Product description A complete kit for building a versatile lighting tool, Westcott's theC47 Book Light Kit includes the necessary Slim Jim Cine framework, connectors, and fabrics to create an adjustable V-shaped light modifier that is well-suited for interview and narrative lighting. Created in collaboration with Jem Schofield, founder of the popular filmmaking educational site, theC47, this kit is designed to produce a uniquely soft, flattering quality of light by both bouncing and diffusing the original source. - Scrim Jim Cine Frame Tube (22") The integral component within a modular system, this 22" long Scrim Jim Cine Frame Tube from Westcott is used to construct customized panels in sizes ranging from 1 x 1' to 8 x 8'. When paired with optional fabrics, such as silks or diffusers, frame tubes form the rigid support from which fabrics are attached to create flags, diffusion panels, book lights, v-flats, or numerous other light controlling tools.
This tube is constructed from anodized aluminum alloy and heavy-duty hook-and-loop tape is riveted to two sides of the tube for attaching fabrics. A 3/8"-16 threaded mount is incorporated into the tube for mounting atop stands and additional dedicated self-locking connectors are used to combine several pieces of tube to create flat 2D frames or dynamic 3D light shaping tools. - Tube measures 22" long and can be added to additional tubes through the use of dedicated, self-locking connectors.
- Anodized aluminum-alloy construction and self-locking connectors both help to maintain rigid, reliable frame configurations in various sizes up to 8 x 8'.
- Hook-and-loop tape is riveted onto two sides of the tube and is used for attaching a variety of fabric types to the frame system.
- A 3/8"-16 mount is incorporated into the tube's design for mounting to stands or other accessories.
UPC: 817967011884 - Scrim Jim Cine Swing Hinge Corner Frame Connector (2-Pack) Integral to the versatile and modular system design, this pack of two Scrim Jim Cine Swing Hinge Corner Frame Connector from Westcott is used to connect any four Scrim Jim Cine frame tubes at a hinged point for making V-flats, book lights, or other adjustable, positionable light control tools. A built-in positive locking button ensures a secure connection with the frame tube and its durable construction helps to maintain rigidity throughout long shoots and day-to-day use. UPC: 817967012898
- Scrim Jim Cine 2" Straight Frame Connector Integral to the versatile and modular system design, this Scrim Jim Cine 2" Straight Frame Connector from Westcott is used to connect any two Scrim Jim Cine frame tubes for creating a longer straight frame tube segment. A built-in positive locking button ensures a secure connection with the frame tube and its durable construction helps to maintain rigidity throughout long shoots and day-to-day use. UPC: 817967011907
- Scrim Jim Cine 2D Corner Frame Connector Integral to the versatile and modular system design, this Scrim Jim Cine 2D Corner Frame Connector from Westcott is used to connect any two Scrim Jim Cine frame tubes at a corner for making a 2D panel, reflector, flag, or other flat light modifier. A built-in positive locking button ensures a secure connection with the frame tube and its durable construction helps to maintain rigidity throughout long shoots and day-to-day use. UPC: 817967011914
- Scrim Jim Cine Unbleached Muslin/Black Fabric (4 x 6') A versatile tool that allows you to either block or subtly reflect light, the Scrim Jim Cine Unbleached Muslin/Black Fabric from Westcott is compatible with 4 x 6' Scrim Jim Cine frames and features a heavy-duty touch fastener lining for quick setup and convenient portability. This reversible fabric has both an opaque, matte black side and an unbleached muslin side, allowing you to quickly switch between applications. The black side is ideal for controlling and flagging light, while the muslin side offers some reflectivity without compromising the color temperature or look of skin tones.
- Reversible fabric features a matte black side and an unbleached muslin side.
- Opaque matte black fabric helps to control light, prevent light spill, and create shadows on a scene or subject. It is also suitable for use as a flag or barndoor for larger light sources.
- Unbleached muslin side can be used to subtly reflect light onto subjects without affecting the color temperature of the scene in order to maintain a natural appearance.
- Touch fastener lining permits quick installation and removal from 4 x 6' Scrim Jim Cine frames.
