GHz: Up to 867 Mb/s 2.4 GHz: Up to 450 Mb/s
  Wireless Functions	Multiple SSIDs (Up to 16 SSIDs, 8 for each band) Enable/disable wireless radio Automatic channel assignment Transmit power control (Adjust transmit power on dBm) QoS (WMM) MU-MIMO Airtime fairness Beamforming Band steering Load balance Rate limit Reboot schedule Wireless schedule Wireless statistics based on SSID/AP/client
  Wireless Security	Captive portal authentication Access control Wireless Mac address filtering Wireless isolation between clients SSID to VLAN mapping Rogue AP detection 802.1X support
  Transmit Power	CE ≤20 dBm (2.4 GHz, EIRP) ≤23 dBm (5 GHz, EIRP) FCC ≤24 dBm (2.4 GHz) ≤22 dBm (5 GHz)

  Access Point Management	EAP controller software Email alerts LED on/off control Management MAC access control SNMP System logging, local/remote syslog Telnet Web-based management L3 management Multi-site management Management VLAN

  Certifications	CE, FCC, RoHS
  System Requirements	Microsoft Windows XP, Vista, 7, 8, and 10 Linux
  Temperature & Humidity	Operating Temperature 32 to 144°F / 0 to 60°C Storage Temperature -40 to 158°F / -40 to 70°C Operating Humidity 10 to 90% non-condensing Storage Humidity 5 to 90% non-condensing
  Dimensions	8.1 x 7.1 x 1.5" / 205.5 x 181.5 x 37.1 mm
  Weight	Not specified by manufacturer

  Box Dimensions (LxWxH)	16.3 x 13.45 x 2.65"

• TP-Link TL-SG1008P 8-Port Gigabit Desktop Switch with 4-Port PoE

  Ports	4 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45) 4 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45) PoE (Type 1)

  Transmission Method	Store-and-Forward
  MAC Address Table Size	8K

  Supported IEEE Standards	802.3, 802.3ab, 802.3af, 802.3u, 802.3x

  Switching Bandwidth	16 Gb/s

  OS Compatibility	Windows XP or Later Linux macOS

  Power Draw	58.8 W (Active)

  Operating Temperature	32 to 104°F / 0 to 40°C
  Operating Humidity	10 to 90%
  Storage Temperature	-40 to 158°F / -40 to 70°C
  Storage Humidity	5 to 90%

  Indicator Lights	Link/Activity, PoE, Power, Speed
  Dimensions	6.7 x 3.9 x 1.1" / 17.1 x 9.8 x 2.8 cm

  Box Dimensions (LxWxH)	11.0 x 8.9 x 2.6"
