User Manual for Vaddio EasyUSB MicPOD I O Interface Click to enlarge the picture
Contents of the user manual for the Vaddio EasyUSB MicPOD I O Interface
- Product category: Automated Camera Components Vaddio
- Brand: Vaddio
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Vaddio Automated Camera Components
|
User manual for the Vaddio EasyUSB MicPOD I O Interface contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Vaddio product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Vaddio user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Vaddio product will considerably shorten its lifespan!
|
Product description The Vaddio EasyUSB MicPOD I/O Interface is based on Vaddio’s SmartMIC technology, a simple approach to adding live audio conferencing to room designs. As an interface between the EasyUSB Mics and any professional audio mixer, internal DSP and echo cancellation can be integrated into any manufacturer’s audio mixing system.
Each EasyUSB SmartMIC is equipped with an array of three electric condenser microphones positioned to form a 360° pickup pattern. This technology is based on the microphone’s ability to actively manage the room’s live audio for gain, gating, and echo cancellation. Once detected, the microphone adjusts and mixes down to a single output. Because the intelligence is inside the microphone, any mixer can now be used in a live collaboration application for audio conferencing and achieving optimal results.The I/O interface device allows the connection of up to four SmartMICs, and because each input is effectively running three microphones on three different channels, users can technically run 12 microphones all with independent echo cancellation and internal DSP. Note: For installations requiring more than 12 SmartMICs, just add an additional EasyUSB MicPOD I/O for 12 more channels. - Four-channel EasyUSB microphone interface with AEC Reference Input and four balanced line outputs.
- Interface device between EasyUSB SmartMICs and any professional conferencing mixer.
- Compatible with TRIO table and ceiling microphone arrays.
- Connect up to four SmartMICs.
- Allows running of 12 mics, all with independent echo cancellation and internal DSP.
In the Box Vaddio EasyUSB MicPOD I/O Interface Power Supply 5 x 3-Position Phoenix Connector 4 x Rubber Foot Limited 2-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Vaddio EasyUSB MicPOD I O Interface in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersVaddio 999-8535-000 Specs | Frequency Response | 20 Hz to 20 kHz | | Dynamic Range | >90 dB | | Line Outputs | 4 x 3-pin Phoenix | | Reference Input | AEC: 1 x 3-pin Phoenix | | Mic Inputs | 4 x RJ45F TRIO proprietary | | Power Supply | 18 VDC, 2.75 A | | Operating Temperature | 32 to 104°F (0 to 40°C)
20 to 80% RH | | Dimensions (W x H x D) | 8.4 x 1.7 x 6.0" (21.3 x 4.3 x 15.2 cm) | | Weight | 1.45 lb (657.7 g) | | | | Package Weight | 3.3 lb | | Box Dimensions (LxWxH) | 16.1 x 9.4 x 3.4" |
