User Manual for ViewSonic XG2703GS 27" 16:9 WQHD 165 Hz IPS Gaming Monitor Click to enlarge the picture
Contents of the user manual for the ViewSonic XG2703GS 27" 16:9 WQHD 165
- Product category: Computer Monitors ViewSonic
- Brand: ViewSonic
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for ViewSonic Computer Monitors
 |
User manual for the ViewSonic XG2703GS 27" 16:9 WQHD 165 contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any ViewSonic product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official ViewSonic user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a ViewSonic product will considerably shorten its lifespan!
|
Product description 10 Factors to Consider When Selecting A Monitor for Video Editing Read More zvuwyzzfcaxvutvxfurxfxrurdxzqys With up to four times the clarity of a traditional 720p monitor, the XG2703GS 27" 16:9 WQHD 165 Hz IPS Gaming Monitor from ViewSonic features a WQHD 2560 x 1440 resolution for enhanced clarity and detail. In addition to the improved resolution, the 16:9 widescreen display supports a 165 Hz refresh rate designed to virtually eliminate tracers and motion blur.
To take your games to the next level, ViewSonic has included both NVIDIA G-Sync and NVIDIA Ultra Low Motion Blur technologies within this monitor. With NVIDIA G-Sync the monitor is synchronized with the frame rate output of your monitor while NVIDIA Ultra Low Motion Blur helps to create smoother movement and sharper edges to reduce on screen blur during fast moving games.
Setup and configuration of the XG2703GS is simple as it comes equipped with both HDMI and DisplayPort inputs along with USB connectivity to plug USB enabled peripherals directly into the monitor. In addition to the WQHD resolution, this ViewSonic display features a 1,000:1 contrast ratio, 4 ms response time, 350 cd/m² brightness rating, and support for up to 16.7 million colors. Once configured, the screen can be viewed from nearly any angle with 178° horizontal and vertical viewing angles while the monitor can be tilted, swiveled, and pivoted into place for optimal viewing comfort. Additionally, this monitor comes with a 3.9" height-adjustment range, or you can mount it on the wall using the VESA mounting pattern on the back. - QHD Resolution
- At four times the resolution of a traditional 720p panel, and almost double that of a traditional 1080p display, WQHD results in a much sharper image, with no distortion or stretching, all while maintaining the same 16:9 aspect ratio. WQHD resolution also provides up to 77% more screen space for a more immersive experience.
- 165 Hz Refresh Rate
- With a swift 165 Hz refresh rate, this monitor delivers greater visual fluidity and awesome graphics no matter how quickly the in-game action unfolds. Say goodbye to annoying tracers and motion blur, and up your A-game with the smoothest visuals possible.
Please note, 165 Hz achieved when using DisplayPort 1.2a connection port - SuperClear IPS Panel Technology
- Enjoy accurate and vivid colors with consistent levels of brightness no matter the vantage point. With SuperClear IPS panel technology, this monitor delivers the same image quality whether you are looking at the screen from above, below, the front, or the side.
- NVIDIA G-Sync Technology
- NVIDIA G-SYNC technology seamlessly synchronizes the frame rate output between your graphics card and monitor. This eliminates screen tearing, and minimizes stutter and input lag for the most breathtaking gameplay experience.
- NVIDIA Ultra Low Motion Blur Technology
- Experience smooth movement and sharp edges in even action-packed gaming scenarios. NVIDIA Ultra Low Motion Blur (ULMB) decreases motion blur and minimizes ghosting when the on-screen action gets heated. Whether you're racing, shooting, or strategizing, the images on screen remain sharp and smooth.
UPC: 766907845815 In the Box ViewSonic XG2703GS 27" 16:9 WQHD 165 Hz IPS Gaming Monitor Power Cable DisplayPort Cable USB 3.0 Cable Limited 3-Year Warranty User Manual PDF 916.8kb More from Manufacturer Table of Contents
|
Upload User Manual
Have you got an user manual for the ViewSonic XG2703GS 27" 16:9 WQHD 165 Hz IPS Gaming Monitor in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersViewSonic XG2703GS Specs | | | Size | 27" | | Panel Type | IPS-Type LCD | | Touchscreen | No | | Resolution | 2560 x 1440 | | Finish | Matte | | Hardness Rating | 3H | | Maximum Brightness | 350 cd/m2 | | Contrast Ratio | 1000:1 | | Dynamic Contrast Ratio | 120,000,000:1 | | Refresh Rate | 165 Hz | | Adaptive Sync Technology | None | | Bit Depth / Color Support | 8-Bit (16.7 Million Colors) | | Response Time | 4 ms | | Viewing Angle | Horizontal: 178°
Vertical: 178° | | Backlight Lifespan | 30,000 Hours | | | | Connectivity | 1 x 3.5 mm Output
1 x USB Type-B 2.0
2 x USB Type-A 2.0
2 x USB Type-A (USB 3.1 Gen 1)
1 x HDMI 1.4
1 x DisplayPort | | Built-In Speakers | Yes, 2 x 2 W | | | | Power Consumption | 40 W (Eco)
71 W (Maximum)
48 W (Typical) | | AC Input Power | 100 to 240 VAC, 50 / 60 Hz | | | | Operating Temperature | 32 to 104°F / 0 to 40°C | | Operating Humidity | 20 to 90% | | | | Height Adjustment | 3.9" / 10 cm | | Rotation Adjustment | 90° | | Swivel Adjustment | 350° | | Tilt Adjustment | -5 to 15° | | Mounting-Hole Pattern | 100 x 100 mm | | Dimensions (W x H x D) | 24.6 x 15.1 x 3.1" / 62.4 x 38.4 x 7.9 mm (Without Stand)
24.6 x 21.0 x 9.9" / 62.4 x 53.2 x 25.0 mm (With Stand) | | Weight | 15.4 lb / 7 kg (With Stand)
8.8 lb / 4 kg (Without Stand) | | | | Package Weight | 22.7 lb | | Box Dimensions (LxWxH) | 29.0 x 18.0 x 12.0" |
