User Manual for Vivotek 32-Channel 12MP NVR Click to enlarge the picture
Contents of the user manual for the Vivotek 32-Channel 12MP NVR
- Product category: Network Video Recorders (NVRs) Vivotek
- Brand: Vivotek
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Vivotek Network Video Recorders (NVRs)
|
User manual for the Vivotek 32-Channel 12MP NVR contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Vivotek product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Vivotek user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Vivotek product will considerably shorten its lifespan!
|
Product description Enable live viewing, recording, and playback of up to 32 cameras using the 32-Channel 12MP NVR from Vivotek. The NVR has a recording resolution of up to 12MP, and it can record at frame rates of up to 30 fps. H.265, H.264, and MJPEG formats provide data size options and allow you to maximize storage and bandwidth without compromising video quality. The NVR contains four drive bays, each with a 6TB capacity for a total of up to 24TB of storage. The NVR also supports snapshots in JPEG formatting and video clip export in EXE files. Additionally, a 1/8" audio input and output provide two-way audio, with G.711 and G.726 audio formatting.
A number of monitor enhancements allow you to manage your system while you are live viewing, including an OSD display, camera information, remote I/O control, event notification, aspect ratio, and fisheye dewarp. During playback you can use standard media buttons (play, pause, stop) as well as speed controls, the calendar, events, timelines, and storyboard thumbnails. Furthermore, video footage can be searched by calendar, date/time, and alarm. The NVR will alert you in cases of motion detection, PIR detection, tampering detection, digital input, digital output, connection abnormality, storage abnormality, full storage, and camera network loss.
Mobile applications for iOS and Android smartphones and tablets are supported, enabling you to view live video from anywhere in the world. Using EZConnect technology, you can connect your mobile device to your system by simply scanning the included QR code. The NVR comes with an embedded Linux operating system as well as integrated VIVOTEK Camera Configuration and VAST CMS. Dual LAN network ports offer failover protection, and HDMI and VGA outputs allow for HD dual streaming. ONVIF-compliance provides compatibility with a wide range of surveillance devices, enabling you to connect the NVR to a variety of cameras and related equipment. - H.265 / H.264 compression technology
- Plug and play one-button auto setup
- EZConnect by scanning the QR code for 24/7 mobile viewing
- Integrated VIVOTEK camera configuration and VAST CMS
- Fisheye dewarp for both live viewing and playback
- Four drive bays, each with a 6TB capacity, for a total capacity of 24TB
- Embedded Linux operating system
- Supports up to 12MP camera live view and playback
- Dual LAN network ports with failover function
In the Box Vivotek 32-Channel 12MP NVR Power Adapter Power Cord USB Mouse 4 x SATA Cables 32 x H.D.D. Screws 8 x H.D.D Brackets Limited 2-Year Warranty Guides & Manuals Table of Contents
|
Upload User Manual
Have you got an user manual for the Vivotek 32-Channel 12MP NVR in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Download User ManualThe user manual for the Vivotek 32-Channel 12MP NVR can be downloaded in PDF format at the link stated below.
Technical parametersVivotek ND9541 Specs | | | Operating System | Embedded Linux | | CPU | ARM processor | | Flash | 256 MB | | RAM | 4 GB | | Power Restoration | Automatic system restart after power recovery | | | | HDD Trays | 4 x internal | | Max. HDD Capacity | 4 x 6 TB | | Disk Management | Create, format, and remove disk
HDD S.M.A.R.T | | | | Video Output | 1 x HDMI, 1 x VGA | | Resolution | 1920 x 1080 (1080p), 1280 x 720 (720p) | | Graphics Decoder | Hardware decoding | | Frame Rates | 2560 x 1920 @ 30 fps (1 channel)
1920 x 1080 @ 120 fps (4 channel)
1280 x 720 @ 240 fps (8 channel)
1280 x 720 @ 480 fps (16 channel)
720 x 480 @ 960 fps (32 channel) | | Camera Position | Change the view cell position on the Live View screens | | | | Throughput | Recording: 192 Mbps
Network: 96 Mbps | | Video Format | MJPEG, H.264, H.265 | | Audio Format | G.711, G.726 | | Video Resolution | Supports VGA, 1 MP, 2 MP, 3 MP, 5 MP, 12 MP cameras | | Streaming | Single stream | | Recording Time | Pre-Record: 5 seconds (max: 10 seconds)
Post-Record: 20 seconds (max: 300 seconds) | | Recording Modes | Continuous, Schedule, Manual, Event, Activity Adaptive Streaming | | Settings | Recycle (unit: Day) | | Recording Path | Local | | Recording Video Format | 3 GP | | | | Stream Application | Auto adaptive stream | | Display | 32 Channels
