User Manual for Vortex Spitfire AR Prism 1x Riflescope Click to enlarge the picture
Contents of the user manual for the Vortex Spitfire AR Prism 1x Riflescope
- Product category: Red Dot/Holographic Sights Vortex
- Brand: Vortex
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Vortex Red Dot/Holographic Sights
 |
User manual for the Vortex Spitfire AR Prism 1x Riflescope contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Vortex product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Vortex user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Vortex product will considerably shorten its lifespan!
|
Product description Designed for the AR platform, the Spitfire AR Prism 1x Riflescope from Vortex Optics will help you get on target quickly. Its Dual Ring Tactical reticle is etched directly onto the prism and assures consistent point-of-aim at all times, even without illumination. The Spitfire offers a choice of red or green reticle illumination with five intensity levels for each, operated by rear-facing power and intensity controls. All air-to-glass surfaces have multiple anti-reflective coatings for optimal light transmission, and the scope is nitrogen-filled and O-ring sealed for water and fogproof performance. You can replace the standard elevation turret cap with an included yardage-marked BDC cap for rapid dialing of known-distance shots out to 700 yards. - Optical Performance
-
- 1x magnification
- Anti-reflective fully multi-coated optics minimize light loss, and maximize contrast and color transmission
- Reticle is etched on the prism, allowing you to see it whether or not the illumination is engaged
- Use and Handling
-
- Five red and five green reticle brightness levels
- Included BDC turret cap for rapid dialing of known-distance shots (5.56 cartridge)
- 1/2 MOA per click impact point correction
- 120 MOA windage and elevation adjustment range
- Fast focus eyepiece with a 3.8" eye relief
- Construction Details
-
- Single-piece aluminum housing
- Nitrogen-filled, water and fogproof
- Mounted at lower 1/3 co-witness height of 40.4mm from optic center to base surface
- Picatinny rail mount
- -22 to 122°F operating temperature range
- Flip caps
UPC: 875874001602 In the Box Vortex Spitfire AR Prism 1x Riflescope 2mm Hex Wrench 3mm Hex Wrench 5.56 BDC Turret Cap AAA Battery Set Flip Caps Limited Lifetime Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Vortex Spitfire AR Prism 1x Riflescope in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersVortex SPITFIRE Specs | | | Power Source | 1 x AAA | | Runtime | 250 to 3000 Hours | | Mounting | Picatinny / Weaver | | | | Magnification | 1 x | | Objective Lens Diameter | 25 mm | | Field of View | 79' @ 100 yd / 26.2 m @ 100 m | | | | Impact Point Correction | 1/2 MOA | | Windage Adjustment | 120 MOA | | Elevation Adjustment | 120 MOA | | | | Dimensions | L: 4.3" / L: 10.9 cm | | Weight | 11.2 oz / 317.5 g | | | | Package Weight | 0.915 lb | | Box Dimensions (LxWxH) | 6.75 x 3.95 x 2.45" |
