Product description The 9" 3G-SDI Video Production Rackmount Monitor from ViewZ is a 4 RU monitor with a resolution of 960 x 540 and an SDI to HDMI converter. It features 12-bit to 8-bit dithering, and Gamma 2.2-base calibration. The monitor is compatible with VZ-CSP Color Calibration Software, and provides a full screen audio level meter. This monitor can be remotely controlled via an RJ45 connector. - 12-bit to 8-bit dithering
- Integrated two-channel audio waveform & vectorscope
- Embedded 16-channel full screen audio level meter and built-in speaker
- 3G-SDI level A/B (YCbCr, RGB 4:4:4) support
- Selectable Y/R/G/B histogram (SD/HD-SDI)
- Y-clip guide min/max select (SD/HD-SDI)
- False color (SD/HD-SDI) & focus assist (SD/HD-SDI)
- DSLR scaling (HDMI) & DPMS select
- H/V delay, red/green mode tally
- Zero, over, and pixel-to-pixel scan
- Closed caption (CEA-608/708)
- UMD (TSL protocol) & timecode
- Blue and Mono screen color modes
- Precise white balance and Gamma
- Compatible with color calibration software package (VZ-CSP)
In the Box ViewZ 9" 3G-SDI Video Production Rackmount Monitor (4 RU) Limited 2-Year Warranty (Parts) Limited 90-Day Warranty (Labor) Limited 33,000-Hour Warranty (MTBF Approx.) Table of Contents
|
Upload User Manual
Have you got an user manual for the ViewZ 9" 3G-SDI Video Production Rackmount Monitor in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersViewZ VZ-090RM-P Specs | Screen Size | 9" (22.9 cm) | Max Resolution | 960 x 540 | Brightness | 400 cd/m² | Contrast Ratio | 1000:1 | Aspect Ratio | 16:9 | Viewing Angle (H/V) | 170°/170° | Color Depth | 16.7 M (8-bit) | | SDI | SMPTE 425M-AB: 1080p (60/59.94/50/30/29.97/25/24/23.98) 1080i (60/59.94/50) 1080PsF (30/29.97/25/24/23.98)SMPTE 274M: 1080p (30/29.97/25/24/23.98) 1080i (60/59.94/50) 1080PsF (30/29.97/25/24/23.98)SMPTE 260M: 1035i (60/59.94)SMPTE 296M: 720p (60/59.94/50/30/29.97/25/24/23.98)SMPTE 125M: 525i (NTSC 59.94)ITU-R BT.601: 625i (PAL 50)2K Format: 2048 x 1080p (24/23.98/24sF/23.98sF) | HDMI | 1080p/1080i/576p/576i/480p/480i | Analog | CVBS, S-Video: NTSC (525/59.94i) PAL (625/50i)Component: 1080p (60/59.94/50/ 30/29.97/25/24/23.98) 1080i (60/59.94/50) 720p (60/59.94/50) | | Power | 4-pin XLR (12 - 24 VDC) Consumption: 2 x 15 W | Operating Temperature | 32 - 104°F (0 - 40°C) | Gamut Coverage | Panel native value | Gamma | 2.2 base | Color Temperature | 3200K, 6500K, and 9300K | Connectors | Input: 2 x SDI input 1 x HDMI input 1 x PGM port, (program update/HDMI connector) 3 x BNC, input (CVBS, S-video, component) 1 x RS-422 input 1 x Audio input 1 x RJ-45 input (remote control) 1 x 4-pin XLR, 12 - 24 VDC power inputOutput: 1 x SDI output 1 x RS-422 output 1 x Audio output (analog stereo) | Speaker | 2 x 1 W | Screen Mode | Blue and mono | Dimensions | 19 x 6.88 x 4.8" (483 x 175 x 122 mm) | Weight | 11 lb (5 kg) | | Package Weight | 13.6 lb | Box Dimensions (LxWxH) | 22.6 x 11.9 x 7.1" |
