Product description This step-up from the smaller TA44, the Trijicon 2x20 TA47 ACOG Riflescope maintains a compact form-factor but with an extra 0.5x magnification and larger objective to allow users the ability to identify and detect targets to as much as 215yd (200m). Its compact design makes this an ideal optic for smaller platforms such as UZI, H&K, or MP-5 9mm sub-machine guns.The TA47 features tactical hand-adjustable windage and elevation turrets, and a battery-free illuminated reticle to create a versatile weapon sight that is well-suited for use in a wide range of situations and conditions. This Advanced Combat Optical Gunsight (ACOG) sight was designed for use with the both-eyes-open Bindon Aiming Concept for superior sense of balance and a wider field-of-view, and is outfitted with an 6.9 MOA red dot reticle that enables fast sighting and tracking for CQB operations and precise shot placement at distance. Anti-reflection broadband fully multicoated optics maximizes light transmission to provide bright and clear views with limited distortion.Trijicon's battery-free dual-illumination reticle system employs a tritium phosphor lamp for low-light and night targeting, as well as a fiber optic illumination that focuses, channels, and filters available light to illuminate the reticle. Using ambient light ensures that the reticle brightness will be appropriate for the conditions without any adjustment by the user. The reticle's aiming point can be adjusted in 1/2 MOA increments, and an internal adjustment mechanism allows the ACOG to reliably hold zero. Complementing the ACOG's optical and illumination systems is a nitrogen-filled, 7075-T6 aluminum housing with a corrosion and scratch-resistant matte black anodized finish that provides the durability needed for reliable performance in a wide range of conditions. - Optical Performance
-
- 2x low magnification
- 20mm objective lens
- Broad-band multicoated lenses enhance clarity and increase light transmission by minimizing flare, glare, reflections, and distortion
- 29' field of view at 100 yd
- 5.6° actual angle of view
- Reticle Details
-
- Dual-illuminated 6.9 MOA red dot reticle
- Center aiming dot
- Partially illuminated post on lower vertical axis
- Dual illumination system: Battery-free tritium and fiber-optics
- Tritium isotope: Interacts with a phosphors membrane to create illumination for the reticle in low or no light
- Fiber optics: Focuses, channels, and filters ambient light to illuminate the reticle
- Use and Handling
-
- 1/2 MOA per click impact point correction
- ±40 MOA windage/elevation adjustment range
- Tactical tool-free adjustment turrets
- Designed for use with the both-eyes-open Bindon Aiming Concept for superior sense of balance and a wider field-of-view
- 2.1" eye relief
- 10mm exit pupil
- Construction Details
-
- 7075-T6 aluminum alloy housing
- Nitrogen-filled for fogproof and waterproof performance
- Waterproof to 328' (100m)
- M16 carry-handle mount: Designed for M16/AR-15 platforms - screw and washer set included
- Shock-resistant: Tested to withstand recoils on weapons from .22 LRs up to .50 BMGs
- Lightweight: Weighs just 6.4 oz
- Made in the USA
UPC: 719307309562 In the Box Trijicon 2x20 TA47 ACOG Riflescope (6.9 MOA Red Dot Reticle) Screw & Washer Set for ACOG (Matte Black) esduqyebyxbwcbxeruuxavfsacfzxdswturw ACOG Scopecoat LensPen - TA56 Trijicon Sticker Limited Lifetime Warranty Limited 15-Year Warranty Table of Contents
|