Multi Layout Display: 1x1, 1x3, (corridor view), 2x2, 3x3, 4x4, 1+5, 1+3, 1+12, 1+1+3 (1P), 1+3+3 (1P), 1+31 | | Monitor Enhancement | OSD display (NVR), OSD display (camera), camera information, remote I/O control, event notification, aspect ratio, fisheye dewarp
(1O, 1P, 1R, 1O3R, 1O8R) | | PTZ Control | Panel control | | PTZ Operation | Direction control, home, iris, preset, patrol (group), PiP control | | | | Display | 1 Channel
Multi Layout Display: 1x1 | | Playback Control | Regular (play, pause, stop), Rewind, Next / Previous Frame, Speed Control, Calendar, Event, Timeline, Timeline Scale, Thumbnail (storyboard) | | Video Search | By calendar, date/time, alarm | | Thumbnail Explorer | Listing the thumbnail of recorded video (max: 2 channels) | | Monitor Enhancement | OSD Display (camera), event notification, aspect ratio, PiP control, fisheye dewarp (1O, 1P, 1R, 1O3R, 1O8R) | | Snapshot | JPEG | | Video Clip Export | EXE | | | | Stream Application | Stream selection | | Audio | 1-Way | | Display | 32 Channels
Multi Layout Display: 1x1, 2x2, 3x3, 4x4, 1+3, 1+5, 1+12, 1+31 | | Monitor Enhancement | OSD display (NVR), drag & drop, image freeze, audio control, remote I/O control, event notification, bookmark, fisheye dewarp (1O, 1P, 1R) | | PTZ Control | Panel control | | PTZ Operation | Direction control, home, zoom, focus, iris, preset, patrol (group), PiP control | | Snapshot | JPEG | | | | Display | 4 Channels
Multi Layout Display: 1x1, 2x2, 1+3 | | Playback Control | Regular (play, pause, stop), Next Frame, Speed Control, Calendar, Timeline, Timeline Scale, Bookmark | | Monitor Enhancement | OSD display (NVR), drag & drop, audio control, PiP control, fisheye dewarp (1O, 1P, 1R) | | Snapshot | JPEG | | Video Clip Export | EXE | | | | Schedule | Continuous, Scheduled, Manual | | Event | Motion detection, PIR detection, tampering detection, digital input (camera), digital output (camera), connection abnormal, storage abnormal, storage full, camera network loss, DI, DO | | Action Type | Record, email (text), email (snapshot), FTP, buzzer, ePTZ control (go to preset), NVR DO, camera (DO) | | Recording Time | Pre-Record: 5 seconds (max: 10 seconds)
Post-Record: 20 seconds (max: 300 seconds) | | | | Manual | USB Dongle (FAT Format) | | | | Users | User Account: 16
User Account Time Limit: 10 minutes
User Level: Administrator / Regular User
User Feature Definition: By camera | | Log | System, Recording, User, Error | | Date & Time | Time Zone, Manual, Automatic, Sync NTP, Daylight Saving Time | | Firmware | Manual update | | Restore Default | Supported | | Backup / Restore | Supported | | Languages | Czech, English, French, German, Italian, Japanese, Korean, Polish, Portuguese, Russian, Spanish, Simplified Chinese, Traditional Chinese | | | | Insert Camera | Manual, search | | Video Settings | Compression, resolution, FPS, video quality | | Image Settings | Image display, image adjustment | | PTZ Control | Panel control | | PTZ Operation | Direction control, home, preset, patrol (group) | | Motion Detection | Supported | | ONVIF | Core Spec: Version 2.2 or above (by project)
Stream: Video (H.264, MPEG4, MJPEG)
Recording: Continuous, schedule, manual
Discover: Through "Insert Camera & Batch Insert" | | | | UPS | Compatibility: APC model | | | | USB | Front: 2 x USB 2.0
Rear: 1 x USB 3.0 | | Audio | 1 x 1/8" (3.5mm) phone jack audio output
1 x 1/8" (3.5mm) phone jack audio input (reserved) | | Alarm | Inputs: 8
Outputs: 4 | | RS485 | 1 x port (reserved) | | | | Interface | 2 x 10/100/1000 Mbps Ethernet (RJ45) | | Protocols | IPv4, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, SMTP, FTP, DHCP, NTP, DNS, DDNS, IP Filter | | | | Operating System | Microsoft Windows OS: XP/Vista/7/8/2008/2012 | | CPU | Intel Celeron or above | | Memory | 2 GB or above | | Ethernet | 10/100 Mbps | | Display Resolution | 1024 x 768 pixels or above | | Web Browser | Internet Explorer 10 (32 bit) or above | | Software AP | Installation Wizard 2, ST7501, VAST | | Mobile OS Support | EZConnect (iOS/Android), iViewer (iOS/Android) | | | | Input | 56 VDC, 2.5 A | | Consumption | 120 W (max) | | | | LED Indicators | Status, Record, HDD1, HDD2, HDD3, HDD4, Net1, Net2 | | Buttons | Power (front)/Reset (rear) | | Form Factor | Desktop | | Approvals and Compliance | CE, LVD, FCC, VCCI, UL | | Operating Temperature | 32 to 104°F (0 to 40°C) | | Humidity | 0 to 95% | | Dimensions | 16.9 x 15.7 x 1.8" (43.0 x 40.0 x 4,4 cm) | | Weight | 8.5 lb / 3.9 kg (without HDD) | | | | Package Weight | 15.4 lb | | Box Dimensions (LxWxH) | 22.1 x 21.3 x 6.9" |