UPC: 817967012362 - Scrim Jim Cine 1/2-Stop Grid Cloth Diffuser Fabric (4 x 6') Allowing you to diffuse and direct ambient and artificial light sources, this Scrim Jim Cine 1/2-Stop Grid Cloth Diffuser Fabric from Westcott is compatible with 4 x 6' Scrim Jim Cine frames and features a heavy-duty touch fastener lining for quick setup and convenient portability. Constructed from nylon and silk fabrics, this diffusion does not affect the color temperature of light sources and helps to maintain natural-looking skin tones. As part of a modular system, this fabric is an ideal light control tool for a variety of both studio and on-location applications.
- This grid cloth diffuser directs and softens light sources for a clean overall light quality. It is ideal for use with large main light sources and when working in bright, sunlit conditions.
- Provides a 1/2 stop reduction in light output.
- Touch fastener lining permits quick installation and removal from 4 x 6' Scrim Jim Cine frames.
UPC: 817967012218 - Scrim Jim Cine Silver/White Bounce Fabric (4 x 6') A versatile two-sided reflective fabric, the Scrim Jim Cine Silver/White Bounce Fabric from Westcott is compatible with 4 x 6' Scrim Jim Cine frames and features a heavy-duty touch fastener lining for quick setup and convenient portability. This reversible fabric has both bright, cool silver and neutral white reflective sides, allowing you to quickly switch between applications. The silver bounce side adds bright, specular highlights and an overall cooling quality while the white side produces soft, natural looking highlights.
- Reversible fabric features a reflective silver side and a neutral white side.
- Silver side produces cool, bright highlights with a distinct specular quality.
- White side offers natural color rendition with bright, clean highlights.
- Touch fastener lining permits quick installation and removal from 4 x 6' Scrim Jim Cine frames.
UPC: 817967012522 - Scrim Jim Cine Full-Stop Diffuser Fabric (4 x 6') Allowing you to soften ambient and artificial light sources, this Scrim Jim Cine Full-Stop Diffuser Fabric from Westcott is compatible with 4 x 6' Scrim Jim Cine frames and features a heavy-duty touch fastener lining for quick setup and convenient portability. Constructed from nylon and silk fabrics, this diffusion does not affect the color temperature of light sources and helps to maintain natural-looking skin tones. As part of a modular system, this fabric is an ideal light control tool for a variety of both studio and on-location applications.
- This plain diffuser cloth is suitable for both artificial and ambient light sources and is ideal for overhead use, to soften harsh sunlight, or to place in front of a main light source for broad diffusion.
- Provides a full stop reduction in light output.
- Touch fastener lining permits quick installation and removal from 4 x 6' Scrim Jim Cine frames.
UPC: 817967012126 - Scrim Jim Deluxe Wheeled Travel Case Store and transport your Scrim Jim Cine frame system in the dedicated Scrim Jim Deluxe Wheeled Travel Case from Westcott. Scrim Jim Cine frame tubes, connectors, fabrics, and mounts can be safely and conveniently stored in this travel case. Additional fabrics and mounting hardware can fit within the case as well. Durable construction ensures your equipment is well protected as you commute from one location to the next. Padded straps and heavy-duty built-in wheels make transporting your equipment easy and convenient. UPC: 817967045759
