Product description The VOX AC15HW60 is a 60th anniversary recreation of the 1957 VOX AC15/4 tube amplifier for guitarists seeking the legendary tone of a rare, classic combo for recording and performing on stage. The two-channel 15W RMS amp was handcrafted and handwired in the United Kingdom.Eight tubes, including an EF86 preamp tube, and custom-wound transformers deliver the unmistakable VOX tone. The 12” Celestion Alnico Silver speaker has been brought back exclusively for VOX’s 60th anniversary and three power outputs are provided for connection to external speakers. Each of the channels features high and low 1/4" inputs, and Brilliance and Cut controls allow you to refine your tone. The adjustable vibrato can be switched on or off via the included footswitch.The Baltic birch ply cabinet features the signature VOX tolex covering and diamond cloth face. A custom amp cover is included to protect the AC15HW60 from dust and scratches. - Faithful to the original 1957 VOX AC15/4, the 60th Anniversary AC15 amp is equipped with an EF86 tube, diamond cloth, and a split-baffle design
- The all-tube design features eight tubes, including three 12AX7s, an EF86, a 12AU7, two EL84s, and an EZ81
- 12" Celestion Alnico Silver speaker
- Two channels, Normal and Vib-Trem, offer tube tone and VOX vibrato
- Tone controls include Brilliance and Cut
- High and low 1/4" inputs for each channel
- Multiple power outputs for external speakers
- Handcrafted and handwired in the United Kingdom
- Includes footswitch for convenience
In the Box VOX AC15HW60 60th Anniversary AC15 Handwired 15W 1x12" Tube Combo Amplifier Power Cord Footswitch Dust Cover Limited 1-Year Warranty for Amplifier Limited 90-Day Warranty for Tubes and Footswitch Table of Contents
|
Upload User Manual
Have you got an user manual for the VOX AC15HW60 60th Anniversary AC15 Handwired 15W 1x12" Tube Combo Amplifier in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersVOX AC15HW60 Specs | | | Amplifier Type | Tube | | Output Power | 15 W RMS | | Channels | 2 | | Tube Types | 1 x Preamp EF86
3 x Preamp 12AX7/ECC83
1 x Preamp 12AU7/ECC82
2 x Power EL84/6BQ5
1 x Rectifier EZ81/6CA4 | | Output Impedance | 8/16 Ohms Mono | | Effects Loop | No | | Built-In Effects | Vibrato | | Master Volume | No | | Inputs | 2 x 1/4" Hi Instrument
2 x 1/4" Low Instrument
1 x 1/4" Mono Footswitch | | Outputs | 3 x 1/4" Mono External Speaker | | Tone Section | Channel 1: Channel Volume, Presence, Treble
Channel 2: Channel Volume, Presence, Treble | | | | Configuration | 1 x 12" Speaker(s) | | Cabinet Type | Straight Semi-Open Mono | | Power Rating | 15 W RMS | | Input Impedance | 16 ohms Mono | | Construction Material | Baltic Birch | | Covering | Tolex | | | | Dimensions (WxHxD) | 21.0 x 22.6 x 10.9" / 533.0 x 575.0 x 278.0 mm Combo | | Weight | 52.91 lb / 24.00 kg Combo |
