Product description The 6" CineMonitorHD6 eSBL Classic Enhanced SuperBright On-Board Monitor from Transvideo features 1,000 nits brightness and an anti-glare sunlight readable screen. The 4:3 screen is partitioned in 2 areas: the picture zone displays the picture in 16:9 format whereas tools and measurements are displayed in the remaining free area of the screen.The CineMonitorHD6 eSBL Classic can be set in 2 operating modes either for outdoor viewing or color monitoring. In Full Bright mode (for outdoor viewing), details in both the dark areas and highlights are maintained even in bright sunlight without the hood. Featuring RealFrameRate technology, the on-board monitor provides true monitoring of existing in-camera images with 1-frame delay or less. The monitor displays clear images without aliasing or motion blur.The monitor offers a basic set of features including markers, user framelines, on-screen Tally, overexposure control, and horizon leveler. In addition, this rugged monitor features a precision machined aluminum housing that is fully sealed (devoid of holes and fans). Inputs / Outputs - HD/SD SDI, Composite Video, YPrPb, and RGB
Measurements and Exposure Monitoring - Multiple waveforms-Y, R, G, B, YRGB (3 sizes: small, medium, full screen)
- Histogram and vectorscope
- User adjustable false colors
Color, Gammas, and Display Adjustments - Factory color calibration preset D56/D65
- Brightness, contrast, saturation, hue
- Color, black & white, and green modes as well as blue check
Tools - Markers (safe area, 4:3 and 14/9)
- Crosshair and user framelines
- Tri-color LED and multiple on-screen Tally configurations
- Image flip (horizontal and vertical) & monitor reverse
Power In the Box Transvideo 6" CineMonitorHD6 eSBL Classic Enhanced SuperBright On-Board Monitor 2 x Shoulder Strap Pin Bottom Slide 4.5 GHz 3G-SDI BNC to BNC Cable (3.3') Screen Protective Cover Microfiber Cloth and Bag Pelican Case with Custom Shaped Foam Limited 2-Year Warranty on Parts & Labor Note: The warranty can be extended to 3 years on registration of the product on the Transvideo website. Table of Contents
|
Upload User Manual
Have you got an user manual for the Transvideo 6" CineMonitorHD6 eSBL Classic Enhanced SuperBright On-Board Monitor in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersTransvideo HD6 eSBL Specs | | | Display Size & Type | 6.0" (15.2 cm) AMLCD | | Pixels | Picture Zone: 1024 x 576 | | Luminance | 1,000 nits | | Contrast Ratio | Maximum 600:1 | | Viewing Angle | ±80° H, +60/-80° V | | White Point Calibration | D65 ITU-R BT.709-5 & D56 | | Color Space | Rec. ITU-R BT.709-5 | | | | Video Inputs | 1 x HD/SD SDI + 1 Rclk out (BNC)
1 x multi YPrPb / RGB / CVBS (LEMO8) | | Supported Video Standards | 1080p / 1080i / 1080psf
720p / SD SDI 525 / 625
NTSC (M, J, 443) / PAL (M, BG, N) / SECAM | | | | Power Input Connector | XLR4 connector (-1, +4), with galvanic insulation | | Power Consumption | 10 to 36 VDC / 14 W | | Temperature | Storage: -40 to 176°F (-40 to 80°C)
Operating: -4 to 13° F (-20 to 55°C) | | Dimensions | 7.7 x 6.6 x 2.4" (195.6 x 167.6 x 70.0 mm) | | Weight | 3.1 lb (1.4 kg) |
