User Manual for Vixen Optics Advanced Polaris Declination Body Set Click to enlarge the picture
Contents of the user manual for the Vixen Optics Advanced Polaris Declination Body
- Product category: Mount Accessories Vixen Optics
- Brand: Vixen Optics
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Vixen Optics Mount Accessories
|
User manual for the Vixen Optics Advanced Polaris Declination Body contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Vixen Optics product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Vixen Optics user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Vixen Optics product will considerably shorten its lifespan!
|
Product description Vixen Optics' Advanced Polaris Declination Body Set gives users the Declination unit, and the AP Counterweight Bar in one package to properly balance your OTA when mounted. It is a principal part of the Advanced Polaris mount and functions as the DEC body of the mount as well as elevation axis of the APZ Alt-Az mount. Optional equipment such as the Manual Slow Motion Control Module, DEC Motor Module, and AZ Counterweight can be installed for added usability and versatility; and the built-in battery compartment allows it to power the DEC Motor Module on just four user-supplied AA batteries. The AP Counterweight Bar is compatible with Vixen's 1kg, 1.9kg, 2.8kg, 3.7kg counterweights. - Advanced Polaris Counterweight Bar Use the Vixen Optics Advanced Polaris Counterweight Bar to hold compatible weights to balance the mount and OTA which reduces stress on the mount and allows for easier movement while aligning, finding, or tracking an object. This bar is identical to the one that originally ships with the mount and works with Vixen's 1kg, 1.9kg, 2.8kg, and 3.7kg counterweights.
- Declination Body Unit for Advanced Polaris Mount Vixen Optics's Declination Body Unit is a principal part of the Advanced Polaris mount which functions as the DEC body of the mount as well as elevation axis of the APZ Alt-Az mount. Optional equipment such as the Manual Slow Motion Control Module, DEC Motor Module, AP Counterweight Bar and AZ Counterweight can be installed for added usability and versatility; and the built-in battery compartment allows it to power the DEC Motor Module on just four user-supplied AA batteries.
In the Box Bundle Items Advanced Polaris Counterweight Bar - Limited One-Year Warranty
Declination Body Unit for Advanced Polaris Mount - Limited One-Year Warranty
Table of Contents
|
Upload User Manual
Have you got an user manual for the Vixen Optics Advanced Polaris Declination Body Set in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parameters - Advanced Polaris Counterweight Bar
| Dimensions | Overall: 12.9 x 3.1" / 32.8 x 7.8 cm
Shaft diameter: 0.8" / 2.0 cm
Effective length: 10.6" / 26.9 cm | | Weight | 28.9 oz / 820.0 g | | | | Box Dimensions (LxWxH) | 6.0 x 6.0 x 1.0" | - Declination Body Unit for Advanced Polaris Mount
| Battery | 4 x AA
Alkaline, Ni-Cd, Ni-MH recommended | | Fuse | 125 V, 1A Type B | | Dimensions | 4.9 x 3.2 x 3.1" / 12.5 x 8.1 x 7.8 cm | | Weight | 17.3 oz / 490.0 g, without batteries |
