Product description The B&H Binocular Buying Guide Read More Combining excellent optical performance with ruggedness, portability, and comfort, the 10x28 Diamondback Binocular from Vortex Optics is ideal to take along on your hiking trips, when camping or traveling, or just in case. The specially designed optics feature improved transmission, contrast, and true color using fully multi-coated lenses and phase-corrected roof prisms. With the improved close focus of 6.5', you will get plenty of focusing range and a sharp focus on faraway scenery as well as close-ups of nearby street signs, monuments' details, or wildlife. The combination of 10x magnification and the 28mm objectives offers you a generous 5.1° angle of view that gives you good coverage of your targets.
The lightweight aluminum housing is purged with argon gas and sealed with O-rings to offer enhanced fog and waterproof performance. The short-hinge bridge is reduced in size, compared to previous generations of Diamondbacks, to cut overall weight and to expose more of tubes' surface for easy holding. To ensure that you have a non-slip grip and tuning, the body, oversized focusing ring, diopter ring, and twist-up soft tapered eyecups have rubberized coverings. The focusing knob and the diopter ring also have knurling for easy use even with gloves on. Also included with the binocular are a carry case, neck strap, rainguard, and tethered objective caps. - Optical Performance
-
- 10x magnification
- 28mm objective lenses
- Roof prism design
- Fully multi-coated lenses increase transmission, clarity, and brightness
- Phase-corrected prisms improve true color, contrast, and transmission
- 273' linear field of view at 1000 yd
- 6.5' close-focus distance
- Construction Details
-
- Lightweight and durable aluminum body
- Short-hinge bridge cuts weight and exposes more surface for handling
- Adjustable interpupillary distance: 56-74mm
- Slip-resistant rubber armor exterior
- Oversized knurled center focusing wheel
- Textured diopter ring on right eyepiece
- Twist-up soft tapered rubber eyecups
- Water and fogproof: O-ring sealed and argon purged
UPC: 875874006393 In the Box Vortex 10x28 Diamondback Binocular (Green/Black) Comfort Neck Strap Deluxe Carry Case Rainguard Tethered Objective Lens Covers Vortex VIP Unlimited Lifetime Warranty Summer Binocular Buying Guide Christopher Witt 07/14/2016 A Guide to Marine Binoculars Todd Vorenkamp 06/25/2015 Pentax Sport Optics Binocular Roundup Joseph Albanese 06/24/2015 A Guide to Birding with Binoculars Todd Vorenkamp 06/16/2015 wyweyybyttzbbtcdqcwdessvvzdzcxdct User Manual PDF 221.4kb Table of Contents
|
Upload User Manual
Have you got an user manual for the Vortex 10x28 Diamondback Binocular in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersVortex DB-201 Specs | Prism Type | Roof | | Magnification | 10 x | | Objective Lens Diameter | 28 mm | | Angle of View | 5.1° (Actual) | | Field of View | 267.7' @ 1000 yd / 89.2 m @ 1000 m | | Minimum Focus Distance | 41.9' / 12.8 m | | Exit Pupil Diameter | 3.5 mm | | Eye Relief | 16 mm | | Interpupillary Adjustment | 55.9 to 73.7 mm / 2.2 to 2.9" | | Focus Type | Center | | Tripod Mount | Yes (Adapter Optional) | | Dimensions | 4.6 x 4.4" / 11.7 x 11.2 cm | | Weight | 13.5 oz / 382.7 g | | | | Package Weight | 1.65 lb | | Box Dimensions (LxWxH) | 6.6 x 5.8 x 3.4" |
