User Manual for TV One CORIOview 4-window 3G-SDI Processor Click to enlarge the picture
Contents of the user manual for the TV One CORIOview 4-window 3G-SDI Processor
- Product category: Multiviewer Processors TV One
- Brand: TV One
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for TV One Multiviewer Processors
 |
User manual for the TV One CORIOview 4-window 3G-SDI Processor contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any TV One product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official TV One user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a TV One product will considerably shorten its lifespan!
|
Product description The TV One CORIOview C2-6204 4-window 3G-SDI Processor is a multi-window video processor that allows display of up to 4 substantially sized windows on a single DVI-I or 3G-SDI output. Four, high performance CORIO2 Scaling Engines power the 4 windows respectively, providing complete PIP flexibility. CORIO2 is a proprietary technology integrated into chipsets to allow for freedom from constraints imposed by third-party chipsets. Conditions of obsolescence can be eliminated as firmware can be upgraded from the support website. Four 3G-SDI inputs are sustained by the exclusive CORIO2 technology while the fifth DVI-I input is reserved only for reference, background usage or cascading of multiple units. Four internal still image stores are incorporated into the CORIOview C2-6204 Processor, each allowing the display of one of ten user loadable images in place of an input. DVI-D resolution of 1920x1200@60Hz and 1080p, along with a DVI-A analog resolution of 2048x2048@60Hz is possible at any refresh rate. A wide range of analog inputs such as RGBHV/RGBS/RGsB/YPbPr are supported by the CORIOview C2-6204 4-window 3G-SDI Processor, providing a high measure of flexibility. Ten user defined presets, accessible and directly controllable from the front panel, allow easy customization of settings for a variety of applications. Wide source input compatibility is possible due to high performance de-interlacing and motion-adaptive noise reduction. Variable zoom/shrink feature allows the graphic image to be enlarged up to 10X or to be shrunk to 10% to fit multiple images together. Advanced features such as Genlock, Chromakey, Lumakey, and Mixing are incorporated into the C2-6204 which also offers a Key mode allowing windows to be keyed over one another with variable priority or layer control. - Custom 4-window processor allows display of 4 substantially sized windows on a single DVI-I output
- 4 high quality CORIO2 scaling engines power the 4 image windows respectively, providing complete PIP flexibility
- CORIO2 - proprietary technology integrated into chipsets to allow for freedom from constraints imposed by third-party chipsets
- Conditions of obsolescence are eliminated as firmware can be upgraded from the support website
- Includes 4 3G-SDI inputs sustained by CORIO2 technology
- 5th DVI-I input reserved for reference, background usage or cascading of multiple units
- 4 internal still image stores allow the display of one of ten user loadable images in place of an input.
- DVI-D resolution of 1920x1200@60Hz and 1080p
- DVI-A analog resolution of 2048x2048@60Hz
- Supports wide range of analog inputs such as RGBHV/RGBS/RGsB/YPbPr
- Ten user defined presets, accessible and directly controllable from the front panel, allow easy customization of settings for a variety of applications
- Wide source input compatibility possible due to high performance de-interlacing and motion-adaptive noise reduction
- Offers advanced features such as Genlock, Chromakey, Lumakey, and Mixing
- Key mode allows windows to be keyed over one another with variable priority or layer control
In the Box TV One CORIOview 4-window 3G-SDI Processor 6' (2m) AC Power Cord VGA to DVI Adapter (ZDH-2040) BNC to DVI Adapter (ZDC-2050) Operations Manual Rackmount Kit (2 ears and 4 screws) Control Software (downloadable from website) 1 Year Parts & Labor Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the TV One CORIOview 4-window 3G-SDI Processor in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersTV One C2-6204 Specs | Inputs | Signal Type:
- 4x 3G-SDI via BNC Connector
- 1 x DVI-I via DVI Connector
SDI Format 3G, HD, SD-SDI (auto detect):
- SD-SDI (SMPTE 259M-C)
- HD-SDI (SMPTE 392M)
- 3G-SDI (SMPTE 425M-A)
Max Resolution (with re-clocked loop through): 1920x1080p@60Hz
Digital DVI-D Format:
- Max HD Resolution 1920x1080p@60Hz
- Max PC Resolution 1920x1200@60Hz Reduced blank
Analog DVI-A Format:
- Max HDTV Resolution: 1080p@60Hz
- Max PC Resolution: 2048x2048
- Max Horiz Scan Rate: 150KHz
- Signal Format: RGBHV, RGBS, RGsB, YPbPr
- Sync: TTL Level, 10KOhm, Pos or Neg
- Termination: 75Ohm
- R-G-B Level Range: 0.5-2.0 Vp-p
- Scan Rate Detection: Automatic | | Output | Signal Type:
- 1x DVI-I via DVI-I Connector
- 1x 3G-SDI via BNC Connector
SDI Format: 3G, HD, SD-SDI:
- SD-SDI (SMPTE 259M-C)
- HD-SDI (SMPTE 292M)
- 3G-SDI (SMPTE 425M-A)
Digital DVI-D Format:
- Max HD Resolution: 1080p@60Hz
- Max PC Resolution: 1920x1200@60Hz
Analog DVI-A Format:
- Max HDTV Resolution: 1080p@60Hz
- Max PC Resolution: 2048x2048
- Vertical Refresh Rate: Any to 250Hz
- Signal Format: RGBHV, RGBS, RGsB, YPbPr
- R-G-B Level: 0.7 Vp-p | | General | Size and Position: Automatic via AutoSet or Manual
Image Size: User-Definable Presets
Image Freeze: One Video Frame
Settings Memory: Non-Volatile
Shrink Range: Variable to 10%
Image Mirroring: Horizontal and/or Vertical
Zoom Range: Variable to 10X Zoom
Horizontal Filtering: Full Digital
YPbPr de-interlacing: Motion adaptive + noise reduction
Film Mode (525i/1080i): 3:2 Pull Down Detection
Conversion Technology: Proprietary - CORIO2
Frame Rate Conversion: Frame add/drop
Color Resolution: 24-bit (16.8 Million Colors)
Sampling Rate: 162MHz
Digital Sampling: 24-bit, 4:4:4 format
Firmware Memory: Flash, Upgradeable via RS-232
Analog Video Adjust: R-G-B Levels Contrast, Phase | | Control | Local: via Front Panel Buttons & LCD
RS-232/RS-485/RS-422: via D9 Female Connector
Ethernet (TCP/IP): RJ45 | | Compliance | Main Units: FCC, CE, RoHS
Power Supply: UL, CUL, CE, PSE, GS, RoHS | | Dimensions (HxWxD) | Desktop Case: 1.75 x 17 x 7.9" (44 x 420 x 200mm)
With Rack Ears: 1.75 x 19 x 7.9" (44 x 482 x 200mm | | Environmental | Operating Temperature: 32 ~ 122°F (0 ~ 50°C)
Operating Humidity: 10 ~ 85%, Non-condensing
Storage Temperature: 14 ~ 158°F (-10 ~ 70°C)
Storage Humidity: 10 ~ 85%, Non-condensing | | Power Requirements | Internal Power Supply: 100-240VAC, 50-60Hz, 50W | | Weight | 6.8 lbs (3.1kg) | | | | Package Weight | 10.6 lb | | Box Dimensions (LxWxH) | 22.9 x 18.5 x 4.8" |
