Product description The B&H Binocular Buying Guide Read More Combining excellent optical performance with ruggedness, portability, and comfort, the 8x42 Diamondback Binocular from Vortex Optics is ideal to take along on hiking trips, when camping and traveling, or just in case. The optics feature improved transmission, contrast, and true color using fully multi-coated lenses and phase-corrected roof prisms. With the improved close focus of 5' you will get plenty of focusing range and a sharp focus on faraway scenery as well as close-ups of nearby street signs, monuments' details, or wildlife. The combination of 8x magnification and the 42mm objectives offers you a generous 60° angle of view that gives you complete images of targets.The lightweight aluminum housing is purged with argon gas and sealed with O-rings to offer enhanced fogproof and waterproof performance. The short-hinge bridge is reduced in size, compared to previous generations of Diamondbacks, to cut overall weight and to expose more of the tubes' surface for easy holding. To ensure that you have a non-slip grip and tuning, the body, oversized focusing ring, diopter ring, and twist-up soft tapered eyecups have rubberized coverings. The focusing knob and the diopter ring also have knurling for easy use even with gloves on. Also included with the binocular are a carry case, neck strap, rain guard, and tethered objective caps. - Optical Performance
-
- Roof prism design
- 8x magnification
- 42mm objectives provide bright images in most lighting conditions
- Fully multi-coated lenses increase transmission, clarity, and brightness
- Phase-corrected prisms improve true color, contrast, and transmission
- Wide apparent angle of view: 60°
- 393' linear field of view at 1000 yards
- 5' close focus distance
- Exit pupil: 5.3mm
- Eye Relief: 17mm
- Use and Handling
-
- Short-hinge bridge cuts weight and exposes more surface for handling
- Adjustable interpupillary distance: 55-75mm
- Oversized knurled center focusing wheel
- Textured diopter ring on right eyepiece
- Twist-up soft tapered rubber eyecups
- Construction Details
-
- Lightweight and durable aluminum body
- Slip-resistant rubber armor exterior
- Water and fogproof: Argon-purged and O-ring sealed
UPC: 875874006423 In the Box Vortex 8x42 Diamondback Binocular Neck Strap Carry Case Rainguard Eyepiece Cover Tethered Objective Lens Covers Limited Lifetime Warranty Summer Binocular Buying Guide Christopher Witt 07/14/2016 A Guide to Marine Binoculars Todd Vorenkamp 06/25/2015 Pentax Sport Optics Binocular Roundup Joseph Albanese 06/24/2015 wyweyybyttzbbtcdqcwdessvvzdzcxdct A Guide to Birding with Binoculars Todd Vorenkamp 06/16/2015 User Manual PDF 221.4kb Table of Contents
|
Upload User Manual
Have you got an user manual for the Vortex 8x42 Diamondback Binocular in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersVortex DB-204 Specs | Prism Type | Roof | | Magnification | 8 x | | Objective Lens Diameter | 42 mm | | Angle of View | 7.5° (Actual) | | Field of View | 393.7' @ 1000 yd / 131.2 m @ 1000 m | | Minimum Focus Distance | 5' / 1.5 m | | Exit Pupil Diameter | 5.3 mm | | Eye Relief | 17 mm | | Interpupillary Adjustment | 55 to 75 mm / 2.2 to 3" | | Focus Type | Center | | Tripod Mount | Yes (Adapter Optional) | | Dimensions | 5.8 x 5.1" / 14.7 x 12.9 cm | | Weight | 21.8 oz / 618 g | | | | Package Weight | 2.35 lb | | Box Dimensions (LxWxH) | 8.35 x 7.5 x 3.8" |
