User Manual for Weldex 17" TFT LED-Backlight LCD Flat Screen Rack Mountable Monitor Click to enlarge the picture
Contents of the user manual for the Weldex 17" TFT LED-Backlight LCD Flat
- Product category: Surveillance Monitors Weldex
- Brand: Weldex
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Weldex Surveillance Monitors
|
User manual for the Weldex 17" TFT LED-Backlight LCD Flat contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Weldex product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Weldex user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Weldex product will considerably shorten its lifespan!
|
Product description View vibrant, dynamic pictures with the 17" TFT LED Backlight LCD Flat Screen Rack Mountable Monitor from Weldex. Featuring 1280 x 1024 resolution and 16.7M colors with 250 cd/m² brightness, the monitor depicts the finest details accurately and clearly. The on-screen display menu provides feature and video adjustments for quick changes to contrast, color, language, and video and input selection. It also features multiple inputs for input video signals and a built-in speaker for monitoring incoming audio signals. - Design fits in a standard 19" rack mount housing
- Displays images with resolutions up to 1280 x 1024 pixels
- Composite video, S-video, and VGA PC inputs for video signals
- Features audio (left / right) line inputs and built-in speaker
- Supports 16.7 million colors for true color rendition
- Automatic input tuning or manual input selection
- Wide viewing angle of 140° horizontal and 150° vertical
- On-screen menu display for feature and video adjustments
In the Box Weldex 17" TFT LED-Backlight LCD Flat Screen Rack Mountable Monitor Power Supply Wireless Remote Control with Batteries 15-Pin VGA Cable Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Weldex 17" TFT LED-Backlight LCD Flat Screen Rack Mountable Monitor in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersWeldex WDL-1700MR Specs | Display Type | Color active matrix TFT | | Diagonal Screen Size | 17.0" (43.2 cm) | | Pixel Pitch (H x V) | 0.264 x 0.264 mm | | Back Light | LED | | Resolution | SXGA (1280 x 1024) | | Contrast Ratio | 1000:1 | | Brightness | 250 cd/m2 | | Response Time | Rising TR: 3.8 ms / Falling TF: 1.2 ms | | Viewing Angle | Up: 80° / Down: 80° / Right: 85° / Left: 85° | | Colors | 16.7M | | Video Input | 1 x Analog RGB, 15-pin (D-sub type) VGA composite, RCA connector, S-video, S-VHS connector (Y/C) | | Audio | Right / Left Line-in, RCA connectors
PC audio input / output (headphone jack) | | Power Requirements | 55 W maximum | | Power Saving | VESA DPMS | | Mounting | 19.0" (48.2 cm) rack mountable | | Standards | FCC, CE, CCIB, TCO 99 certified | | Dimensions (WxHxD) | Flange / Trim: 19.0 x 15.6 x 3.0" (48.2 x 39.6 x 7.6 cm)
Body: 16.5 x 14.5 x 2.0" (41.9 x 36.8 x 5.1 cm) | | Weight | 15.4 lb (6.9 kg) |