In the Box Bundle Items 8 x Scrim Jim Cine Frame Tube (22") bwtfrwbruczbtewrday Scrim Jim Cine Swing Hinge Corner Frame Connector (2-Pack) 8 x Scrim Jim Cine 2" Straight Frame Connector 8 x Scrim Jim Cine 2D Corner Frame Connector bwtfrwbruczbtewrday Scrim Jim Cine Unbleached Muslin/Black Fabric (4 x 6') Scrim Jim Cine 1/2-Stop Grid Cloth Diffuser Fabric (4 x 6') Scrim Jim Cine Silver/White Bounce Fabric (4 x 6') Scrim Jim Cine Full-Stop Diffuser Fabric (4 x 6') Scrim Jim Deluxe Wheeled Travel Case
Also Includes - 8 x Scrim Jim Cine Frame Tube (34")
Table of Contents
|
Upload User Manual
Have you got an user manual for the Westcott theC47 Book Light Kit in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parameters - Scrim Jim Cine Frame Tube (22")
| Construction | Anodized aluminum, hook-and-loop tape on two sides | | Attachment Method | Integrated 3/8"-16 threaded mount
Compatible with self-locking connectors for building complete frame | | Dimensions | 22 x 1 x 1" / 55.9 x 2.5 x 2.5 cm | | Weight | 7.1 oz / 200 g | | | | Box Dimensions (LxWxH) | 21.6 x 1.4 x 1.2" | - Scrim Jim Cine Swing Hinge Corner Frame Connector (2-Pack)
| Dimensions | 6.75 x 3.0 x 1.0" / 17.2 x 7.6 x 2.5 cm | | Weight | 3.5 oz / 100 g | | | | Box Dimensions (LxWxH) | 4.25 x 4.05 x 2.4" | - Scrim Jim Cine 2" Straight Frame Connector
| Dimensions | 5.1 x 1 x 1" / 12.9 x 2.5 x 2.5 cm | | Weight | 3.5 oz / 100 g | | | | Box Dimensions (LxWxH) | 8.2 x 3.55 x 2.25" | - Scrim Jim Cine 2D Corner Frame Connector
| Dimensions | 2.75 x 2.75 x 1.1" / 7.0 x 7.0 x 2.9 cm | | Weight | 1.6 oz / 45.4 g | | | | Box Dimensions (LxWxH) | 8.7 x 1.25 x 1.2" | - Scrim Jim Cine Unbleached Muslin/Black Fabric (4 x 6')
| Type | Reversible; solid matte black block and unbleached muslin sides | | Material | Duvetyn fabric | | Care & Cleaning | Spot clean by hand with non-bleach laundry detergent | | Dimensions | 4 x 6' / 1.2 x 1.8 m | | Weight | 1.1 lb / 500 g | | | | Box Dimensions (LxWxH) | 12.5 x 9.1 x 3.0" | - Scrim Jim Cine 1/2-Stop Grid Cloth Diffuser Fabric (4 x 6')
| Type | Grid cloth diffusion | | Diffusion Strength | 1/2-Stop | | Material | Nylon and silk fabrics | | Care & Cleaning | Spot clean by hand with non-bleach laundry detergent | | Dimensions | 4 x 6' / 1.2 x 1.8 m | | Weight | 0.5 lb / 0.2 kg | | | | Box Dimensions (LxWxH) | 10.1 x 9.3 x 1.3" | - Scrim Jim Cine Silver/White Bounce Fabric (4 x 6')
| Type | Reversible; silver and white sides | | Material | Double-laminated cloth | | Care & Cleaning | Spot clean by hand with non-bleach laundry detergent | | Dimensions | 4 x 6' / 1.2 x 1.8 m | | Weight | 7.1 oz / 200 g | | | | Box Dimensions (LxWxH) | 10.1 x 7.9 x 1.4" | - Scrim Jim Cine Full-Stop Diffuser Fabric (4 x 6')
| Type | Plain diffusion | | Diffusion Strength | Full-Stop | | Material | Nylon and silk fabrics | | Care & Cleaning | Spot clean by hand with non-bleach laundry detergent | | Dimensions | 4 x 6' / 1.2 x 1.8 m | | Weight | 7.1 oz / 200 g | | | | Box Dimensions (LxWxH) | 9.6 x 1.6 x 0.01" | - Scrim Jim Deluxe Wheeled Travel Case
| Accommodates | Scrim Jim Cine frame system | | Material | Nylon | | Closure Method | Zippers | | Carrying/Transport Options | Padded straps
Built-in wheels | | Dimensions | 53.5 x 9.5 x 10.5" (135.9 x 24.1 x 26.7 cm) | | Weight | 11.7 lb (5.3 kg) | | | | Box Dimensions (LxWxH) | 54.0 x 11.0 x 11.0" |
